PROJECTION SYSTEM
-
- Projection System
- DLP
NATIVE RESOLUTION
-
- Native Resolution
- 4K UHD (3840 x 2160)
BRIGHTNESS(ANSI LUMEN)
-
- Brightness (ANSI Lumen)
- 5000
CONTRAST RATIO
-
- Contrast Ratio
- 3,000,000:1 ↑
NOISE
-
- Energy Saving Min. (Bright)
- 29 dB(A)
- Energy Saving Med.
- 27 dB(A)
-
- Energy Saving Max. (Eco)
- 26 dB(A)
UNIFORMITY
-
- Uniformity (JBMMA 9 Point)
- 85%
PROJECTION LENS
-
- Focus (Auto / Manual)
- Manual
- Zoom
- 1.2x
PROJECTION IMAGE
-
- Screen Size
- 40" ~ 300"
- Standard (lens to wall)
- Wide 2017 /Tele 2454 (100")
-
- Throw Ratio
- 0.94 - 1.14
LENS SHIFT
-
- Lens Shift
- Yes ( Horiz ± 20% / Vert ± 50% )
LIGHT SOURCE
-
- Type
- Laser (LD + P/W)
- Life Hours
- 20,000 Hrs
LANGUAGE
-
- OSD Languages
- English / Korean
ASPECT RATIO
-
- Aspect Ratio Control
- 16:9/Original/4:3/Vertical Zoom/All-Direction Zoom
SOUND
-
- Output
- 10W (5W+5W)
SIZE
-
- Net Size (mm) (W x D x H)
- 370x290x155.7, 370x290x143.7 (Without Leg)
WEIGHT
-
- Net Weight (kg or g)
- 9.7Kg
POWER
-
- Power Consumption (Max.)
- 380W
- Stand-by Power
- 0.5W↓
-
- Power Supply
- 100V – 240V @ 50~60 Hz (PSU Built-in)
TEMPERATURE
-
- Operation Temperature
- 0 ~ 40℃
INPUT SIGNAL COMPATIBILITY
-
- Digital(HDMI)
- Up to 4K (4096x2160) (60Hz, 50Hz, 24Hz)
INPUT/OUTPUT TERMINALS
-
- Audio out
- Yes
- RS-232C
- Yes
-
- IP control
- Yes
- RJ45
- 1
-
- HDMI
- 2
- HDBaseT
- Yes
-
- USB Type-A
- 2 (USB2.0)
FEATURES
-
- Platform (OS, UI)
- webOS 4.5
- Internet Browser
- Yes
-
- Screen Share (Wireless Mirroring with MiraCast supporting device)
- Yes
- Wireless Contents Share (with Android, iOS)
- Yes (Android Only)
-
- Contents Sharing (with DLNA supporting device)
- Yes
- Bluetooth Sound out
- Yes
-
- Bluetooth AV Sync Control
- Yes
- LG Sound Sync(with Sound Bar)
- Yes
-
- HDMI ARC(Audio Return Channel)
- Yes
- Plug & Play(RGB/DVI/HDMI Auto Source Detection)
- Yes
-
- USB Host (Movie, Music, Photo)
- Yes
- File(Office) Viewer
- Yes
-
- Setting Guide
- Yes (Bean Bird)
- HID (Keyboard/Mouse/GamePad Connection Thru USB)
- Yes
-
- HDR
- HDR10
- HDR Effect
- Yes
-
- DICOM
- Yes
- TruMotion
- Yes
-
- Digital Keystone Correction
- Warping
- Image Flip
- Yes (Horizontal/Vertical)
-
- Black Level Control
- Yes
- Noise Reduction
- Yes
-
- Quick(Instant) Power on/off
- Yes (on 12 Sec off 2 Sec)
- Self Diagnosis
- Yes
DESIGN
-
- Cabinet Color
- Top/Bottom - White Front/Rear - Black
- Local Key
- Joystick
-
- Kensington Lock
- Yes
- Leg-Stand
- Yes (4 Leg)
-
- Ceiling mount hole (for bracket)
- Yes
1 year Warranty
