8" 2-way Pendent Mount PoE+ Speaker - Black

Ideal Use Cases

The AtlasIED IP-PM8GD-B is specifically designed for environments that demand seamless paging and network integration in open-ceiling layouts. Ideal locations include educational institutions, retail spaces, and corporate buildings where aesthetic and performance meet. Thanks to its pendant mount, it fits perfectly into spaces where ceiling installations are preferred for optimal sound distribution.

Why Choose This Model

This model stands out due to its comprehensive integration of audio and network capabilities. Featuring an 8-inch, 2-way coaxial speaker, it offers a reliable solution that combines loudspeaker functionality with an integrated amplifier capable of delivering up to 15 watts with 802.3at PoE+ power. The RJ-45 connectivity and HTTP GUI for static configuration ensure easy network management, making this model a robust choice for both technical and aesthetic considerations.

Installation and Integration

Installation is straightforward with the RJ-45 connector facilitating network connections. The product’s dimensions, 16.62 inches in height and 12.25 inches in width, alongside a manageable weight of 12.5 pounds, allow for easy installation and maintenance. These physical features are complemented by a safety listing to UL 62368, ensuring compliance with safety standards. The flexible PoE options—9 watts with 802.3af and 15 watts with 802.3at—allow for versatile power management tailored to specific network capabilities.

Performance Highlights

The IP-PM8GD-B delivers a frequency response from 86Hz to 15.5kHz, ensuring clear audio across a wide range. Its 105-degree dispersion pattern, effective from 800Hz to 4kHz, allows for broad sound coverage, making it suitable for large open areas. With a sensitivity of 106dB, it ensures that audio output remains robust and clear, even at lower power levels. The integrated amplifier’s capability to adjust output based on the PoE standard further enhances its adaptability.

What Makes It Different

What truly sets the IP-PM8GD-B apart is its dual PoE compatibility, offering two distinct power outputs and a user-friendly HTTP GUI for configuration. This model not only provides high-quality audio but also ensures ease of integration into existing network infrastructures. The pendant mount design is particularly beneficial in maintaining clear sound paths in open-ceiling environments, a feature not commonly found in competing models.

Final Assessment

The AtlasIED IP-PM8GD-B is a compelling choice for those seeking a network-connected speaker with the versatility of PoE+ capabilities. Its robust design, coupled with high-performance audio specifications and straightforward installation process, positions it as a leading option for open-ceiling installations. Whether for educational, commercial, or corporate settings, this speaker offers a blend of performance, reliability, and aesthetic integration.
