Audio Extender Reciever Only

Ideal Use Cases

The AVPro Edge AC-AEX-R receiver is ideal for professional audio systems needing long-distance audio transmission. It extends uncompressed audio signals up to 100 meters over unshielded twisted pair (UTP) and 130 meters over shielded twisted pair (STP). This makes it perfect for integrating SmartTV audio into distributed systems, supporting popular streaming services like Netflix and Spotify. Its compatibility with both analog stereo L/R and optical digital S/PDIF signals ensures versatility in various audio setups.

Why Choose This Model

The AC-AEX-R stands out with its support for both stereo and multichannel digital audio up to 5.1 channels via Dolby Digital or DTS. It can handle LPCM 2-channel and Dolby Digital/DTS Digital ES formats through the optical input, with sampling rates ranging from 32 kHz to 96 kHz. This flexibility, combined with its ability to switch between coaxial and optical signals, makes it an adaptable solution for diverse audio requirements. The dual active audio outputs allow connections to multiple audio systems simultaneously, enhancing integration options for installers.

Installation and Integration

Installation is streamlined with the use of RJ45 and proprietary UTP/STP cable systems, featuring Power over Cable (POC) technology. This allows for both audio and power to be transmitted over a single cable, reducing clutter and simplifying setup. The receiver’s compact dimensions (22.3 x 58 x 82 mm) and lightweight design (0.19 lb) make it suitable for installations with limited space. It consumes a maximum of 3 watts, and power options include USB or a separate power adapter with a locking barrel plug, accommodating various installation environments.

Performance Highlights

Engineered for uncompressed audio transmission, the AC-AEX-R maintains high audio quality over long distances. It supports analog L/R and optical digital S/PDIF signals, catering to both two-channel and 5.1-channel systems. With an input impedance of 47 kΩ and output impedance of 600 Ω, it ensures reliable signal processing. The device offers robust ESD protection, rated at +4 kV/-4 kV for both contact and air discharge, safeguarding against electrical disturbances.

What Makes It Different

The AC-AEX-R distinguishes itself through its combination of long-distance uncompressed audio extension and dual active audio outputs. Its ability to handle both analog and digital signals, coupled with SmartTV audio support, makes it invaluable for systems requiring streaming audio integration. The durable chassis and 10-year warranty reflect its reliability and longevity, providing peace of mind for professional installers.

Final Assessment

For installations that demand reliable, long-distance audio extension, the AC-AEX-R is an optimal choice. It offers comprehensive support for various audio formats and dual outputs, all within a compact and lightweight package. Note that this listing is for the receiver only, with the necessary power supply sold separately. Be aware of the California warning: this product contains chemicals, including lead, known to cause cancer.
