8″ 2-way High Output Pendent Speaker with 60-Watt 70V Transformer –

The AtlasIED PM8CX-B is a white, high-output 8-inch 2-way pendant loudspeaker designed for paging and background music in spaces with very high ceilings. Its compression-driver coaxial configuration combines a 60-watt, 70V transformer with an 8-ohm operating option. The specified 92dB average sensitivity, 55Hz to 15kHz frequency response, and 90-degree dispersion provide concrete performance parameters for planning a distributed audio installation.

Ideal Use Cases

This model is intended for installations where loudspeakers must be suspended from very high ceilings. It supports both spoken paging and background music, allowing one loudspeaker type to serve systems that need announcements as well as routine music playback. Its pendant-mount format makes it relevant when the ceiling height or room configuration calls for the loudspeaker to be positioned below the overhead structure rather than installed directly into it.

The 90-degree dispersion specification gives system designers a defined coverage value when planning loudspeaker positions. This is especially useful when multiple speakers must be arranged across a high-ceiling space and coverage needs to be considered before transformer settings and amplifier requirements are finalized.

Why Choose This Model

The PM8CX-B combines a coaxial loudspeaker design, multiple transformer power settings, and 8-ohm capability in one model. Its listed settings are 7.5, 15, 30, and 60 watts, along with 8-ohm operation. This range provides several stated configuration choices instead of limiting the speaker to a single transformer setting.

For an 8-ohm configuration, the specified RMS power rating is 150 watts. For a 70V installation, the integrated transformer is rated at 60 watts. These published values allow the model to be evaluated for either of its stated operating approaches without relying on unspecified performance figures.

Installation and Integration

The loudspeaker is designed for pendant mounting and incorporates a 70V transformer. During system planning, the selected 7.5W, 15W, 30W, or 60W setting can be matched to the intended 70V system design. The listed 8-ohm option also enables integration where an 8-ohm loudspeaker load is required.

Because this model is specifically identified for very high-ceiling installations, placement should be planned around its pendant format and 90-degree dispersion. Amplifier selection and system loading should be based on the chosen operating mode, the listed transformer setting, and the number of loudspeakers in the installation. The supplied data does not specify dimensions, weight, connection type, or included mounting components.

Performance Highlights

• Speaker configuration: 8-inch, 2-way compression-driver coaxial loudspeaker.
• Sensitivity: 92dB average.
• Frequency response: 55Hz to 15kHz.
• Dispersion: 90 degrees.
• 70V transformer: 60-watt rating with 7.5W, 15W, 30W, and 60W settings.
• Low-impedance operation: 8-ohm capability with a specified 150-watt RMS rating.
• Finish: White.

Together, these specifications define the model’s core audio behavior. The frequency-response range identifies its stated playback bandwidth, while the sensitivity and dispersion ratings provide additional reference points for comparing it with other loudspeakers intended for elevated mounting positions.

What Makes It Different

The defining combination is its high-output 8-inch 2-way coaxial design, pendant mounting, and support for both a tapped 70V transformer and 8-ohm operation. It is not presented solely as a paging speaker or solely as a background-music speaker; the stated application includes both. The four listed 70V power settings also provide configuration flexibility within the transformer’s 60-watt rating.

Its published 150-watt RMS rating at 8 ohms further distinguishes the low-impedance operating specification from the transformer settings. The white finish provides the stated appearance for installations where that color is required.

Final Assessment

The AtlasIED PM8CX-B is a focused choice for very high-ceiling paging and background-music installations requiring an 8-inch pendant loudspeaker. Its 60-watt 70V transformer, four listed power settings, 8-ohm option, 92dB average sensitivity, 55Hz to 15kHz response, and 90-degree dispersion provide the essential figures needed for system evaluation. It is backed by a 60-month warranty measured from the date of purchase.
