Display System 3-Chip Polysilicon TFT LCD
Native Chip Resolution 1920 x 1200 (WUXGA)
Supported Resolutions Maximum: SVGA – 800 x 600 Maximum: UXGA – 1600 x 1200
Maximum Brightness 3600 Lumens
Aspect Ratio Native: 16:10 Supported: 16:9 Supported: 4:3
Dynamic Contrast Ratio 15,000:1
Color Depth 10-Bit (1.07 Billion Colors)
Focus Manual
Lens f/1.5 – 1.71 (f = 20.42 – 24.5 mm)
Optical Zoom Manual: 1.2x
Throw Distance 2.953 – 29.528′ / 0.9 – 9 m
Throw Ratio 1.38 to 1.68:1
Projection Size 30 – 300″ / 76.20 – 762.00 cm
Keystone Correction Auto-Vertical: 30 Manual-Horizontal: 30
Ceiling Mountable Yes
Rear Screen Projection Yes
Built-In Speaker Yes (Mono)
Speaker Power 2W
Inputs/Outputs 1 x HDMI (HDMI Type-A) Audio, Video Input 1 x HDMI with MHL Support (HDMI Type-A) Audio, Video Input 1 x VGA (DE-15/DB-15) Video Input 1 x Composite (RCA) Video 1 x 2RCA Audio Input 1 x USB 2.0 (USB Type-A) Audio, Video Input 1 x USB 2.0 (USB Type-B) Service Input
Wireless LAN / Wi-Fi Yes, Built-in
Light Source Lamp (1 x UHE)
Lamp Power 210 W
Expected Lamp Life Medium Brightness: 6000 Hours Low Brightness: 10,000 Hours
Fan Noise Medium Brightness: 37 dB Low Brightness: 28 dB
Security Password Protection
AC Input Power 120 to 240 VAC, 50 / 60 Hz
Power Consumption Medium Brightness: 315 W Low Brightness: 315 W
Dimensions (W x H x D) 11.9 x 3.6 x 9.9″ / 30.2 x 9.1 x 25.1 cm Including feet, approximate 11.9 x 3.4 x 9.8″ / 30.2 x 8.6 x 24.9 cm Excluding feet, approximate
Weight 6.2 lb / 2.81 kg
Package Weight 9.015 lb
Box Dimensions (LxWxH) 15 x 14.15 x 6.25″
Brightness of 3600 Lumens WUXGA (1920 x 1200) Native Resolution
Brightness of 3600 Lumens VGA, RCA Composite, 2x HDMI Inputs
Brightness of 3600 Lumens Analog Audio Input Built-In 2-Watt Speaker
Brightness of 3600 Lumens High Color and White Brightness Levels
Brightness of 3600 Lumens Both color and white brightness of 3600 lumens. Wireless
Brightness of 3600 Lumens Built-in Wi-Fi connectivity allows you to project from laptops and mobile and streaming devices. Portable Design
Miracast allows you to wirelessly mirror a compatible Android phone or tablet or Intel-based Windows laptop. Manual Keystone Correction
Brightness of 3600 Lumens Manual keystone correction adjusts vertically and horizontally to help achieve a perfectly rectangular image.
Designed for Fast Wireless Setup Scan the on-screen QR code using your phone or tablet for a quick connection. Eco Features RoHS compliant Recyclable design Epson 1286 Specs Image Display Display System 3-Chip Polysilicon TFT LCD
Designed for Fast Wireless Setup Native Chip Resolution 1920 x 1200 (WUXGA) Supported Resolutions
Designed for Fast Wireless Setup Maximum SVGA – 800 x 600, UXGA – 1600 x 1200 Maximum Brightness 3600 Lumens
Aspect Ratio Native 16:10
Aspect Ratio Supported 16:9, 4:3
Aspect Ratio Color Depth 10-Bit (1.07 Billion Colors) Lens Focus Manual Lens
Aspect Ratio Manual 1.2x
Throw Distance Throw Ratio 1.38 to 1.68:1
Projection Size 30 300″ / 76.20 – 762.00 cm Features Keystone Correction
Projection Size Auto-Vertical 30
Projection Size Manual-Horizontal 30 Ceiling Mountable Yes Rear Screen Projection Yes Built-In Speaker Yes (Mono) Speaker Power 2W
1 x HDMI (HDMI Type-A) Audio, Video Input, with MHL Support (HDMI Type-A) Audio, Video Input
1 x VGA (DE-15/DB-15) Video Input 1 x Composite (RCA) Video
Input/Output Connectors Inputs/Outputs 1 x 2RCA Audio Input
1 x USB 2.0 (USB Type-A) Audio, Video Input, 2.0 (USB Type-B) Service Input Hardware
Input/Output Connectors Inputs/Outputs Wireless LAN / Wi-Fi Yes, Built-in General Light Source Lamp (1 x UHE) Lamp Power 210 W Expected Lamp Life
Input/Output Connectors Inputs/Outputs Medium Brightness 6000 Hours
Input/Output Connectors Inputs/Outputs Low Brightness 10,000 Hours
Fan Noise Medium Brightness 37 dB
Fan Noise Low Brightness 28 dB Security Password Protection
Fan Noise AC Input Power 120 to 240 VAC, 50 / 60 Hz
Power Consumption Medium Brightness 315 W
Power Consumption Low Brightness 315 W
Power Consumption Dimensions (W x H x D) 11.9 x 3.6 x 9.9″ / 30.2 x 9.1 x 25.1 cm Including feet, approximate 11.9 x 3.4 x 9.8″ / 30.2 x 8.6 x 24.9 cm Excluding feet, approximate Weight 6.2 lb / 2.81 kg Packaging Info Package Weight 9.015 lb
Power Consumption Box Dimensions (LxWxH) 15 x 14.15 x 6.25″
SKU PL-1286
