Panasonic PT-MZ670LU WUXGA 1080p LCD Projector with Speaker

(No reviews yet) Write a Review
Free Shipping
  • Panasonic PT MZ670LU WUXGA 1080p LCD Projector with Speaker
  • Panasonic PT MZ670LU WUXGA 1080p LCD Projector with Speaker
  • Panasonic PT MZ670LU WUXGA 1080p LCD Projector with Speaker
  • Panasonic PT MZ670LU WUXGA 1080p LCD Projector with Speaker
  • Panasonic PT MZ670LU WUXGA 1080p LCD Projector with Speaker
Frequently bought together:


Panasonic MZ670U Overview

Enjoy bright images in most everyday settings with the Panasonic PT-MZ670U 6500-Lumen WUXGA 3LCD Projector. Its 6500 lumens of brightness and 3,000,000:1 dynamic contrast ratio will work together to overcome light in moderately bright rooms and provide detail in dark areas of the image. It sports a 1920 x 1200 WUXGA native resolution for viewing detailed video, pictures, or data. The projector's 1.7 to 2.8:1 throw ratio offers a range of throw distances for focused images.

The PT-MZ670U features 5BNC, VGA, RCA, and two HDMI inputs to connect to nearly any device. Its analog audio input and output will allow you to pass sound through the projector to your sound system of choice, and the VGA input output enables daisy-chaining of multiple projectors or displays. The projector is controllable via the included wireless/wired remote control, Ethernet, RS-232, or DIGITAL LINK with various control software options.

Key Features

  • Brightness of 6500 Lumens
  • WUXGA (1920 x 1200) Native Resolution
  • 1.7 to 2.8:1 Throw Ratio
  • 5BNC, VGA, RCA, 2 x HDMI Inputs
  • VGA Output for Loop-Through
  • Analog Audio Input and Output
  • Integrated 10-Watt Speaker
  • DIGITAL LINK Control & A/V Capability
  • Ethernet & RS-232 Controllable
  • Wireless/Wired Remote Included

Picture Quality Features

  • SOLID SHINE laser phosphor drive with 3LCD optical engine helps provide bright, vivid, detailed images
  • Brightness of up to 6500 lumens
  • Dynamic contrast ratio of 3,000,000:1 helps ensure legible text and enhanced picture quality thanks to the laser light source and WUXGA native resolution
  • Detail Clarity Processor 4 helps enhance image clarity and sharpness
  • Daylight view basic helps provide clear and crisp images in bright environments
  • DICOM Simulation Mode for medical presentations
  • Color adjustment function corrects color variations in multiple-projection

Low Maintenance & ECO Features

  • Continuous operational period for the laser light source up to 20,000 hours
  • Inorganic LCD panel and polarizing plate help maintain image quality over time
  • Estimated maintenance time for the reusable filter is up to 20,000 hours
  • One-way airflow design enhances lens assembly sealing to reduce dust intrusion
  • Dust-resistant cabinet improves sealing of filter module and air-intake duct
  • ECO management system designed to help reduce power consumption

System Flexibility Features

  • DIGITAL LINK supports transmission of uncompressed Full HD video, audio, and control commands over a single CAT 5e or higher STP cable for distances up to 492'
  • Powered lens shift, zoom, and focus via the included remote control
  • Corner keystone and curved screen correction
  • 360° projector cabinet rotation
  • Various lens options to suit multiple rooms and applications
  • Network function via LAN for remote operation
  • Supports multi-monitoring and free control software
  • Wireless projection possible with the optional ET-WM300 wireless adapter

Panasonic MZ670U Specs

Image Display

Display System 3-Chip 0.76" LCD
Native Chip Resolution 1920 x 1200 (WUXGA)
Maximum Brightness 6500 Lumens
Uniformity 90%
Aspect Ratio Native: 16:10
Dynamic Contrast Ratio 3,000,000:1
Color Depth 8-Bit (16.78 Million Colors)
Scan Horizontal: 15 to 91 kHz
Vertical: 24 to 100 Hz


Focus Manual Powered
Lens f/1.7 - 2.3 (f = 26.9 - 45.5 mm)
Lens Shift Vertical: ± 67%
Horizontal: ± 35%
Optical Zoom Powered: 1.69x
Throw Ratio 1.7 to 2.8:1
Projection Size 40 - 400" / 1.02 - 10.16 m


Keystone Correction Vertical: ± 30°
Horizontal: ± 25°
Ceiling Mountable Yes
Built-In Speaker Yes (Mono)
Speaker Power 10W
Projection Tilt Option Yes

Input/Output Connectors

Inputs/Outputs 2 x HDMI (HDMI Type-A) Audio, Video Input
1 x 5BNC Video Input
1 x HDBaseT (RJ45) Audio, Control, Data, LAN, Service, Video Input
1 x Composite (RCA) Video Input
1 x VGA (DE-15/DB-15) Video Input
1 x VGA (DE-15/DB-15) Video Output
1 x 2RCA Audio Input
2 x 1/8" / 3.5 mm Mini Audio Input
1 x 1/8" / 3.5 mm Mini Audio Output
1 x RS-232 (DE-9/DB-9) Control Input
1 x DE-9/DB-9 Control Input
1 x 1/8" / 3.5 mm Mini Control Input
1 x Ethernet (RJ45) LAN Input
1 x USB 2.0 (USB Type-A) Audio, Data, Video Input
1 x USB 2.0 (USB Type-A) Power Output
Memory Card Slot None
Wireless LAN / Wi-Fi No, Optional Adapter Available


Light Source Laser Phosphor
Expected Lamp Life Medium Brightness: 20,000 Hours
Fan Noise Full Brightness: 33 dB
Low Brightness: 28 dB
Security None
AC Input Power 100 to 240 VAC, 50 / 60 Hz
Power Consumption Full Brightness: 415 W
Standby Mode (Lamp Off): 22 W
Low Brightness: 0.5 W
Dimensions (W x H x D) 22.0 x 8.1 x 17.4" / 560.0 x 205.0 x 443.2 mm With included lens
Weight 35.3 lb / 16.0 kg Approximate

Packaging Info

Package Weight 50 lb
Box Dimensions (LxWxH) 30 x 22 x 14"
View AllClose

Warranty Information

1 Year Parts & Labor Manufacture Warranty
