Full on/off (Christie RealBlack enabled): 2,000,000:1
Dynamic contrast: 5000:1
Full on/off (Christie RealBlack disabled): 1200:1
ANSI 250:1 |
| Display |
| Type |
1 x 0.66” DMD |
| Resolution |
4K UHD; 4.15MP; 2716x1528 (WQXGA+) DMD
3840 x 2160 (8,294,400 pixels) 16:9 |
| Illumination system |
| Type |
Laser phosphor with Christie BoldColor Technology |
| Typical lifetime |
20,000 hours to 50% |
| Signal inputs |
| Standard |
HDMI x 2 (HDMI 2.0b, HDCP 2.1 Compliant)
3GSDI x 1 (BNC)
DVI-D x 1 (digital only)
DisplayPort x 1 (versions 1.2)
USB x 1 (Type A)
Wi-Fi® dongle (optional) |
| Optional |
Terra SDVoE (optional input card)
12G SDI (optional input card)
HDBaseT (RJ45 x 1) |
| 3D & 2D HFR |
HDMI 1.4, HDBaseT – frame packed, top/bottom, side-by-side (up to 120Hz output)
Optional signal input up to 1920 x 1200 @ 120Hz over HDMI, DP and DVI
3D sync in (BNC) – for genlocking projectors
3D sync out (BNC) – for genlocking projectors, or controlling emitters |
| Signals |
Standard video signals up to 4096 x 2160 @ 60Hz (over a single cable; HDMI 2.0 or DP 1.2)
Horizontal and vertical scaling while maintaining aspect ratio, all inputs |
| Pixel clock |
Maximum input pixel rate 600 Mpix/s (supports 4096 x 2160 @ 60Hz / 3840 x 2160 @ 60Hz over HDMI & DP)
Minimum input pixel rate 27 Mpix/s (supports 480i @ 60Hz & 576i @ 50Hz) |
| Scan rates |
Horizontal: 15 kHz to 91 kHz
Vertical: 24 Hz to 85 Hz |
| Signal outputs |
| Monitor out (loop through) |
3GSDI x 1 (BNC)
DVI-D x 1 (Digital out) |
| Control and networking |
RS232 In
Control via HDBaseT
Ethernet (10/100) RJ45
Built-in backlit keypad
Wired remote control (3.5mm stereo) - loop out available for daisy chaining |
| Accessories |
| Standard |
IR remote w/ wired remote jack (wire not included)
AC line cords for projector head
User manual |
| Optional |
Christie One Rigging Frame
Lens adapter for E Series lenses
1DWUSB-BGN (wireless dongle for video and control)
HS fog filter covers + filters (order once per projector then only filters refills)
HS fog filter refills (1 set)
Christie One Mount Plus
One Mount Extender Rod
One Mount Rigging Kit (used with One Mount, One Mount Plus and/or One Mount Extender Rod)
Replacement remote control |
| Lens mount |
Boresight adjustable
Motorized horizontal and vertical lens offset (memory available)
Motorized zoom and focus adjustment (memory available for full ILS lenses) |
| Lens options |
1.20-1.73:1 zoom lens (full ILS)
1.7-2.21:1 zoom lens (full ILS)
2.12-2.83:1 zoom lens (full ILS)
2.83-5.66:1 zoom lens (full ILS)
5.66-10.18:1 zoom lens (full ILS) |
| Power requirements |
| Operating voltage |
Normal: 100-240 VAC @ 50/60Hz |
| Power consumption |
Maximum power consumption: 1070W
ECO1 mode (80%): 865W
ECO2 mode (50%): 540W |
| Operating current |
Normal mode: 9.0A ±15% (120 VAC), 4.8A ±15% (220 VAC)
ECO1 mode: 7.2A ±15% (120 VAC), 3.9A ±15% (220 VAC)
ECO2 mode: 4.5A ±15% (120 VAC), 2.45A ±15% (220 VAC) |
| Dissipation |
Normal mode: 3651 BTU/hr
ECO1 mode: 2951 BTU/hr
ECO2 mode: 1842 BTU/hr |
| Audible noise |
Typical: 39dB(A)
Eco mode: 33dB(A) |
| Physical specs |
| Dimensions |
(L x W x H) 23.6 x 20.5 x 8.4" (600 x 520 x 214mm) without feet |
| Weight (without lens) |
79.4 lb (36 kg) |
| Shipping dimensions |
(L x W x H) 35.6 x 29.9 x 14.8" (905 x 760 x 365mm) |
| Shipping weight |
99 lb (45 kg) |
| Operating environment |
Temp: 0 to 40° C (32 to 104° F)
Humidity: 0 - 85% non-condensing |
| Regulatory |
| Contact Christie for the timing of certifications: |
UL/CSA/IEC 60950-1
FCC Class A
CE
FDA
CCC
KC
PSE
CU
SABS
BIS
VCCI
RCM
Ukr
TER
SASO |
| This product conforms to all relevant European directives, standards, safety, health and environmental concerns |
RoHS
REACH
WEEE |
| Limited warranty |
Three years parts and labor on the projector
Three years or 15,000 hours parts and labor on the illumination system*
Contact an authorized Christie representative for full details of our limited warranty |
