DvLED Cabinet Public 5000, 500x1000mm, No Modules-sold in multiples of 2

Ideal Use Cases

The PPDS Public 5000 44HDL5000PP/00 is a direct-view LED cabinet for creating audience-facing public displays with variable sizing and customizable curvature. Each cabinet measures 500 x 1000 x 40 mm and provides 0.50 m² of display area, giving system designers a consistent building block for larger visual installations. Landscape and portrait placement are supported, allowing the cabinet orientation to follow the intended display format.

This product is supplied without LED modules and is sold in multiples of two. It is therefore intended for planned system configurations in which the required modules, cabinet quantity, power distribution, and signal control components are specified together. The cabinet data lists a 1.9 mm pixel pitch, 256 x 512 cabinet resolution, and 131,072 cabinet pixels.

Why Choose This Model

The cabinet combines a slim 40 mm depth with die-cast aluminium construction and an 11.2 kg cabinet weight. Its 3840 Hz refresh rate, typical contrast ratio of at least 3000:1, and brightness uniformity of at least 97% provide clearly defined performance targets for a coordinated LED display system. Wide colour gamut picture enhancement is included, while brightness and colour calibration are supported for alignment across a multi-cabinet installation.

A 150-degree horizontal viewing angle and 150-degree vertical viewing angle support visibility across a broad audience area. Colour temperature is adjustable from 4000 to 9500 K, with a default specification of 6500 ±500 K.

Installation and Integration

Installation features include guide pins, a cabinet locking mechanism, and a lightweight cabinet design. These features help installers position and connect multiple cabinets within the planned display structure. The cabinet uses RJ45 for its data connection and signal control loop-through, with a NovaStar receiving card specified in the product data.

Power connectivity is provided through an input/output connector. For power loop-through, the stated limit is eight cabinets or fewer in 230 V environments and four cabinets or fewer in 110 V environments. These limits give integrators defined parameters when planning cabinet groups and electrical distribution.

One RJ45 CAT-5 LAN cable and one quick-start guide are listed as included. Because this is a no-module cabinet sold in multiples of two, the required LED modules and any other system components should be accounted for separately when preparing the complete installation.

Performance Highlights

Brightness is specified at 550 nits before calibration and no more than 500 nits after calibration. Typical power consumption is 120 W/m², while maximum power consumption is listed as 340 W/m² AC and 388 W/m² BC. The cabinet supports 50 Hz and 60 Hz frame frequencies in addition to its 3840 Hz refresh specification.

The provided technical data specifies a 128 x 128 module resolution and identifies three module pixel-pitch options within the product range: 1.9 mm, 2.5 mm, and 3.9 mm. For this cabinet listing, the stated pixel pitch is 1.9 mm. Its cabinet aspect ratio is 1:2, corresponding to the 500 x 1000 mm face dimensions and 256 x 512 cabinet resolution.

What Makes It Different

The Public 5000 cabinet brings together modular sizing, selectable orientation, customizable curvature, and loop-through signal and power connections in a die-cast aluminium format. Rather than being presented as a complete populated panel, this SKU is specifically identified as a cabinet without modules. That distinction allows the cabinet purchase to be coordinated with the intended module configuration while retaining defined cabinet dimensions, resolution, construction, and connection specifications.

Operational specifications include a temperature range of 20 to 45 °C and relative humidity of 10% to 80%. Storage specifications are 20 to 50 °C and 10% to 85% relative humidity.

Final Assessment

The 44HDL5000PP/00 is a clearly specified cabinet platform for Public 5000 direct-view LED installations. Its 500 x 1000 mm format, 1.9 mm listed pixel pitch, 3840 Hz refresh rate, NovaStar receiving card, RJ45 signal path, and supported calibration provide a defined foundation for system planning. It carries a two-year warranty and the listed regulatory approvals include RoHS, EAC, EN, IEC/UL, FCC SDOC, Part 15, and Class A standards. Buyers should account for the multiples-of-two ordering requirement and the fact that LED modules are not included.
