The Panasonic Connect TH-65CQE2W 4K Professional display is designed for 24-hours/day continuous operation and crystal-clear viewing clarity. The display provides a brightness of 500cd/m² with an anti-glare panel, and minimum haze treatment, reducing the reflection of ambient light and vastly improving visibility. For ultimate flexibility and a clean look without set-top-boxes or cables, the TH-65CQE2W is also equipped with a built-in TV tuner for access to broadcast, cable, and subscription TV services, making them an ideal solution for corporate, education, and even sports bar applications.
KEY FEATURES
- High image quality
- Superb Reliability & Easy Installation
- System scalability
Specifications
Panel | Panel size * 65-inch (64.52-inch/1638.9 mm)
Panel | Brightness (typ.) * 500 cd/m2
Panel | Panel surface treatment * Anti-glare (Haze 1 %)
Terminals | USB * Type A: DC 5 V/max. 0.9 A, USB 3.0 is supported, Type A: DC 5 V/max. 0.5 A, USB 2.0 is supported,Type A: DC 5 V/max. 0.5 A, USB 2.0 is supported (Internal), Type C: DC 5 V/max. 3.0 A, USB 3.0 is supported, DisplayPort Alternate mode compatible
Terminals | microSD * microSD/SDHC/SDXC / MAX 1 TB
Terminals | SERIAL IN * Stereo mini jack (φ3.5 mm) x 1, RS-232C Compatible
Terminals | LAN * RJ45 x 1, compatible with PJLink™ 10BASE-T/100BASE-TX/1000BASE-T
Terminals | IR In * Stereo mini jack (φ3.5 mm) x 1
Terminals | Slot * No
Terminals | Wi-Fi * Yes (Built-in)
Terminals | AUDIO OUT * Stereo mini jack (φ3.5 mm) x 1, SPDIF x 1
Built-in Speaker * 20 W
Power consumption * 245 W
Dimension (WxHxD) (Excluding remote IR sensor) * 456 x 835 x 96 mm (57.32″ x 32.84″ x 3.78″)
Dimension (WxHxD) (Including remote IR sensor) * 1456 x 853 x 96 mm (57.32″ x 33.58″ x 3.78″)
Weight * 24.6 kg/54.3 lbs
Wall-hanging pitch * 600 x 400 mm, M6
HTML browser * HTML5 (Vwed)
Panel | Effective display area (W x H) * <div>1428.4 x 803.5 mm (56.23″ x 31.63″)</div>
Panel | Resolution * 3840 x 2160
Panel | Contrast * 1200:1
Panel | Viewing angle [(T/B)/(L/R)] * 178°/178° (CR>10)
Terminals | HDMI™ IN * HDMI™ x 4 (compatible with HDCP2.2)
Terminals | Bluetooth® * Yes (Built-in)
Android™-OS * Yes
Operating time*1 * 16 h/day
Orientation * Landscape/Portrait
Tilt angle*2 * 0-20 degrees forward with landscape setting
Power Requirements * AC 220 – 240 V 50 Hz / 60 Hz
Power Off Condition * 0 W
Stand-by Conditions * Approx. 0.5 W
Energy efficiency class * G
Bezel Width * 12.9 mm (0.51″) (T/R/L),16.1 mm (0.63″) (B)
Operating environment * Temperature: 0 °C to 40 °C (32 °F to 104 °F)/Humidity: 20-80 % (Non condensation)/for up to 0-1400 m (4593 ft) altitude.
Temperature: 0 °C to 35 °C (32 °F to 95 °F)/Altitude 1400 -2800 m (4593 ft to 7874 ft)
Note * *1: In case of long time, the moving image is recommended to be displayed. If you display a still picture for an extended period, the image retention might remain on the screen. However, image retention can gradually disappear by displaying a moving images.
*2: Please contact your sales representative with regard to the tilt angle before installation.
