The Samsung VMB-U Series 46" Video Wall Display provides an immersive and dependable viewing experience for a wide range of locations. A narrow bezel-to-bezel design allows for seamless images, while wide viewing angles ensure clear details and vivid colors regardless of where the screen is located. Non-glare panels evenly distribute light across the screen to maintain vibrant and accurate content; picture enhancement technology delivers optimized visuals. Daisy chain multiple displays and control them via linked RS232C input and output.
A Full HD 1920 x 1080 resolution with a 500 cd/m² brightness facilitates accurate images. A 1200:1 static contrast ratio ensures crisp imaging. Deploying in portrait or landscape orientation, this display is designed for 24/7 operation. An IP5X dust resistance rating also allows for easy deployment without the need to a separate dust-resistant cabinet. Streamline performance with the Samsung UHD Signage Player box or create a free-standing display with the WMN-46VD stand, both available separately.
Space-Saving Design with Narrow Bezels
Specifications
Display
Display technology LCD
Display diagonal 116.8 cm (46")
Display resolution 1920 x 1080 pixels
HD type Full HD
Panel type IPS
Aspect ratio 16:9
Pixel pitch 0.53 x 0.53 mm
Display brightness 500 cd/m²
Pixel frequency 82 MHz
Contrast ratio (typical) 1200:1
Contrast ratio (dynamic) 45000:1
Response time 0.008 s
Viewing angle, horizontal 178°
Viewing angle, vertical 178°
Horizontal scan range 62.7 - 72.3 kHz
Vertical scan range 57 - 63 Hz
Operating hours (hours/days) 24/7
Design
Placement supported Indoor
Orientation Landscape/Portrait
Bezel width (side) 1.25 mm
Bezel width (top) 2.25 mm
Bezel width (bottom) 2.25 mm
VESA mounting Yes
Panel mounting interface 600 x 400 mm
Product colour Black
Panel colour Black
Ports & interfaces
HDMI ports quantity 2
HDMI version 2.0
DVI port Yes
DisplayPorts quantity 1
DisplayPort version 1.2
Ethernet LAN Yes
Ethernet LAN (RJ-45) ports 1
RS-232 input ports 1
RS-232 output ports 1
RS-232C Yes
USB port Yes
USB ports quantity 1
HDCP Yes
HDCP version 2.2
IR input ports quantity 1
Audio input Yes
Audio output Yes
Power
Power consumption (typical) 160 W
Energy efficiency scale A to G
Energy efficiency class (SDR) G
Energy consumption (SDR) per 1000 hours 128 kWh
AC input voltage 100 - 240 V
AC input frequency 50 - 60 Hz
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Operating relative humidity (H-H) 10 - 90%
Logistics data
Harmonized System (HS) code 85285210
Weight & dimensions
Width 1022 mm
Depth 69.9 mm
Height 577 mm
Weight 15.7 kg
Packaging data
Package width 1193 mm
Package depth 257 mm
Package height 719 mm
Package weight 22.2 kg
