Screen Size (Diagonal) 98″
Resolution 3840 x 2160
Panel Type IPS-Type LCD
Bit Depth / Color Support 10-Bit (1.07 Billion Colors)
HDR Compatibility Hybrid Log Gamma
Brightness 500 cd/m
Viewing Angle (H x V) 178 x 178
Screen Area 84.9 x 47.8″ / 215.65 x 121.41 cm
Aspect Ratio 16:9
Contrast Ratio 1300:1
Dynamic Contrast Ratio 50,000:1, 50,000:1 Response Time 8 ms (GtG) Pixels Per Inch (ppi) 45 ppi Backlighting Technology Direct LED Connectivity
Response Time 8 ms (GtG)
Pixels Per Inch (ppi) 45 ppi
Backlighting Technology Direct LED
Primary Connectivity Location Display
Input Ports 2 x HDMI Video 1 x DisplayPort Video 1 x DVI-D Video 2 x 1/8″ / 3.5 mm Audio 1 x 15-Pin VGA Video
Output Ports 1 x DisplayPort Video
USB Ports 2 x USB (Version Unspecified) Type-A – Power
Ethernet Ports 2
Control RS-232C via DE-9/DB-9 IR via 1/8″ / 3.5 mm Input IR via 1/8″ / 3.5 mm Output
Other I/O 1 x RS-232C Control 1 x 1/8″ / 3.5 mm IR Input 1 x 1/8″ / 3.5 mm IR Output
Digital Media Slot None
Number of OPS/Expansion Slots 1
Display Orientation Landscape, Portrait
HDCP Support Yes, Version 2.2
Lighting Lifespan 50000 Hours
Surface Treatment Anti-Glare
Haze Level 28%
Built-In Speakers Yes, 2 x 10 W
External Speaker Output 2 x 15 W
Tilt Adjustment 0 to 20
Power Consumption Typical: 685.0 W Operational: 599.0 W Standby: 0.5 W
AC Input Power 110 to 240 VAC, 50 / 60 Hz
Apparent Power 703 VA
Operating Temperature 32 to 104 F / 0 to 40 C
Storage Temperature -4 to 140 F / -20 to 60 C
Operating Humidity 20 to 80%
Storage Humidity 20 to 80%
Operating Altitude 0.00 to 9186′ / 0 to 2800 m
Certifications CSA, EU, FCC, RCM, UL, as per Manufacturer
Wall Mounting 800 x 500 mm
Material of Construction Metal
Bezel Thickness 16 mm
Dimensions 86.4 x 49.2 x 3.5″ / 219.5 x 125.0 x 8.9 cm
Weight 198.5 lb / 90.04 kg
Package Weight 304 lb
Box Dimensions (LxWxH) 96 x 60.8 x 17″
1300 1 Contrast Ratio
Panasonic SQ1W Overview Slim and stylish design and 24/7 operation
Panasonic SQ1W Overview High image quality through HDR support (HLG system) that displays light and dark images in a realistic way, expand ability with ultra-slim Intel SDM (Intel Smart Display Module), DisplayPort connection for daisy-chain signage, multiple screen function (quad, PinP, PbyP), and 4K DIGITAL LINK
Panasonic SQ1W Overview 4K USB media player eliminates the need for external devices and allows updates via LAN
Panasonic SQ1W Overview Flexible and light installation either in portrait or landscape Failover and failback Key Features 4K UHD (3840 x 2160) Native Resolution 500 cd/m Brightness
1300:1 Contrast Ratio
Panasonic SQ1W Overview HDMI, DisplayPort, DVI-D, and VGA Ports 8 ms Response Time 178 Viewing Angles RS-232 & IR Control DIGITAL LINK Connectivity Two Built-In 10W Speakers 800 x 500mm VESA Compliant Panasonic SQ1W Specs Display
Panasonic SQ1W Overview Screen Size (Diagonal) 98″ Resolution 3840 x 2160 Panel Type
Bit Depth / Color Support 10-Bit (1.07 Billion Colors)
IPS-Type LCD HDR Compatibility Hybrid Log Gamma Brightness 500 cd/m Viewing Angle (H x V) 178 x 178 Screen Area 84.9 x 47.8″ / 215.65 x 121.41 cm
IPS-Type LCD Aspect Ratio 16:9
IPS-Type LCD Contrast Ratio 1300:1
2 x HDMI Video 1 x DisplayPort Video 1 x DVI-D Video 2 x 1/8″ / 3.5 mm Audio 1 x 15-Pin VGA Video
Input Ports Output Ports 1 x DisplayPort Video
2 x USB (Version Unspecified) Type-A Power
USB Ports Ethernet Ports 2 Control RS-232C via DE-9/DB-9 IR via 1/8″ / 3.5 mm Input IR via 1/8″ / 3.5 mm Output Other I/O 1 x RS-232C Control 1 x 1/8″ / 3.5 mm IR Input 1 x 1/8″ / 3.5 mm IR Output Digital Media Slot None
USB Ports Number of OPS/Expansion Slots 1 General Display Orientation Landscape, Portrait HDCP Support Yes, Version 2.2 Lighting Lifespan 50000 Hours Surface Surface Treatment Anti-Glare Haze Level 28% Audio Built-In Speakers Yes, 2 x 10 W External Speaker Output 2 x 15 W Convenience Tilt Adjustment 0 to 20 Electrical
Power Consumption Typical 685.0 W
Power Consumption Operational 599.0 W
Power Consumption Standby 0.5 W
Power Consumption AC Input Power 110 to 240 VAC, 50 / 60 Hz Apparent Power 703 VA Environmental
Power Consumption Operating Temperature 32 to 104 F / 0 to 40 C Storage Temperature -4 to 140 F / -20 to 60 C
Power Consumption Operating Humidity 20 to 80% Storage Humidity 20 to 80%, Altitude 0.00 to 9186′ / 0 to 2800 m Certifications
Power Consumption CSA, EU, FCC, RCM, UL, as per Manufacturer Physical Wall Mounting 800 x 500 mm Material of Construction Metal Bezel Thickness 16 mm Dimensions 86.4 x 49.2 x 3.5″ / 219.5 x 125.0 x 8.9 cm Weight 198.5 lb / 90.04 kg Packaging Info Package Weight 304 lb
Power Consumption Box Dimensions (LxWxH) 96 x 60.8 x 17″
SKU TH-98SQ1W
