Display System 0.55″ DLP
Native Chip Resolution 1024 x 768 (XGA)
Supported Resolutions VGA @ 60 Hz SVGA @ 56 Hz SVGA @ 60 Hz XGA @ 60 Hz SXGA @ 60 Hz 1280 x 720 @ 50 Hz 1280 x 720 @ 60 Hz 1280 x 768 @ 50 Hz 1280 x 768 @ 60 Hz 1280 x 800 @ 50 Hz 1280 x 800 @ 60 Hz 1600 x 900 @ 50 Hz 1600 x 900 @ 60 Hz
Maximum Brightness 2000 Lumens
Uniformity 80%
Aspect Ratio 4:3
Contrast Ratio 1000:1
Scan Horizontal: 15.6 to 67.5 kHz Vertical: 49.8 to 60.3 Hz
Lens f/2.0 – 2.7 (f = 15.2 – 32.7 mm)
Lens Shift Vertical: + 17%
Optical Zoom Powered: 2.2x
Throw Ratio 1.3 to 2.9:1
Projection Size 30 – 200″ / 76.20 – 508.00 cm
Keystone Correction Vertical: ± 40° Horizontal: ± 40°
Inputs/Outputs 1 x HDMI (HDMI Type-A) Audio, Video Input 1 x Ethernet (RJ45) LAN Input/Output 1 x M3 Audio Output 1 x USB 2.0 (USB Type-B) Power Output
Wireless LAN / Wi-Fi Yes, Built-in
Lamp Power 36 W
Expected Lamp Life Medium Brightness: 20,000 Hours
Fan Noise Medium Brightness: 33 dB Low Brightness: 30 dB
Power Consumption Medium Brightness: 240 W Standby Mode (Lamp Off): 0.4 W Standby Mode (Lamp Off): 0.5 W Standby Mode (Lamp Off): 12 W
Dimensions (W x H x D) 18.3 x 2.7 x 3.3″ / 46.5 x 6.9 x 8.4 cm
Weight 9.9 lb / 4.5 kg
Panasonic JX200HWU Overview Aspect Ratio 4:3
Panasonic JX200HWU Overview Contrast Ratio 1000:1 Scan
Panasonic JX200HWU Overview Horizontal 15.6 to 67.5 kHz
Panasonic JX200HWU Overview Vertical 49.8 to 60.3 Hz Lens Lens
Lens Shift Vertical + 17% Optical Zoom
Lens Shift Powered 2.2x
Lens Shift Throw Ratio 1.3 to 2.9:1
Projection Size 30 200″ / 76.20 – 508.00 cm Features Keystone Correction
Projection Size Vertical ± 40°
Projection Size Horizontal ± 40° Inputs/Outputs
1 x HDMI (HDMI Type-A) Audio, Video Input
1 x Ethernet (RJ45) LAN Input/Output
Projection Size 1 x M3 Audio Output
1 x USB 2.0 (USB Type-B) Power Output
Projection Size Wireless LAN / Wi-Fi Yes, Built-in General Lamp Power 36 W Expected Lamp Life
Projection Size Medium Brightness 20,000 Hours
Fan Noise Medium Brightness 33 dB
Fan Noise Low Brightness 30 dB
Power Consumption Medium Brightness 240 W
Standby Mode (Lamp Off) 0.4 W, 0.5 W, 12 W
Power Consumption Dimensions (W x H x D) 18.3 x 2.7 x 3.3″ / 46.5 x 6.9 x 8.4 cm Weight 9.9 lb / 4.5 kg
SKU PT-JX200HWU
