Screen Size (Diagonal) 75″
Resolution 3840 x 2160
Brightness 500 cd/m²
Viewing Angle (H x V) 178 x 178°
Screen Area 64.9 x 36.5″ / 1649.6 x 927.9 mm
Aspect Ratio 16:9
Contrast Ratio 1200:1
Response Time 8 ms (GtG)
Primary Connectivity Location Display
Input Ports 3 x HDMI Audio, Video 1 x DisplayPort Audio, Video 1 x DVI-D Video 1 x VGA 15-Pin 2 x 1/8″ / 3.5 mm Audio
Output Ports 1 x HDMI – Audio, Video 1 x 1/8″ / 3.5 mm – Audio
USB Ports 1 x USB 3.0 / 3.1/3.2 Gen 1, USB-A (Rear) 2 x USB 2.0, USB-A (Front) 1 x Unspecified USB, USB-B
Ethernet Ports 1
Control I/O RS-232C via DE-9/DB-9 Input
Number of OPS/Expansion Slots 1
Display Orientation Landscape, Portrait
HDCP Support Yes, Version 2.2
Touchscreen Technology Infrared (IR)
Multi-Touch Points 20
Surface Treatment Anti-Glare
Built-In Speakers Yes, 2 x 10 W
Speaker Configuration 2-Channel
External Speaker Output 2 x 15 W
OS Compatibility Windows macOS *As of January, 2022: Check with manufacturer for the most up-to-date compatibility
Power Consumption Typical: 278.0 W Maximum: 363.0 W Standby: 0.5 W
AC Input Power 110 to 240 VAC, 50 / 60 Hz
Wall Mounting 600 x 400 mm
Bezel Thickness 16.3 mm (Right/Top/Left) 54.3 mm (Bottom)
Duty Cycle 18 Hours
Dimensions 67.6 x 40.6 x 4.2″ / 1716.0 x 1032.0 x 107.0 mm
Weight 124.8 lb / 56.6 kg
Screen Size (Diagonal) 75″ Resolution 3840 x 2160 Brightness 500 cd/m² Viewing Angle (H x V) 178 x 178° Screen Area 64.9 x 36.5″ / 1649.6 x 927.9 mm
Contrast Ratio 1200:1 Response Time 8 ms (GtG) Connectivity
3 x HDMI Audio, Video
1 x DisplayPort Audio, Video 1 x DVI-D Video 1 x VGA 15-Pin 2 x 1/8″ / 3.5 mm Audio
1 x HDMI Audio, Video
1 x USB 3.0 / 3.1/3.2 Gen 1, USB-A (Rear)
2 x USB 2.0, USB-A (Front)
1 x Unspecified USB, USB-B
USB Ports Ethernet Ports 1 Control I/O RS-232C via DE-9/DB-9 Input
USB Ports Number of OPS/Expansion Slots 1 General Display Orientation Landscape, Portrait HDCP Support Yes, Version 2.2 Surface Touchscreen Technology Infrared (IR) Multi-Touch Points 20 Surface Treatment Anti-Glare Audio Built-In Speakers Yes, 2 x 10 W Speaker Configuration 2-Channel External Speaker Output 2 x 15 W Hardware OS Compatibility Windows macOS
USB Ports *As of January, 2022: Check with manufacturer for the most up-to-date compatibility Electrical
Power Consumption Typical 278.0 W
Power Consumption Maximum 363.0 W
Power Consumption Standby 0.5 W
Power Consumption AC Input Power 110 to 240 VAC, 50 / 60 Hz Physical Wall Mounting 600 x 400 mm Bezel Thickness 16.3 mm (Right/Top/Left) 54.3 mm (Bottom) Duty Cycle 18 Hours Dimensions 67.6 x 40.6 x 4.2″ / 1716.0 x 1032.0 x 107.0 mm Weight 124.8 lb / 56.6 kg
SKU TH-75BQ1W
