Computer CPU Quad-Core Up to 1.8 GHz Cortex A57 Memory 2 GB
Designed with input from industry professionals, the AV Line M4250 GSM4212UX 8-Port Gigabit PoE++ Compliant Managed AV Switch from Netgear is engineered for 1G AV over IP. Enjoy eight rear-facing 60W PoE++ compliant RJ45 ports with a 720W power budget and two 10G SFP+ uplink slots that ensure a clean integration in AV racks and pre-configuration for out-of-the-box functionality. Built for AV over IP
Pre-Configured for Out-of-the-Box Use NETGEAR IGMP Plus enables instant multicast functionality for most AV over IP installations.
Dedicated AV Web-Based Interface Unique interface designed for the AV professional with color-coded, port-based profiles.
Profiles for Common Audio Protocols Quickly assign profiles to ports for Dante, AES67, and AVB audio configurations.
Video Profiles Built-In Special profiles for NVX, SVSI, Q-SYS, and Dante video profiles can be easily assigned to ports as needed. Mounting Flexibility Rackmount Versatility 1 RU, 7.9″ deep rackmount with all power and Ethernet ports on the back.
Reversed Mounting Possibility Possible reversed mounting with ports in the front including recessed mounting to protect cables.
Universal Mounting Availability Mounting outside the rack made possible with bottom M5 and front M10 threaded holes. Advanced Features Layer 2 / Layer 3 Switching
Universal Mounting Availability Common Layer 2 and Layer 3 switching engine across all M4250 models.
Control Methods Abound Built-in IT web GUI, console, telnet, and SSH. Standard Network Features
Control Methods Abound Feature set includes static, RIP and PIM routing, DHCP Server, and PTPv2. Specifications Key Specs Inputs/Outputs
40x RJ45 Gigabit Ethernet PoE+ (30 W, 802.3at) 8x SFP Gigabit Ethernet
2x RJ45 Gigabit Ethernet LAN 2x USB-C 1x USB-A Stackable No Switching Bandwidth 96 Gb/s
Control Methods Abound PoE Power Budget 480 W Stackable No Protocols
Control Methods Abound Layer Services Supported Layer 2, Layer 3 Supported Protocols DHCP Server IGMP Snooping IPv4 IPv6 Link Aggregation Port Mirroring
Control Methods Abound Jumbo Frames Support 12,000 Bytes
Control Methods Abound MAC Address Table Size 16K Security Security Features DHCP Snooping DoS Attack Prevention RADIUS Authentication Storm Control Performance Forwarding Rate 71.42 Mpps Switching Bandwidth 96 Gb/s Packet Buffer 32 Mb Computer
CPU Quad-Core Up to 1.8 GHz Cortex A57 Memory 2 GB Electrical PoE per Port 30 W
Power Supply Type Internal Environmental Operating Temperature 32 to 77 F / 0 to 45 C
Power Supply Type Internal Environmental Operating Humidity 90%
Power Supply Type Internal Environmental Storage Temperature -4 to 158 F / -20 to 70 C Storage Humidity 95% General Certifications No
Power Supply Type Internal Environmental Cooling System Fan/Passive Combo Indicator Lights Yes Rack Mountable Yes 1 RU
Power Supply Type Internal Environmental Dimensions 17.3 x 15.7 x 1.7″ / 440 x 400 x 43.2 mm
Power Supply Type Internal Environmental Weight 13.91 lb / 6.31 kg Packaging Info
Power Supply Type Internal Environmental Package Weight 17.635 lb
Power Supply Type Internal Environmental Box Dimensions (LxWxH) 20.9 x 18.2 x 4.8″
SKU GSM4212UX-100NAS
