Description
Christie DWU1075-GS Overview
The black DWU1075-GS 10,875-Lumen WUXGA 1DLP Laser Phosphor Projector from Christie features laser phosphor illumination that eliminates the need for lamp and filter replacements and provides up to 20,000 hours of Illumination life. It uses Christie BoldColor Technology for accurate color reproduction. It offers a maximum resolution of 1920 x 1200 with a brightness level of 10,875 lumens. In addition, the projector is suitable for use in live events, corporate, houses of worship and smaller location-based entertainment venues.
Performance
- Solid state laser phosphor illumination combined with Christie BoldColor Technology for accurate color reproduction
- Advanced processing
- 162 MHz pixel clock
- Built-in color matching, constant intensity, and advanced warping and blending
- Compact and lightweight for easy transportation and handling
- Capable of 360° rotation and functions in portrait mode
- DVI, two HDMI inputs, and one HDMI loop out
- Accepts analog inputs via an HD15 connection for fixed installs and live events
- Features a 3G-SDI loop through input for rental stagers
- Horizontal and vertical scaling while maintaining aspect ratio on all inputs
- Quiet operation
- Automated camera-based stacking, warping, and blending capability allows for quick setup
- Up to 20,000-hour life (with 50% brightness)
3D Inputs
- HDMI 1.4, HDBaseT—frame packed, top/bottom, side by side
- Up to 120 Hz 3D output
- 3D Sync in (BNC) connector for genlocking projectors
- 3D Sync out (BNC) connector for genlocking projectors or controlling emitter or polarizer
Networking
- RS-232 in
- Control via HDBaseT
- Ethernet (10/100) RJ45 connections are fully compatible with the rugged and lockable EtherCon
- Built-in backlit keypad
- Wired remote control (3.5mm stereo)
- Loop out available for daisy chaining
Lens Mount
- Boresight adjustable
- Motorized horizontal and vertical lens offset
- Motorized zoom and focus adjustment
Regulatory
- UL/CSA/IEC 60950-1
- FCC Class A, CE, FDA, CCC, KC, PSE, CU, SABS, BIS, VCCI, RCM, Ukr, TER, SASO
- RoHS, REACH, and WEEE
Christie DWU1075-GS Specs
Image Display
| Display System | 1-Chip 0.67" DMD DLP |
| Native Chip Resolution | 1920 x 1200 (WUXGA) |
| Supported Resolutions | WUXGA - 1920 x 1200 |
| Maximum Brightness | White: 9500 Lumens Color: 9500 Lumens |
| Offset | 100% ± vertical 30% ± horizontal |
| Aspect Ratio | Native: 16:10 |
| Contrast Ratio | 1200:1 |
| Dynamic Contrast Ratio | 6000:1 |
| Color Wheel | 4-Segment (R/G/B/Y) |
| Scan | Horizontal: 15 to 9 kHz Vertical: 24 to 85 Hz |
Features
| Supported HDR Input Formats | None |
| Multi-Input Support (PIP/PBP) | None |
| Projection Tilt Option | No |
Input/Output Connectors
| Inputs/Outputs | 1 x 3G-SDI (BNC) Audio Output 1 x HDMI (HDMI Type-A) Video Output 1 x 3G-SDI (BNC) Audio Input 1 x DVI-D Video Input 1 x VGA (DE-15/DB-15) Video Input 1 x HDMI 1.4 (HDMI Type-A) Video Input 1 x USB Type-A Data Input 1 x Micro-USB Data Input 1 x RS-232 (DE-9/DB-9) LAN Input 1 x HDBaseT (RJ45) Control Input 1 x RJ45 Data Input 1 x Mini-HDMI Video Input 1 x BNC Control Input 1 x BNC Control Input 1 x 1/8" / 3.5 mm Mini Remote Input 1 x 1/8" / 3.5 mm Mini Remote Input |
Hardware
| Wireless LAN / Wi-Fi | None |
General
| Light Source | Laser Phosphor |
| Expected Lamp Life | Full Brightness: 20,000 Hours |
| Fan Noise | Medium Brightness: 35 dB |
| Security | None |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Power Consumption | Medium Brightness: 1070 W |
| Dimensions (W x H x D) | 19.9 x 22.2 x 7.6" / 50.5 x 56.4 x 19.3 cm |
| Weight | 54.9 lb / 24.90 kg |
Packaging Info
| Package Weight | 71.45 lb |
| Box Dimensions (LxWxH) | 30 x 23.8 x 14.8" |
