The Huddly L1 uses AI to automatically frame participants. It does this smoothly and responsively, without distracting moving parts. The L1 retains an overview of the entire room whilst displaying the zoomed image. This means that when people enter, leave, or move about, the L1 instantly adjusts the frame. The Huddly L1’s neural engine has been trained and optimized to detect the people in large and medium meeting rooms. The camera is able to retain an overview of the entire room, even while zoomed in, allowing it to capture data such as meeting room usage, occupancy, and people count.

Specifications

Key Specs
Resolution and Frame Rate 1080p at up to 30 fps,720p at up to 30 fps
Image Sensor 1″-Type CMOS
Sensor Resolution 20.3 MP
System Connection USB-C 3.0 / 3.1/3.2 Gen 1

Sensor
Resolution and Frame Rate 1080p at up to 30 fps,720p at up to 30 fps
Number of Lenses 1
Image Sensor 1″-Type CMOS
Sensor Resolution 20.3 MP
Aperture f/2.9
Field of View
Horizontal: 92°
Diagonal: 103°
Vertical: 65°
Zoom 5x (Digital)

General
System Connection USB-C 3.0 / 3.1/3.2 Gen 1
Other I/O 1x RJ45 Gigabit Ethernet
Focus Type Auto
Wireless No
Bluetooth No
Wi-Fi No
Power Source AC Adapter, Bus Powered, PoE
Low-Light Correction Yes
DC Input Power 5 VDC at 3 A
OS Compatibility
macOS
Windows 10 or Later
Chrome OS

Microphone
Microphone No

Physical
Privacy Shutter No
Security No
Built-In Light No
Housing Material Aluminum
Dimensions (W x H x D) 4.8 x 2.1 x 3.5″ / 122.0 x 53.0 x 90.0 mm
Weight 1.3 lb / 600 g

Packaging Info
Package Weight 4.005 lb
Box Dimensions (LxWxH) 11.8 x 7.7 x 3.8″
