Display System -Chip 0.55″ DMD DLP
Native Chip Resolution 1024 x 768 (XGA), 1024 x 768 (XGA) Supported Resolutions
Supported Resolutions VGA – 640 x 480 SVGA – 800 x 600 SXGA – 1280 x 1024 SXGA+ – 1400 x 1050 UXGA – 1600 x 1200 WUXGA – 1920 x 1200
Maximum Brightness 3200 Lumens
Aspect Ratio Native: 4:3
DLP Link 3D Yes
Scan Horizontal: 15 to 100 kHz Vertical: 50 to 120 Hz
Focus Manual
Lens f/2.4 – 3.1 (f = 17.09 – 29.05 mm)
Throw Distance 3 – 52.4′ / 0.914 – 15.972 m
Throw Ratio 1.5 to 2.5:1
Projection Size 30 – 300″ / 762.00 – 7620.00 mm
Keystone Correction Auto-Horizontal: 30 Auto-Vertical: 30
Ceiling Mountable Yes
Rear Screen Projection Yes
Wireless LAN / Wi-Fi None
Lamp Power 282 W 202 W
Expected Lamp Life Medium Brightness: 3500 Hours Low Brightness: 8000 Hours
Fan Noise Medium Brightness: 38 dB Low Brightness: 31 dB
Security Cable Lock Slot
Power Consumption Medium Brightness: 282 W Low Brightness: 202 W Standby Mode (Lamp Off): 2.4 W Low Brightness: 0.2 W
Dimensions (W x H x D) 13.4 x 3.5 x 10.1″ / 340.4 x 88.9 x 256.5 mm
Unit Weight (LB) 7.7 Lb
Package Weight 11.65 lb
Box Dimensions (LxWxH) 17.717 x 14.961 x 9.134″
Image Display Display System -Chip 0.55″ DMD DLP
VGA 640 x 480
SVGA 800 x 600
SXGA 1280 x 1024, 1400 x 1050
UXGA 1600 x 1200
WUXGA 1920 x 1200 Maximum Brightness 3200 Lumens
Aspect Ratio Native 4:3 DLP Link 3D Yes Scan
Aspect Ratio Horizontal 15 to 100 kHz
Aspect Ratio Vertical 50 to 120 Hz Lens Focus Manual Lens
Throw Distance Throw Ratio 1.5 to 2.5:1
Projection Size 30 300″ / 762.00 – 7620.00 mm Features Keystone Correction
Projection Size Auto-Horizontal 30
Projection Size Auto-Vertical 30 Ceiling Mountable Yes Rear Screen Projection Yes
Input/Output Connectors Wireless LAN / Wi-Fi None General Lamp Power 282 W 202 W Expected Lamp Life
Input/Output Connectors Medium Brightness 3500 Hours
Input/Output Connectors Low Brightness 8000 Hours
Fan Noise Medium Brightness 38 dB
Fan Noise Low Brightness 31 dB Security Cable Lock Slot
Power Consumption Medium Brightness 282 W
Power Consumption Low Brightness 202 W, 0.2 W
Standby Mode (Lamp Off) 2.4 W
Power Consumption Dimensions (W x H x D) 13.4 x 3.5 x 10.1″ / 340.4 x 88.9 x 256.5 mm
Power Consumption Unit Weight (LB) 7.7 Lb Packaging Info Package Weight 11.65 lb
Power Consumption Box Dimensions (LxWxH) 17.717 x 14.961 x 9.134″
SKU NP-M322X
Brand NEC
MPN NP-M322X
GTIN 00805736051827, 805736051827
UPC 805736051827
