Screen size (diagonal) (inch) 64.5-inch (1638.9 mm)
Screen size (diagonal) (mm) 64.5-inch (1638.9 mm)
Aspect Ratio 16:9
Effective display area (W x H) (mm) 1428.4 x 803.5 mm(56.23″ x 31.63″)
Effective display area (W x H) (inch) 1428.4 x 803.5 mm(56.23″ x 31.63″)
Resolution 3840 x 2160
Contrast Ratio 1200 : 1
Response Time 8.0 ms (G to G)
Viewing angle [(T/B)/(L/R)] 178°/178° (CR>10)
Panel Surface Treatment Anti-glare type (Haze 25%)
Terminals | HDMI IN TYPE A Connector x 3 (HDCP2.2 supported)
Terminals | PC IN/AUDIO IN (L/R) Mini D-sub 15-pin x 1 (Female)/Stereo Mini Jack (M3) x 1
Terminals | Serial D-sub 9-pin x 1, RS232C Compatible
Terminals | AUDIO OUT Stereo Mini Jack (M3) x 1
Terminals | LAN RJ45 x 1, RJ45 10BASE-T/100BASE-TX
Terminals | USB Type ADC 5 V/1 A (USB 3.0 is supported),Type ADC 5 V/2 A (USB 2.0 is supported (TBD)),Type C (USB2.0 is supported), DP Alt mode compatible (TBD)
Terminals | Slot SDM-S / SDM-L, 3.3 V/max.1.1 A, 12 V/max 5.5 A
Built-in Speaker 20W [10 W + 10 W]
Power Requirements AC 110 – 240 V 50 Hz / 60 Hz
Power consumption TBD
Power Off Condition Approx. 0.3 W
Standby Condition Approx. 0.5 W
Dimensions (W x H x D) (mm) 1463 x 838 x 69 mm(57.58″ x 32.97″ x 2.72″) (TBD)*Not including handles.
Dimensions (W x H x D) (inch) 1463 x 838 x 69 mm(57.58″ x 32.97″ x 2.72″) (TBD)*Not including handles.
Weight (kg) 29 kg (63.9 lbs.)
Bezel width (mm) 14.9 mm (0.59″) (T/R/L/B)
Bezel width (inch) 14.9 mm (0.59″) (T/R/L/B)
Wall-hanging pitch (mm) VESA Compliant 400 x 400 mm(15.8″ x 15.8″), M8
Wall-hanging pitch (inch) VESA Compliant 400 x 400 mm(15.8″ x 15.8″), M8
Orientation Landscape/Portrait
Tilting angle 0 – 20 degrees forward/backward with landscape/portrait setting
Operating Time 18 h/day
Operating environment Temperature: 0 °C to 40 °C (32 °F to 104 °F)/Humidity: 20-80 % (Non condensation)/for up to 0-1400 m (4593 ft) attitude.Temperature: 0 °C to 35 °C (32 °F to 95 °F)/Altitude 1400-2800 m (4593 ft to 9186 ft)
Increased input type and number of available inputs
Higher visibility due brightness typically found on higher end products
Installation flexibility portrait and tilt supported
Screen size (diagonal) (inch) 64.5-inch (1638.9 mm), (diagonal) (mm) 64.5-inch (1638.9 mm)
Brightness (typ.) 500 cd/m2
Contrast Ratio 1200 : 1 Response Time 8.0 ms (G to G) Viewing angle [(T/B)/(L/R)] 178°/178° (CR>10) Panel Surface Treatment
Anti-glare type (Haze 25%)
Terminals | HDMI IN
TYPE A Connector x 3 (HDCP2.2 supported)
Terminals | PC IN/AUDIO IN (L/R)
Terminals | AUDIO OUT Stereo Mini Jack (M3) x 1 Terminals | LAN
Type ADC 5 V/1 A (USB 3.0 is supported),Type ADC 5 V/2 A (USB 2.0 is supported (TBD)),Type C (USB2.0 is supported), DP Alt mode compatible (TBD) Terminals | Slot
Power Requirements AC 110 240 V 50 Hz / 60 Hz
Power Requirements Power consumption TBD
Power Requirements Power Off Condition Approx. 0.3 W Standby Condition Approx. 0.5 W
Power Requirements Dimensions (W x H x D) (mm) 1463 x 838 x 69 mm(57.58″ x 32.97″ x 2.72″) (TBD)*Not including handles., (W x H x D) (inch) 1463 x 838 x 69 mm(57.58″ x 32.97″ x 2.72″) (TBD)*Not including handles.
Power Requirements Weight (kg) 29 kg (63.9 lbs.), (lbs.) 29 kg (63.9 lbs.) Bezel width (mm) 14.9 mm (0.59″) (T/R/L/B) Bezel width (inch) 14.9 mm (0.59″) (T/R/L/B) Wall-hanging pitch (mm)
Power Requirements VESA Compliant 400 x 400 mm(15.8″ x 15.8″), M8 Wall-hanging pitch (inch), Compliant 400 x 400 mm(15.8″ x 15.8″), M8 Orientation Landscape/Portrait Tilting angle 0 – 20 degrees forward/backward with landscape/portrait setting
Power Requirements Operating Time 18 h/day, environment
Power Requirements Temperature 0 °C to 40 °C (32 °F to 104 °F)/Humidity: 20-80 % (Non condensation)/for up to 0-1400 m (4593 ft) attitude.Temperature: 0 °C to 35 °C (32 °F to 95 °F)/Altitude 1400-2800 m (4593 ft to 9186 ft)
SKU TH-65EQ2W
