Network Remote Control with LEDs-Dante-Black

Ideal Use Cases

The RDL DB-NLC1 is a black Dante network remote control intended for fixed installations that require direct access to level and mute functions. Its three pushbuttons provide two level-adjustment controls and one mute control. Fifteen front-panel level indicators and a mute indicator give the operator visible status at the control location.

The unit is particularly suited to installations built around standard US electrical boxes. Its wall-mounted format keeps essential controls in a defined location, while the RJ45 network connection and Power over Ethernet requirement support integration with compatible network infrastructure. A cover plate is available separately.

Why Choose This Model

The DB-NLC1 combines physical controls, detailed visual feedback, and network connectivity in a compact device. Its 18 indicators consist of 15 front-panel level indicators, one mute indicator, and two rear-panel indicators for Ethernet Link and Activity. This arrangement provides control feedback on the front while retaining network-status information at the rear.

Two dedicated level buttons and a separate mute button keep the available operations clearly defined. The network interface supports a 100 Mbps transmission rate, and the RJ45 connector includes Link and Activity indication. Power is supplied through PoE Class 0 in accordance with IEEE 802.3af.

Installation and Integration

The DB-NLC1 mounts in a standard US electrical box. Its physical dimensions are 1.8 inches wide, 4.11 inches high, and 1.5 inches deep, equivalent to 4.57 by 10.44 by 3.81 centimeters. These measurements can be used when planning the electrical box, wall clearance, and surrounding finish. The required cover plate is offered separately, allowing it to be selected as part of the installation.

Network and power integration use the RJ45 connection and IEEE 802.3af PoE Class 0. This configuration supplies the unit through compatible PoE infrastructure. The specified ambient operating range is 0 degrees C to 40 degrees C, with 30 degrees C listed as the maximum recommended ambient temperature.

For design documentation, the source data lists a PDF specification sheet, CAD files in American DXF format, and an American DXF rear-panel diagram.

Performance Highlights

• Network connection: RJ45 with Ethernet Link and Activity indicators.
• Transmission rate: 100 Mbps.
• Front-panel indication: 15 level indicators and one mute indicator.
• Rear-panel indication: Ethernet Link and Activity indicators.
• Physical controls: Two level-adjustment pushbuttons and one mute pushbutton.
• Power requirement: PoE Class 0, IEEE 802.3af.
• Operating environment: 0 degrees C to 40 degrees C, with 30 degrees C maximum recommended.

These specifications define a focused network control interface: level adjustment, mute operation, front-panel status display, and rear network-status confirmation are provided without adding controls not identified for this model.

What Makes It Different

The DB-NLC1 places 16 of its 18 indicators on the front panel for level and mute status, while reserving two indicators on the rear for Ethernet Link and Activity. This separation makes the displayed information relevant to its location: operating feedback is presented at the user-facing panel, and connection feedback remains available at the network side.

The model also brings its three available functions into dedicated physical buttons rather than combining them into a multi-purpose control. Its black finish distinguishes this version, while its standard electrical-box mounting format defines how it fits into a fixed installation. The unit is packaged in a cardboard box measuring 3.625 by 4.625 by 2.125 inches, with a listed shipping weight of 0.5 pounds.

Final Assessment

The RDL DB-NLC1 is a purpose-built Dante network remote control for installations requiring wall-mounted level and mute access. It provides two level buttons, one mute button, 18 total indicators, 100 Mbps RJ45 networking, and IEEE 802.3af PoE Class 0 power. Its standard US electrical-box mounting, compact 1.8-by-4.11-by-1.5-inch dimensions, and separately available cover plate give system designers concrete installation requirements. For applications matching those controls and network specifications, the DB-NLC1 offers a clearly defined interface in a black finish.
