Samsung LH75QBCNBGCXEN. Product design: Digital signage flat panel. Display diagonal: 190.5 cm (75″), Display technology: LED, Display resolution: 3840 x 2160 pixels, Display brightness: 350 cd/m², HD type: 4K Ultra HD. Operating hours (hours/days): 16/7. Operating system installed: Tizen 7.0
Specifications
Display
Display diagonal 190.5 cm (75″)
Display technology LED
Panel type VA
Display resolution 3840 x 2160 pixels
Display brightness 350 cd/m²
HD type 4K Ultra HD
Touchscreen No
Response time 8 ms
Contrast ratio (typical) 4000:1
Dynamic contrast ratio marketing name Mega Contrast
Viewing angle, horizontal 178°
Viewing angle, vertical 178°
Pixel pitch 0.429 x 0.429 mm
Active display area (W x H) 1650.24 x 928.26 mm
Display diagonal (metric) 189.3 cm
Colour saturation 72%
Horizontal scan range 30 – 81 kHz
Vertical scan range 48 – 75 Hz
Native refresh rate 60 Hz
Haze rate 2%
RGB colour space NTSC
Ports & interfaces
HDMI ports quantity 3
HDMI version 2.0
HDMI input ports quantity 3
DVI port No
USB port Yes
USB ports quantity 2
Ethernet LAN Yes
Ethernet LAN (RJ-45) ports 1
Wi-Fi No
RS-232 interface Yes
Remote (IR) input 1
PC Audio out Yes
Audio
Built-in speaker(s) No
Design
Product design Digital signage flat panel
Placement supported Indoor
Screen shape Flat
VESA mounting Yes
Panel mounting interface 400 x 400 mm
Bezel width (bottom) 1.34 cm
Bezel width (side) 1.34 cm
Bezel width (top) 1.34 cm
Mounting type Wall
Performance
Purpose Commercial
Operating hours (hours/days) 16/7
HDCP Yes
HDCP version 2.2
Power
Power consumption (typical) 214.5 W
Power consumption (standby) 0.5 W
AC input voltage 100 – 240 V
AC input frequency 50/60 Hz
Computer system
Built-in processor Yes
Internal memory 8 GB
Operating system installed Tizen 7.0
Video formats supported HEVC/H.265
Weight & dimensions
Display width 1682.3 mm
Display depth 28.5 mm
Display height 960.4 mm
Display weight 33.4 kg
Packaging data
Package width 1839 mm
Package depth 180 mm
Package height 1113 mm
Package weight 43.5 kg
Packaging content
Remote control included Yes
Batteries included Yes
Cables included AC, RS-232, USB
Mounting kit Yes
Operational conditions
Operating temperature (T-T) 0 – 40 °C
Operating relative humidity (H-H) 10 – 80%
Storage temperature (T-T) -20 – 45 °C
Storage relative humidity (H-H) 5 – 95%
Technical details
Sustainability compliance Yes
Sustainability certificates ENERGY STAR, EPEAT, TÜV mark
Processor Quantum Lite 4K Processor
Other features
Sound modes Dolby Audio
On/off switch Yes
