Key Features
The NP-P501X provides built-in cornerstone correction including Pincushion and Barrel correction
It also features vertical lens shift, which helps facilitate flexible projector placement
Other features include a 16W mono speaker and IEU Lite (Image Express Utility Lite) for audio and video transmission from a computer to the projector over the network
Plus, the NP-P501X is compatible with NTSC, PAL and SECAM video systems as well
USED- LIKE NEW
NEC NP-P501X Overview
The NEC NP-P501X 5000-Lumen Multi-Region Installation Projector features an XGA 1024 x 768 native resolution. For connectivity, it affords dual HDMI inputs with HDCP, a USB viewer, a VGA input and more. It also supports both wireless LAN and wired LAN connectivity. The projector provides up to 5000 lumens of brightness and a contrast ratio of 4000:1. The 6000 hour lamp life and filter life ensure a lower overall cost of ownership as well.
The NP-P501X provides built-in cornerstone correction including Pincushion and Barrel correction. It also features vertical lens shift, which helps facilitate flexible projector placement. Other features include a 16W mono speaker and IEU Lite (Image Express Utility Lite) for audio and video transmission from a computer to the projector over the network. Plus, the NP-P501X is compatible with NTSC, PAL and SECAM video systems as well.
Main Features
Dual HDMI inputs with HDCP ensure quick switching between presentations and they also allow for simultaneous digital connections of HD sources including Blu-ray players, cable boxes, satellite receivers and computers The Carbon Savings Meter calculates the positive effects of operating the projector in Eco-mode, which is encouraged by an optional message at startup. A green Eco-mode button on the remote control makes the switch easy IEU Lite (Image Express Utility Lite) provides wired and wireless data transmission for audio and video from a computer to the projector (peer-to-peer) over the network AutoKeystone correction instantly projects a square image even when the projector is set up at a steep offset angle to the screen Variable audio-out allows you to adjust the volume of an external speaker system using the projector’s remote control 4000:1 contrast ratio ensures detailed images from all inputs Four audio inputs make it easier to add sound and enhance your presentations 16W mono speaker provides enough volume for large rooms Built-in cornerstone correction including Pincushion and Barrel correction Eco-mode extends lamp life, lowers audible noise and reduces total cost of ownership The projector’s 6000-hour filter reduces cleaning frequency for a lower total cost of ownership Vertical lens shift enables flexible projector placement Closed captioning enables decoding and display of text information from a video The integrated RJ-45 Ethernet jack with 10/100 BASE-T capability provides a quick connection to the LAN
Additional Features
Supports wireless LAN external control Active lens cover USB viewer Geometric correction Virtual remote Sleep timer Auto power on and quick power-off Built-in wall color correction Advanced AccuBlend AutoSense
NEC NP-P501X Specs
Image Display
| Display System |
3-Chip Micro Lens Array (MLA) LCD |
| Native Chip Resolution |
1024 x 768 (XGA) |
| Supported Resolutions |
VGA – 640 x 480
SVGA – 800 x 600
XGA – 1024 x 768
SXGA – 1280 x 1024
SXGA+ – 1400 x 1050
UXGA – 1600 x 1200 |
| Maximum Brightness |
5000 Lumens
3000 Lumens |
| Aspect Ratio |
Native: 4:3 |
| Scan |
Horizontal: 15 to 100 kHz
Vertical: 50 to 120 Hz |
Lens
| Focus |
Manual |
| Lens |
f/1.7 – 2.1 (f = 17.4 – 29 mm) |
| Throw Distance |
1.9 – 45.3′ / 0.579 – 13.807 m |
| Throw Ratio |
1.3 to 2.2:1 |
| Projection Size |
25 – 300″ / 63.50 – 762.00 cm |
Features
| Keystone Correction |
Manual: ± 30° |
| Ceiling Mountable |
Yes |
| Rear Screen Projection |
Yes |
| Built-In Speaker |
Yes (Mono) |
| Speaker Power |
16W |
Input/Output Connectors
| Wireless LAN / Wi-Fi |
Yes, Built-in |
General
| Lamp Power |
270 W
160 W |
| Expected Lamp Life |
Medium Brightness: 3500 Hours
Low Brightness: 6000 Hours |
| Fan Noise |
Medium Brightness: 37 dB
Low Brightness: 30 dB |
| Power Consumption |
Medium Brightness: 357 W
Low Brightness: 231 W
Standby Mode (Lamp Off): 10 W
Low Brightness: 0.2 W |
| Dimensions (W x H x D) |
15.7 x 4.5 x 11.1″ / 398.8 x 114.3 x 281.9 mm |
| Weight lb |
9.0 |
Packaging Info
| Package Weight |
12.5 lb |
| Box Dimensions (LxWxH) |
19 x 15.3 x 9″ |
