Key Features

Refreshed, simplified user interface
Layer 2/Layer 3 capabilities (static routing included)
Multicast/IGMP snooping and querying feature
Per port unregistered flooding
130W Total power budget
Dante and AES67 compatibility
AV-Over-IP Compatible
PoE Monitoring; Auto-Recovery and Power Scheduling

Product Overview

Use the SW-505-8P-F to provide 12-Port of network connectivity and PoE+ power in commercial or residential applications. This 12-Port, fanless switch includes 8 Gigabit PoE+ Ethernet ports, 2 non-PoE Ethernet ports, and 2 Gigabit SFP expansion ports. Designed to support AV-over-IP (AVoIP) applications, the SW-505-8P-F includes eight 1-Gigabit PoE+ Ethernet ports, two non-PoE Ethernet Ports, and two 1-Gigabit SFP expansion ports. Both 1 Gb SFP ports can be aggregated for a connection speed of up to 2 Gb. The 8 PoE+ ports deliver both gigabit data and power over a single cable to 802.11af/at-compliant devices, with a maximum of 30W per port. For separately powered devices, these ports deliver network connectivity only. The total power budget is 130W for all PoE+ ports combined. The advanced Layer 2/Layer 3 features and easy-to-use management interface simplify configuration and make this switch ideal for use in single-switch AVoIP environments. Setup of IGMP/Multicast on a per-port basis is easy, improving the setup and reliability of running audio and video over the network simultaneously. This model also features a small form factor and fanless design that is perfect for conference rooms, offices, theaters, or wherever silent operation is needed.

Main Features

  • Refreshed, simplified user interface
  • Layer 2/Layer 3 capabilities (static routing included)
  • Multicast/IGMP snooping and querying feature
  • Per port unregistered flooding
  • 130W Total power budget
  • Dante and AES67 compatibility
  • AV-Over-IP Compatible
  • PoE Monitoring; Auto-Recovery and Power Scheduling
  • Easy port aggregation; 1G SFP ports can be aggregated for a 2G connection
  • 802.1Q VLAN And QoS support including DCSP

General Information

Name: Luxul SW-505-8P-F 12-Port 1Gb L2/L3 Managed Switch, US Powercord
Category: Luxul by Legrand, Data Comm & Networking, Hubs, Routers & Switches, Network Switches
UPC Code: 655003923483
General Information:



The SW-505-8P-F provides 12 ports of network connectivity and PoE+ power in commercial or residential applications designed to support AV-over-IP (AVoIP) applications. This 12-port, fanless switch includes 8 1 Gbps PoE+ Ethernet ports, 2 non-PoE Ethernet ports, and 2 – 1 Gbps SFP expansion ports.
Manufacturer Legrand Group
Manufacturer Part Number SW-505-8P-F
Manufacturer Website Address http://www.legrand.us
Brand Name Luxul
Product Model SW-505-8P-F
Product Name 12-Port L2/L3 Managed Switch – 8 PoE+ Gigabit Front Facing Ports
Product Type Ethernet Switch
  Product UPC 655003923483
Technical Information:
Features Fanless
Interfaces/Ports:
Total Number of Network Ports 8
Network (RJ-45) Yes
Modular Yes
Port/Expansion Slot Details 8 x Gigabit Ethenet PoE+
2 x Gigabit Ethenet Network
2 x Gigabit Ethenet Expansion Slot
Media & Performance:
Media Type Supported Twisted Pair
Optical Fiber
Ethernet Technology Gigabit Ethernet
Network Technology 1000Base-T
1000Base-X
I/O Expansions:
Total Number of Expansion Slots 2.0
Expansion Slot Type SFP (mini-GBIC)
Number of SFP Slots 2
Network & Communication:
Layer Supported 3
Management & Protocols:
Manageable Yes
Power Description:
PoE (RJ-45) Port Yes
Power Source PoE+
NETWORK SWITCH SKU SW-505-8P-F

Luxul SW-505-8P-F 12-Port 1Gb L2/L3 Managed Switch, US Powercord

Free Shipping on All Orders Warranty Included

Product Overview

Product Overview Use the SW-505-8P-F to provide 12-Port of network connectivity and PoE+ power in commercial or residential applications. This 12-Port, fanless switch includes 8 Gigabit PoE+ Ethernet ports, 2 non-PoE Ethernet ports, and 2 Gigabit SFP expansion ports.
