Key Features
75 , 1500 cd/m2, 4K IPS panel with slim and stylish design and 24/7 operation
Supports HDR (PQ and HLG), 12-axis Color Management Function and BT.2020 Emulation
A slot with Intel® SDM (Smart Display Module) specifications that supports 4K signals
Auto Brightness Adjustment function for efficient display operation
The SQ1H Series is a model that uses panels with a high brightness of over 1000cd/m², so it is compatible with installation in atriums exposed to glare and outdoor display windows. Compatible with the “12-axis Color Management Function” and “HDR”. Thoroughly displays the rich colors of 4K images. With easy, vertical installation, various types of installation have become possible. Also offering energy efficiency and high environmental reliability, this model is capable of constant, 24/7 operation. The SQ1H Series is equipped with the Intel® SDM specification slot standard that supports 4K signals. Combined with the interface board, you can easily use a built-in PC and add various interfaces. DIGITAL LINK function enables simple Installation and low system costs. By connecting the DisplayPort input/output terminals in a daisy chain, 4K images can be simultaneously displayed.
- 75″, 1500 cd/m2, 4K IPS panel with slim and stylish design and 24/7 operation
- Supports HDR (PQ and HLG), 12-axis Color Management Function and BT.2020 Emulation
- A slot with Intel® SDM (Smart Display Module) specifications that supports 4K signals
- Auto Brightness Adjustment function for efficient display operation
Specifications:
Display Panel
|
|
|
Panel size
|
75-inch class (1892.7mm)
|
|
Aspect ratio
|
16:9
|
|
Effective display area
(W x H)
|
1649.6 x 927.9 mm (64.94″ x 36.53″)
|
|
Resolution
|
3840 x 2160
|
|
Brightness (typ.)
|
1500 cd/m²
|
|
Contrast ratio (typ.)
|
1200:1
|
|
Response time (typ.)
|
10.0 ms (G to G)
|
|
Viewing angle [(T/B)/(L/R)]
|
178° / 178° (CR>10)
|
|
Panel Surface Treatment
|
Anti-glare type (Haze 1 %)
|
Terminals
|
|
|
HDMI In
|
HDMI TYPE-A Connector x 2 (Compatible with HDCP 2.2)
|
|
DisplayPort In
|
DisplayPort x 1 (HDCP2.2)
|
|
DisplayPort Out
|
DisplayPort x 1 (HDCP1.4)
|
|
DVI-D
|
DVI-D 24-pin x 1 (HDCP 1.1)
|
|
Serial in
|
D-sub 9-pin x 1, RS-232C Compatible
|
|
IR In/Out
|
Stereo Mini Jack (M3) x 1 / x 1
|
|
Audio In
|
Stereo Mini Jack (M3) x 1 0.5V [rms] (Shared each video input except USB and MEMORY VIEWER)
|
|
Audio Out
|
Stereo Mini Jack (M3) x 1, 0.5 V [rms], Variable (-∞ ~ 0 dB) (1 kHz 0 dB Input, 10 kΩ Load)
|
|
LAN
|
RJ45 x 1, 10 BASE-T / 100 BASE-TX, Compatible with PJLink™
|
|
DIGITAL LINK
|
RJ45 x 1, 100 BASE-TX, Compatible with long reach mode and PJLink™
|
|
Slot
|
Intel® SDM specification Corresponding size SDM-S/SDM-L, Supply power 3.3 V/MAX 1.1 A, 12 V/MAX 5.5 A
|
|
Sensor
|
4-pole sub-mini Jack (Φ 2.5 mm) x 1
|
|
USB
|
USB Connector (TYPE-A) x 2, DC 5 V/2 A, DC 5V/1A (USB 3.0 Supported)
|
Audio
|
|
|
Built-in speaker
|
20 W [10 W + 10 W]
|
|
External speaker out
|
30 W [15 W + 15 W] (10% THD)
|
Electrical
|
|
|
Power requirements
|
110–127 V AC, 50/60 Hz, 220–240 V AC, 50/60 Hz
|
|
Power consumption
|
720 W
|
|
Power off condition
|
Approx. 0.3 W
|
|
Standby condition
|
Approx. 0.5 W
|
Mechanical
|
|
|
Dimensions (W x H x D)
|
1684 x 962 x 96* mm (66.28″ x 37.86″ x 3.75″)
|
|
Weight
|
Approx. 42.2 kg (93.0 lbs)
|
|
Bezel width
|
14.9 mm (0.6″) (T/B/L/R)
|
|
Wall-hanging pitch
|
600 x 400 mm (23.62″ x 15.75″) VESA Compliant
|
Installation Environment
|
|
|
Orientation
|
Landscape/Portrait*1
|
|
Tilting angle
|
Landscape : 0-20 degrees forward / backward
Portrait : 0-20 degrees forward / backward
|
|
Operating time*2
|
24 h/day
|
Environment
|
|
|
Operating environment
|
Temperature: 0 °C to 40 °C (32 °F to 104 °F)/Humidity: 20-80 % (Non condensation)/for up to 0-1400 m (4593 ft) altitude.
Temperature: 0 °C to 35 °C (32 °F to 95 °F)/Altitude 1400 -2800 m (4593 ft to 7874 ft)
|
