Display System LCD
Native Resolution 1920 x 1080
Maximum Brightness White: 4100 Lumens Color: 4100 Lumens
Throw Ratio 0.25 to 0.35:1
Projection Size 49 to 150″ / 124.5 to 381.0 cm
HDR Support No
Inputs/Outputs 3x HDMI Audio, Video Input 1x DE-15/DB-15 (VGA) Video Input 1x DE-15/DB-15 (VGA) Video Input/Output 1x RCA (Composite) Video Input 3x 1/8″ / 3.5 mm Mini Audio Input 1x 1/8″ / 3.5 mm Mini Audio Output 1x USB-A Power Output 2x USB-B Audio, Video Input 1x DE-9/DB-9 (RS-232) Control Input/Output 1x RJ45 (Ethernet) LAN Input/Output
Light Source Laser Phosphor
Aspect Ratio Native: 16:9 Supported: 16:10 Supported: 4:3 Supported: 16:6 Supported: 21:9
Dynamic Contrast Ratio 2,500,000:1
Color Depth 10-Bit (1.07 Billion Colors)
Includes Lens Yes
Focus Manual
Aperture f/1.6
Focal Length 3.7mm
Throw Distance 13 to 35″ / 0.3 to 0.9 m
Keystone Correction Manual to Vertical: 3 Manual to Horizontal: 3
Digital Zoom 1.35x
Multi-Input Support (PIP/PBP) Not Specified by Manufacturer
HDCP Support Not Specified by Manufacturer
Mobile App Compatible Yes: Android & iOS
Wireless LAN / Wi-Fi Yes, Built-in
Bluetooth No
Expected Lamp Life Full Brightness: 30,000 Hours Medium Brightness: 20,000 Hours
Fan Noise Full Brightness: 37 dB Low Brightness: 27 dB
Input Power 100 to 240 VAC, 50 / 60 Hz
Power Consumption Full Brightness: 277 W Low Brightness: 214 W Standby Mode (Lamp Off): 0.5 W
Certifications RoHS
Operating Conditions 41 to 104 F / 5 to 40 C at 20 to 80% Humidity
Dimensions (W x H x D) 14.1 x 15.6 x 6.5″ / 35.8 x 39.6 x 16.5 cm (Including Feet)
Weight 13 lb / 5.9 kg
Package Weight 17.45 lb
Box Dimensions (LxWxH) 19 x 18.9 x 12.5″
Epson 770F Overview Take control of playlist and playback functions and enhance your content with included templates, effects, color filters, and other customizable options. Additional Features
Epson 770F Overview Clear and easy-to-read 1080p projections
Epson 770F Overview Built-in edge blending for scalable, wall-sized images 360 placement
Epson 770F Overview Wall mountable with optional ELPMB62 mount
Epson 770F Overview Remote management and control tools Epson 770FSpecs Display System LCD
Epson 770F Overview Native Resolution 1920 x 1080 Maximum Brightness
Epson 770F Overview White 4100 Lumens
Epson 770F Overview Color 4100 Lumens
Epson 770F Overview Throw Ratio 0.25 to 0.35:1
Epson 770F Overview Projection Size 49 to 150″ / 124.5 to 381.0 cm
HDR Support No Inputs/Outputs 3x HDMI Audio, Video Input
HDR Support No Inputs/Outputs 1x DE-15/DB-15 (VGA) Video Input, DE-15/DB-15 (VGA) Video Input/Output
1x RCA (Composite) Video Input 3x 1/8″ / 3.5 mm Mini Audio Input 1x 1/8″ / 3.5 mm Mini Audio Output
2x USB-B Audio, Video Input 1x DE-9/DB-9 (RS-232) Control Input/Output
1x RJ45 (Ethernet) LAN Input/Output Light Source Laser Phosphor Image Display Display System LCD, LAN Input/Output HDCP Support
1x USB-A Power Output Native Resolution 1920 x 1080 Maximum Brightness
1x USB-A Power Output White 4100 Lumens
1x USB-A Power Output Color 4100 Lumens
Aspect Ratio Native 16:9
Aspect Ratio Supported 16:10, 4:3, 16:6, 21:9
Aspect Ratio Color Depth 10-Bit (1.07 Billion Colors) Lens Includes Lens Yes Focus Manual Aperture f/1.6
Aspect Ratio Focal Length 3.7mm
Aspect Ratio Throw Distance 13 to 35″ / 0.3 to 0.9 m, Ratio 0.25 to 0.35:1
Aspect Ratio Projection Size 49 to 150″ / 124.5 to 381.0 cm Features Keystone Correction
Manual to Vertical 3
Manual to Horizontal 3
Aspect Ratio HDR Support No Digital Zoom 1.35x
Aspect Ratio Multi-Input Support (PIP/PBP)
Input/Output Connectors Inputs/Outputs 3x HDMI Audio, Video Input
Input/Output Connectors Inputs/Outputs 1x DE-15/DB-15 (VGA) Video Input, DE-15/DB-15 (VGA) Video Input/Output
1x USB-A Power Output Not Specified by Manufacturer Hardware Mobile App Compatible
1x USB-A Power Output Yes Android & iOS
1x USB-A Power Output Wireless LAN / Wi-Fi Yes, Built-in Bluetooth No General Light Source Laser Phosphor Expected Lamp Life
1x USB-A Power Output Full Brightness 30,000 Hours
1x USB-A Power Output Medium Brightness 20,000 Hours
Fan Noise Full Brightness 37 dB
Fan Noise Low Brightness 27 dB
Fan Noise Input Power 100 to 240 VAC, 50 / 60 Hz
Power Consumption Full Brightness 277 W
Power Consumption Low Brightness 214 W
Standby Mode (Lamp Off) 0.5 W Certifications RoHS
Power Consumption Operating Conditions 41 to 104 F / 5 to 40 C at 20 to 80% Humidity
Power Consumption Dimensions (W x H x D) 14.1 x 15.6 x 6.5″ / 35.8 x 39.6 x 16.5 cm (Including Feet) Weight 13 lb / 5.9 kg Packaging Info Package Weight 17.45 lb
Power Consumption Box Dimensions (LxWxH) 19 x 18.9 x 12.5″
SKU 770F
Brand Epson
MPN V11HA79020
GTIN 00010343975385, 010343975385
UPC 010343975385
