Samsung QM32R-A 32" Class Full HD Smart Digital Signage LED Display

Samsung QM32R Overview

Engage your customers and vividly display your business messaging with the Samsung QMR-A 32″ Class Full HD Smart Digital Signage LED Display, featuring high picture quality with 400 cd/m² of brightness and reliable 24/7 usage. You can present a range of immersive and timely information with captivating Full HD images. The slim, symmetrical design seamlessly integrates into virtually any environment, with embedded digital signage software for an all-in-one solution. Fully compatible with Cisco WebEx Room Kit products to create the ultimate video collaboration experience.

Key Features

• Full HD (1920 x 1080) Native Resolution
• 8 ms Response Time
• 5000:1 Contrast Ratio
• SSSP with Tizen 4.0 OS

Full HD for Sharp, Captivating Messages

1920 x 1080 resolution delivers sharp, Full HD images that capture attention.

Slim and Symmetrical Design

The slim and symmetrical design of the QM32R vastly simplifies mounting and installation, allowing for seamless integration into virtually any environment.

Powerful, All-in-One Signage Solution

The embedded MagicINFO Player S6, backed by a powerful Tizen operating system, allows for easy content, display management, and playback without the need for a computer.

Built-In Wi-Fi and Bluetooth

With Wi-Fi and Bluetooth built in, the QM32R supports easy content management.

Cisco Certified

The QM32R is fully compatible with Cisco WebEx Room Kit products to create the ultimate video collaboration experience.

Samsung Workspace Secured by Knox

With Samsung Workspace, you can remotely access and control a computer plus access web-based cloud services, with security provided by Samsung Knox.

Attract Customers with Optimized 24/7 Performance

Engage your customers with high picture quality, 400 cd/m² brightness, and reliable 24/7 usage in commercial environments.

Samsung QM32R Specs

Panel

• Diagonal Size32″
• TypeEdge LED BLU
• Resolution1920*1080 (Full HD)
• Pixel Pitch(mm)0.360 x 0.360
• Active Display Area(mm)698.4(H) x 392.85(V)
• Brightness(Typ.)400 nit
• Contrast Ratio5000:1
• Viewing Angle(H/V)178/178
• Response Time(G-to-G)8ms(Typ.)
• Display Colors16.7M(True Display) 1.07B(Ditherd 10bit)
• Color Gamut72%
• Operation Hour24/7
• Haze2%

Display

• Dynamic C/RMEGA
• H-Scanning Frequency30 ~ 81kHZ
• V-Scanning Frequency48 ~ 75HZ
• Maximum Pixel Frequency594MHz

Sound

• Speaker TypeBuilt in Speaker(10W + 10W)

Connectivity

Input

• RGBDisplay Port 1.2 (1)
• VideoHDMI 2.0 (1)
• HDCPHDCP2.2
• AudioStereo mini Jack, HDMI
• USBUSB 2.0 x 2

Output

• RGBHDMI 2.0 (Loop-out)
• AudioStereo mini Jack

• External ControlRS232C(in/out) thru stereo jack, RJ45
• External SensorIR

Power

• TypeInternal
• Power SupplyAC 100 – 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption

• Max[W/h]72
• Typical[W/h]44
• Rating[W/h]65
• BTU(Max)245.5
• Sleep mode0.5

Mechanical Specification

Dimension (mm)

• Set725.1 x 419.6 x 34.6
• Package812 x 513 x 120

Weight (kg)

• Set5.7
• Package8.0

• VESA Mount (mm)200 X 200
• Stand TypeFoot Stand (Optional)
• Bezel Width (mm)8.8mm(U/L/R/B)

Operation

• Operating Temperature 0 ~ 40
• Humidity 10 % ~ 80 %

Feature

• Key FeaturesFHD Signage Display Slim & Light Signage with Built-in MagicInfo S6, SSSP 6.0
• OrientationN/A
• Remote ControlN/A

• Special Features H/W:Temperature Sensor,Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W 2ch), Video Wall Daisy Chain(HDCP2.2:4EA,HDCP1.4:7EA), IP5x Rating, Wi-Fi/BT S/W:Auto Source Switching & Recovery, LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting)

Internal Player

• ProcessorCortex A72 1.7GHz Quad-Core CPU
• On-Chip Cache MemoryL1 Instruction Cache : 48KB L1 Data Cache : 32KB L2 Cache : 2MB
• Clock Speed1.7GHz
• Main Memory Interface2.5GB LPDDR4 1.5GHz 64bit

• GraphicsGraphic resolution : 1920×1080 Output resolution : 3840×2160 (Scale up from graphic processing result.)
• Storage (FDM)8GB (3.88GB Occupied by O/S, 4.12GB Available)
• Multimedia*Video Decoder : MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 *Audio Decoder : AC3 (DD), MPEG
• IO PortsUSB 2.0

• Operating SystemTizen 4.0 (VDLinux)

Certification

• Safety60950-1
• EMCClass B
• Security802.1x (WPA2 Enterprise) : EAP-TLS, EAP-TTLS, EAP-PEAP
