Introducing the QMC series, the slimmest display in the Samsung’s UHD signage offerings. This products deliver an unparalleled slim design that fits into any business, while delivering the visual quality to make a big impact. The sleek form factor is easily installed to fit any room design and delivers stunning visual performance. Dynamic Crystal Color and Quantum Processor Lite 4K delivering consistent, lifelike colors to any content. This is not just a display for simple advertising. It’s a display that brings the solutions, tools, and picture quality to grow to your business, no matter what industry you’re in.
Specification
Display Panel
Diagonal Size Class 85
Measured 84.5
Resolution 3,840 x 2,160 (16:9)
Brightness (Typ.) 500 nit
Orientation Landscape/Portrait
Haze 25%
Contrast Ratio (Typ.) 4,000:1 4,000:1 4,000:1
Type VA
Active Display Area 1,872.0 (H) x 1,053.01 (V)
Pixel Pitch (mm) 0.487 x 0.487
Color Gamut NTSC 72%
Operation Hour 24/7
Connectivity / Sound
Input
Video DP 1.2 (1), HDMI 2.0 (3)
Audio N/A
USB USB USB 2.0 x 2
Tuner N/A
Output
Video N/A
Audio Stereo mini Jack
USB N/A
WiFi / BT O/O
External Control RJ45 RS232C (In/Out), RJ45
Speaker 10W 2ch
Mechanical Spec
Dimension (mm)
Set 1,904.3 x 1085.3 x 28.5
Package TBD
Weight (kg) Set TBD
Package TBD
VESA Mount 400 x 400
VESA Mount Screw (Min~Max) 12~14mm
Bezel Width (mm) 13.9 (Even)
Features
Key UHD Signage with Built-in MagicInfoS10, SSSP 10.0
Internal Player
Operating System Tizen 7.0
Processor CA73 1.6GHz Quad-Core
Storage (FDM) 16GB (10GB available)
Special
H/W 2nd Gen. B2B Design Center IR Temperature Sensor Ambient Sensor Auto Level Wi-Fi (2.4/5.0GHz dual) and BT
S/W Signage New Home Workspace (Microsoft371/VMWare/RDP) Custom Home Auto Source Switching and Recovery Dicom Simulation Mode Director Mode SmartView+ Upgradable Web-Engine
Tizen Enterprise Platform Video Conference Solution Smart Calibration
Certification
Safety 60950-1/62368-1
EMC Class A
Environment ENERGY STAR 8.0, EPEAT
IP Rating IP5x
Security 802.1 x (WPA2 Enterprise): EAP-TLS, EAP-TTLS, EAP-PEAP
Power
Power Supply AC 100 – 240 V, 50/60 Hz
Operating Condition
Temperature 0℃~ 40℃
Relative Humidity 10~80%
Accessories
Included Quick Setup Guide, Warranty Card, Power Cord RS232C (In) Gender Remote Controller & Batteries
Optional
Stand STN-L6585C
Mount N/A
Specialty TBD
