Screen size (diagonal) (inch) 49.5-inch (1257.3 mm)
Screen size (diagonal) (mm) 49.5-inch (1257.3 mm)
Aspect Ratio 16:9
Effective display area (W x H) (mm) 1095.8 x 616.4 mm(43.14″ x 24.26″)
Effective display area (W x H) (inch) 1095.8 x 616.4 mm(43.14″ x 24.26″)
Resolution 3840 x 2160
Contrast Ratio 5000:1
Response Time 9.5 ms (G to G)
Viewing angle [(T/B)/(L/R)] 178 /178 (CR>10)
Panel Surface Treatment Anti-glare type (Haze 25%)
Terminals | HDMI IN TYPE A Connector x 3 (HDCP2.2 supported)
Terminals | PC IN/AUDIO IN (L/R) Mini D-sub 15-pin x 1 (Female)/Stereo Mini Jack (M3) x 1
Terminals | Serial D-sub 9-pin x 1, RS232C Compatible
Terminals | AUDIO OUT Stereo Mini Jack (M3) x 1
Terminals | LAN RJ45 x 1, RJ45 10BASE-T/100BASE-TX
Terminals | USB Type ADC 5 V/1 A (USB 3.0 is supported),Type ADC 5 V/2 A (USB 2.0 is supported (TBD)),Type C (USB2.0 is supported), DP Alt mode compatible (TBD)
Terminals | Slot SDM-S / SDM-L, 3.3 V/max.1.1 A, 12 V/max 5.5 A
Built-in Speaker 20W [10 W + 10 W]
Power Requirements AC 110 – 240 V 50 Hz / 60 Hz
Power consumption TBD
Power Off Condition Approx. 0.3 W
Standby Condition Approx. 0.5 W
Dimensions (W x H x D) (mm) 1129 x 649 x 66* mm(44.43″ x 25.56″ x 2.60″*) (TBD)*Not including handles.
Dimensions (W x H x D) (inch) 1129 x 649 x 66* mm(44.43″ x 25.56″ x 2.60″*) (TBD)*Not including handles.
Weight (kg) 16 kg (34 lbs.) (TBD)
Bezel width (mm) 14.9 mm (0.59″) (T/R/L/B)
Bezel width (inch) 14.9 mm (0.59″) (T/R/L/B)
Wall-hanging pitch (mm) VESA Compliant 400 x 400 mm(15.8″ x 15.8″), M6
Wall-hanging pitch (inch) VESA Compliant 400 x 400 mm(15.8″ x 15.8″), M6
Orientation Landscape/Portrait
Tilting angle 0 – 20 degrees forward/backward with landscape/portrait setting
Operating Time 18 h/day
Operating environment Temperature: 0 C to 40 C (32 F to 104 F)/Humidity: 20-80 % (Non condensation)/for up to 0-1400 m (4593 ft) attitude.Temperature: 0 C to 35 C (32 F to 95 F)/Altitude 1400-2800 m (4593 ft to 9186 ft)
16 9
5000 1
Temperature 0 C to 40 C (32 F to 104 F)/Humidity: 20-80 % (Non condensation)/for up to 0-1400 m (4593 ft) attitude.Temperature: 0 C to 35 C (32 F to 95 F)/Altitude 1400-2800 m (4593 ft to 9186 ft)
Increased input type and number of available inputs
Higher visibility due brightness typically found on higher end products
Screen size (diagonal) (mm) 49.5-inch (1257.3 mm)
Brightness (typ.) 500 cd/m2
Contrast Ratio 5000:1 Response Time 9.5 ms (G to G) Viewing angle [(T/B)/(L/R)] 178 /178 (CR>10) Panel Surface Treatment
Anti-glare type (Haze 25%)
Terminals | HDMI IN
TYPE A Connector x 3 (HDCP2.2 supported)
Terminals | PC IN/AUDIO IN (L/R)
Terminals | AUDIO OUT Stereo Mini Jack (M3) x 1 Terminals | LAN
Type ADC 5 V/1 A (USB 3.0 is supported),Type ADC 5 V/2 A (USB 2.0 is supported (TBD)),Type C (USB2.0 is supported), DP Alt mode compatible (TBD) Terminals | Slot
Power Requirements AC 110 240 V 50 Hz / 60 Hz
Power Requirements Power consumption TBD
Power Requirements Power Off Condition Approx. 0.3 W Standby Condition Approx. 0.5 W
Power Requirements Dimensions (W x H x D) (mm) 1129 x 649 x 66* mm(44.43″ x 25.56″ x 2.60″*) (TBD)*Not including handles., (W x H x D) (inch) 1129 x 649 x 66* mm(44.43″ x 25.56″ x 2.60″*) (TBD)*Not including handles.
Power Requirements Weight (kg) 16 kg (34 lbs.) (TBD), (lbs.) 16 kg (34 lbs.) (TBD) Bezel width (mm) 14.9 mm (0.59″) (T/R/L/B) Bezel width (inch) 14.9 mm (0.59″) (T/R/L/B) Wall-hanging pitch (mm)
Power Requirements VESA Compliant 400 x 400 mm(15.8″ x 15.8″), M6 Wall-hanging pitch (inch), Compliant 400 x 400 mm(15.8″ x 15.8″), M6 Orientation Landscape/Portrait Tilting angle 0 – 20 degrees forward/backward with landscape/portrait setting
Power Requirements Operating Time 18 h/day, environment
Power Requirements Temperature 0 C to 40 C (32 F to 104 F)/Humidity: 20-80 % (Non condensation)/for up to 0-1400 m (4593 ft) attitude.Temperature: 0 C to 35 C (32 F to 95 F)/Altitude 1400-2800 m (4593 ft to 9186 ft)
SKU TH-50EQ2W
