Clear View with Non-glare Coating

Viewers can be annoyed by unnecessary reflections when watching a screen under brightly lit conditions. The UH7F-H series has resolved such inconveniences by increasing the level of haze, which enhances visibility and text readability.

ULTRA HD Resolution

Ultra HD resolution is 4 times higher than FHD and it makes the color and details of content vivid and realistic. In addition, the IPS panel offers a wide viewing angle and clear content.

Narrow Bezel & Slim Depth

The UH5F-H series digital signage has a thin bezel size and thickness. It helps create an immersive experience while providing a sophisticated design that can help improve the décor of the space where the product is installed.

Detachable Logo and Built-in Speaker

49UH7F-H is equipped with a new transparent logo that is detachable giving the user flexibility for installation. Content is enriched with sound effects from built-in speakers.

IP5x Certified Design

The IP5x Dust-Proof Certification ensures that the product is protected from dust, reducing the risk of performance degradation.

30° Tilting Installation

When installed in high places the UH7F-H series supports the installation of 30 degrees of tilt. making it easier for customers to see.

Auto Screen Rotation

49UH7F-H automatically detects its orientation (landscape or portrait mode) in the initial installation step. The direction of onscreen menu and background content will be set when you turn on a display.

Fine Adjustment

The UH7F-H series is equipped with a “horizontal sensor” which shows users how the device is oriented, to aid in installation.

High-Performance with webOS

The 49UH7F-H has a built-in Quad Core System on a Chip (SoC) and can execute several tasks at once while providing smooth content playback. The LG webOS™ platform has an intuitive Graphic User Interface (GUI) and simple app development tools.

Various Sensor Connection

LG webOS™ smart signage platform easily supports connections with external sensors such as GPIO, NFC/RFID, temperature sensors, etc, via USB plug-in. There is no need to purchase additional software or media players.

Compatible with AV Control System

The UH7F-H series has been certified Crestron Connected® for high compatibility with professional AV controls to achieve seamless integration and automated control, boosting business management efficiency.

Compatible with Video Conference System

The UH7F-H series has certified its compatibility with Cisco System, which offers powerful and integrated control for a smart video conference.

• 700 nits Brightness (Typ.)
• Surface Treatment (Haze) : 28%
• Bezel : 9.9 mm (T/R/L), 14.4 mm (B)
• 30° Tilting, Detachable Logo, Built-in Speakers
• WebOS™ Smart Signage Platform
• Cisco System & Crestron Connected® Compatible

SPECIFICATIONS

General Information
Manufacturer	LG Electronics
Manufacturer Part Number	49UH7F-H
Product Series	UH7F-H
Product Model	49UH7F-H
Product Name	49UH7F-H Digital Signage Display
Product Type	Digital Signage Display
Technical Information
Bezel Width (Bottom)	0.57″
Bezel Width (Top)	0.39″
Bezel Width (Left)	0.39″
Bezel Width (Right)	0.39″
Memory
Standard Memory	8 GB
Display & Graphics
Screen Size	49″
Display Screen Type	LCD
Display Resolution	3840 x 2160
Backlight Technology	Edge LED
Video
Scan Format	2160p
Dynamic Contrast Ratio	500,000:1
Color Depth	10-bit
Brightness	700 Nit
Color Gamut	95% BT.709
Network & Communication
Ethernet	Yes
Wireless LAN	Yes
Interfaces/Ports
USB	Yes
HDMI	Yes
Serial	Yes
Number of USB 2.0 Ports	1
Software
Operating System	webOS 4.1
Power Description
Input Voltage	120 V AC
	230 V AC
Physical Characteristics
Color	Black
VESA Mount Standard	300 x 300
Mount Type	Wall Mountable
Miscellaneous
Package Contents	49UH7F-H Digital Signage Display Remote Control 2 x Batteries Power Cord Quick Service Guide HDMI Cable Regulation Book Phone to RS232C Adapter
Energy Star	Yes
Environmentally Friendly	Yes
Environmental Certification	CEC
	ENERGY STAR 8.0
	ErP
Warranty
Limited Warranty	3 Year
