The Panasonic Connect TH-98SQE2W 4K Professional Display is designed for 24-hour continuous operation and crystal-clear viewing clarity. The display provides a brightness of 500cd/m² with an anti-glare panel, and minimum haze treatment of 25%, reducing the reflection of ambient light and vastly improving visibility in all environments. For ultimate flexibility and a clean look without set-top-boxes or cables, the TH-98SQE2W is also equipped with a slot for the Intel SDM specification supporting applications, such as digital signage and broadcasts, using a built-in PC, terminal board, or wireless presentation system.

KEY FEATURES

• High image quality and high legibility suitable for various scenes
• Superb Reliability & Easy Installation
• Various external linkage suitable for conference room and signage applications

Specification

DISPLAY PANEL
Screen Size (Diagonal) 98-inch class (2476.9 mm / 97.51 inch)
Panel type / Backlight ADS / Direct-LED
Aspect ratio 16:9
Effective Display Area (W x H) 2158.8 x 1214.3 mm (84.99″ x 47.80″)
Resolution (H ｘ V) 3840 x 2160
Brightness (Typ) 500 cd/m2
Contrast Ratio (Typ) 1200:1
Dynamic Contrast Ratio 50000:1
Max. Display Colors Approx. 1.07 Billion
Response Time (Typ) 8.0 ms (G to G)
Viewing Angle (Horizontal / Vertical) 178 ° / 178 ° (CR>10)
Panel Life Time1
(Typ) Approx. 50000 hours
Panel Surface Treatment Anti-glare type (Haze 25%)

CONNECTION TERMINAL
HDMITM IN HDMITM Type A Connector x 4 (HDCP2.2)
DisplayPort IN DisplayPort x 1 (HDCP2.2)
DIGITAL OUT HDMITM Type A Connector x 1 (HDCP2.2)
SERIAL IN Stereo mini jack (Φ3.5 mm) x 1, RS-232C Compatible
IR IN Stereo mini jack (Φ3.5 mm) x 1
AUDIO OUT Stereo mini jack (Φ3.5 mm) x 1
SPDIF x 1
LAN RJ45 x 1 compatible with PJLinkTM　10BASE-T/100BASE-TX/1000BASE-T
USB
USB connector TYPE A x 1 : DC5 V / MAX 0.9 A, (USB 3.0 is supported)
USB connector TYPE A x 1 : DC5 V / MAX 0.5 A, (USB 2.0 is supported)
USB connector TYPE A x 1 : DC5 V / MAX 0.5 A, (USB 2.0 is supported) (Internal)
USB connector TYPE C x 1 : DC5 V / MAX 3.0 A, (USB 3.0 is supported, DP Alt Mode)

microSD microSD / SDHC / SDXC / MAX 1TB
Wifi / Bluetooth® Dongle　IEEE 802.11 a/b/g/n/ac Dual band　Bluetooth® 5.1 with BLE, HID / A2DP
SLOT Intel® SDM specification
Corresponding size SDM-S / SDM-L, Supply power 66W

AUDIO
Built in Speaker 24 W [(6 W x 2) + (6 W x 2)]

ELECTRICAL
Power Requirements AC110-240 V　50 Hz / 60 Hz
Power Consumption 715 W
On Mode Average Power Consumption1 566 W
Power Off Condition 0 W
Stand-by Condition 0.5 W
Apparent power 748 VA

MECHANICAL
Dimension (W x H x D) Not including remote controller sensor 2216 x 1271 x 99 mm (87.25″ x 50.02″ x 3.87″)
Dimension (W x H x D) Including remote controller sensor 2216 x 1288 x 99 mm (87.25″ x 50.67″ x 3.87″)
Weight 99.8kg / 220.1 lbs
Carton Dimensions (W x H x D) 2435 x 1684 x 387 mm (95.87″ x 66.30″ x 15.24″)
Gross Weight 150 kg / 330.7 lbs
Cabinet Material Metal
Bezel Color Black
Bezel Width T/R/L/B 28.2 mm (1.11″)
Pitch for Wall-Hanging VESA Compliant 800 x 400 mm (31.5″ x 15.8″) (Installed by: M8 screws / Screw hole depth: 12 mm (0.48″))

INSTALLATION
Orientation Landscape / Portrait (clockwise rotation)
Tilting Angle Landscape / Portrait installation 20 degrees forward/backward

MAIN FEATURE
Input search Yes
Multi display settings Yes
Power Management (HDMITM) Yes
Power save Yes
Button Lock Yes
Controller user level Yes
Dynamic backlight control Yes
Timer setting Yes
PJLink Yes
Image settings Yes
USB Media Player Yes
Memory Viewer Yes
Built-in memory function Yes
Data Cloning Yes
Multi Monitoring & Control
Software compatible
Yes
AndroidTM OS Yes
Local Dimming Yes
HTML5 Browser Yes
Wireless Display Yes
Operating Time1 24 h / day

Bluetooth®
Supported version Bluetooth® 5.1 with BLE
Profile HID / A2DP
