Contrast Ratio 300000:1
Economode 24,000 hours
Audible Noise 35.0 dB
Lamp Life 20000 hours
Short Throw No
Native Resolution 1920 x 1200
Display Technology LCD
Aspect Ratio 16:10 (WUXGA)
Image Size Diagonal 40 to 150 in. / 1.02 to 3.8m, NP11FL; 30 to 500 in. / 0.76 to 12.7m, NP12ZL, NP13ZL; 40 to 500 in. / 1.02 to 12.7m, NP41ZL; 50 to 500 in. / 1.27 to 12.7m, NP15ZL, NP40ZL, NP43ZL; 60 to 500 in. / 1.52 to 12.7m, NP14ZL; 100 to 400 in. / 2.54 to 10.16m, NP44ML-02LK
Inputs RGB1(analog): VGA 15 pin D-sub, Component video using ADP-CV1E adapter RGB2(digital): HDMI (V2.0) w/HDCP (V1.4/2.2) RGB3(digital): HDMI (V2.0) w/HDCP (V1.4/2.2) RGB4(digital): DisplayPort w/HDCP (V1.3) RGB5(digital): HDBaseT w/HDCP (V1.4/2.2) Audio 1: Stereo Mini Jack
Lens Shift Horz & Vertical
Outputs Audio Out: Stereo Mini Jack Monitor Out: HDBaseT w/HDCP (V1.4/2.2)
Data / Video Signals Supported Video Standards NTSC, NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM SD/HD Video Signal Compatibility 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 4K PC Signal Compatibility VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA, Quad HD Macintosh Signal Compatibility Yes Sync Compatibility Separate Sync / Composite Sync / Sync on G External Control RS-232, IR, HDBaseT, DDC/CI, RJ-45, USB (USB 2.0)
Digital Keystone Horizontal & Vertical
Throw Distance 2.5 to 68.5 ft. / 0.74 to 20.9m, (Throw Ratio): 0.8:1 Manual Fixed Lens , 1.16 1.56:1 Manual Zoom Lens w/lens shift , 1.46 3.02:1 Manual Zoom Lens w/lens shift , 2.90 4.79:1 Manual Zoom Lens w/lens shift , 4.59 7.02:1 Manual Zoom Lens w/lens shift , 0.32:1 Ultra-Short Throw Lens / 0.79 to 1.11:1 Motorized Zoom Lens / 1.30 to 3.02:1 Motorized Zoom Lens / 2.99 to 5.93:1 Motorized Zoom Lens
Unit Weight 53.8 lbs. / 24.4kg
Lens Zoom: Motorized Focus: Motorized F number, fnumber: (NP44ML-02LK) F=2.0, f= 6.27, (NP11FL) F= 2.3, f= 13.2mm, (NP12ZL) F= 2.2 to 2.69, f= 19.4 to 25.3mm, (NP13ZL) F= 1.7 to 2.37, f= 24.2 to 48.6mm, (NP14ZL) F= 2.2 to 2.64, f= 48.5 to 77.6mm, (NP15ZL) F=2.2 to 2.7, f= 76.6 to 116.5mm, (NP40ZL) F=2.0 to 2.5, f= 13.3 to 18.6mm, (NP41ZL) F=1.7 to 2.0, f= 21.8 to 49.8mm, (NP43ZL) F=2.2 to 2.6, f= 49.7 to 99.8mm
Projector Methods Front, Ceiling, Rear
Lumens (ANSI) 10000 ANSI Lumens
Dimensions (WxDxH) 23.6 x 8.5 x 19.3 in. / 599 x 216 x 490mm
NEC PA1004UL Overview Contrast Ratio 300000:1 Economode 24,000 hours Audible Noise 35.0 dB Lamp Life 20000 hours Short Throw No
NEC PA1004UL Overview Native Resolution 1920 x 1200 Display Technology LCD
NEC PA1004UL Overview Aspect Ratio 16:10 (WUXGA)
NEC PA1004UL Overview Image Size Diagonal 40 to 150 in. / 1.02 to 3.8m, NP11FL; 30 to 500 in. / 0.76 to 12.7m, NP12ZL, NP13ZL; 40 to 500 in. / 1.02 to 12.7m, NP41ZL; 50 to 500 in. / 1.27 to 12.7m, NP15ZL, NP40ZL, NP43ZL; 60 to 500 in. / 1.52 to 12.7m, NP14ZL; 100 to 400 in. / 2.54 to 10.16m, NP44ML-02LK Inputs
NEC PA1004UL Overview RGB1(analog) VGA 15 pin D-sub, Component video using ADP-CV1E adapter RGB2(digital): HDMI (V2.0) w/HDCP (V1.4/2.2) RGB3(digital): HDMI (V2.0) w/HDCP (V1.4/2.2) RGB4(digital): DisplayPort w/HDCP (V1.3) RGB5(digital): HDBaseT w/HDCP (V1.4/2.2) Audio 1: Stereo Mini Jack
NEC PA1004UL Overview Lens Shift Horz & Vertical Outputs
NEC PA1004UL Overview Audio Out Stereo Mini Jack Monitor Out: HDBaseT w/HDCP (V1.4/2.2)
NEC PA1004UL Overview Data / Video Signals
NEC PA1004UL Overview Supported Video Standards NTSC, NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM SD/HD Video Signal Compatibility 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 4K PC Signal Compatibility VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA, Quad HD Macintosh Signal Compatibility Yes Sync Compatibility Separate Sync / Composite Sync / Sync on G External Control RS-232, IR, HDBaseT, DDC/CI, RJ-45, USB (USB 2.0) Digital Keystone Horizontal & Vertical
Throw Distance Zoom Motorized Focus: Motorized F number, fnumber: (NP44ML-02LK) F=2.0, f= 6.27, (NP11FL) F= 2.3, f= 13.2mm, (NP12ZL) F= 2.2 to 2.69, f= 19.4 to 25.3mm, (NP13ZL) F= 1.7 to 2.37, f= 24.2 to 48.6mm, (NP14ZL) F= 2.2 to 2.64, f= 48.5 to 77.6mm, (NP15ZL) F=2.2 to 2.7, f= 76.6 to 116.5mm, (NP40ZL) F=2.0 to 2.5, f= 13.3 to 18.6mm, (NP41ZL) F=1.7 to 2.0, f= 21.8 to 49.8mm, (NP43ZL) F=2.2 to 2.6, f= 49.7 to 99.8mm
Throw Distance Projector Methods Front, Ceiling, Rear Lumens (ANSI) 10000 ANSI Lumens
Throw Distance Dimensions (WxDxH) 23.6 x 8.5 x 19.3 in. / 599 x 216 x 490mm
SKU NP-PA1004UL-B-41
Brand NEC
MPN NP-PA1004UL-B-41
GTIN 00805736073119, 805736073119
UPC 805736073119
