8" 2-way High Performance Pendant Mount Speaker with 70.7V-60W Transfmr

Ideal Use Cases

The AtlasIED PM8CX-WH is expertly designed for environments with very high ceilings, making it a prime choice for venues that require effective audio solutions for both paging and background music. Its 90-degree dispersion ensures wide coverage, vital for large open spaces.

Why Choose This Model

This model combines an 8-inch, 2-way compression-driver coaxial setup with a robust 60-watt 70.7V transformer, offering versatile power settings—7.5W, 15W, 30W, and 60W—along with an 8-ohm operation. With 150 watts RMS at 8 ohms and a sensitivity of 92dB, it promises clarity and power, making it an ideal fit for demanding audio environments.

Installation and Integration

Designed for pendant mounting, the PM8CX-WH integrates seamlessly into existing systems. Its installation is straightforward, with a choice of transformer settings or an 8-ohm option, accommodating various power requirements. While it does not specify connector types or suspension hardware, these standard elements can be easily sourced to fit the installation needs.

Performance Highlights

The PM8CX-WH delivers a frequency response from 55Hz to 15kHz, ensuring a full range of sound for both speech and music. Its 92dB sensitivity and 90-degree dispersion are critical for achieving optimal audio performance across large areas, guaranteeing consistent sound coverage.

• Speaker configuration: 8-inch, 2-way compression-driver coaxial
• Transformer: 60-watt, 70.7V
• Power settings: 7.5W, 15W, 30W, 60W, and 8-ohm operation
• Sensitivity: 92dB
• Frequency response: 55Hz to 15kHz
• Dispersion: 90 degrees

What Makes It Different

The standout feature of the PM8CX-WH is its high-output 8-inch 2-way design combined with a compression driver, allowing it to handle both music and speech with equal effectiveness. The multiple power settings, including a robust 8-ohm option, provide flexibility that is rare in similar models, catering to various installation needs.

Final Assessment

If you’re seeking a powerful, flexible audio solution for high-ceiling installations, the AtlasIED PM8CX-WH is an excellent choice. Its comprehensive specifications, including a 60-watt transformer and 150 watts RMS capability, ensure reliable performance. With a 60-month warranty, it’s a sound investment for any commercial audio setup.
