Product Overview
Quickly and easily grow your network to support IP security cameras, access points, VoIP phones, and other PoE-compatible devices with the GS305PP 5-Port Gigabit PoE+ Compliant Unmanaged Network Switch from NETGEAR. Four out of the five Gigabit-speed Ethernet ports support up to 30W of PoE+ each with a total budget of 83W.
Shipping charges and warranty coverage vary by product and order. Review the applicable terms before purchase.
Ready to ship
Rates and available methods are shown at checkout
Key Features
Quickly and easily grow your network to support IP security cameras, access points, VoIP phones, and other PoE-compatible devices with the GS305PP 5-Port Gigabit PoE+ Compliant Unmanaged Network Switch from NETGEAR. Four out of the five Gigabit-speed Ethernet ports support up to 30W of PoE+ each with a total budget of 83W.
Simply connect this switch to your network to get started. No complex setup or configuration is required. With a 10 Gb/s switching capacity, 1.448 Mpps forwarding rate, a 128KB memory buffer, and 9216 byte jumbo frames, the GS305PP delivers fast and reliable data transfers. The fanless design allows the switch to operate silently in the background of your office.
PoE Power Auto-Balance & Allocation
The GS305PP automatically balances the PoE power level on each port, depending on the device needs.
Energy Efficient
This switch is designed to optimize power usage and for low operating costs.
Versatile Mount
This device supports desktop placement or wall mounting using the included kit.
Silent Operation
The fanless design means zero added noise wherever its located, making it ideal for noise-sensitive environments.
| Inputs/Outputs |
1x RJ45 Gigabit Ethernet 4x RJ45 Gigabit Ethernet PoE+ (30 W, 802.3at) |
| Stackable | No |
| Switching Bandwidth | 10 Gb/s |
| PoE Power Budget | 83 W |
| Stackable | No |
Protocols
| Supported Protocols | Auto-MDIX/MDI |
| Queuing | Weighted Round Robin (WRR) |
| Jumbo Frames Support | 9216 Bytes |
| MAC Address Table Size | 2K |
Performance
| Latency | 2.4 µs |
| Forwarding Rate | 1.44 Mpps |
| Switching Bandwidth | 10 Gb/s |
| Packet Buffer | 128 kB |
Electrical
| PoE per Port | 30 W |
| PoE Power Budget | 83 W |
| Power Draw |
88.89 W (Max) 2.89 W (Standby) |
| Input Power | 54 VDC at 1.66 A |
| Power Supply Type | External |
Environmental
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 90% |
| Storage Temperature | -4 to 158°F / -20 to 70°C |
| Storage Humidity | 95% |
| Noise Level | 0.0 dB |
General
| Certifications | CE, FCC, RCM, CCC, VCCI, KC |
| Cooling System | Passive |
| Mean Time Between Failures (MTBF) | 6.19 Million Hours |
| Material of Construction | Metal |
| Indicator Lights | Yes |
| Rack Mountable | No |
| Dimensions | 6.2 x 4 x 1.1″ / 158 x 101 x 29 mm |
| Weight | 0.9 lb / 0.41 kg |
Packaging Info
| Package Weight | 2.455 lb |
| Box Dimensions (LxWxH) | 10.2 x 6.7 x 3.3″ |
