Epson PowerLite PL-975W 3600-Lumen WXGA 3LCD Projector

Epson 975W Overview

Enjoy bright, vibrant images with the Epson PowerLite 975W 3600-Lumen WXGA 3LCD Projector. Its 3600 lumens of brightness, combined with its 15,000:1 contrast ratio, will help it overcome ambient light in many situations and help retain detail in dark areas of the image without compromising overall brightness. Its 1280 x 800 native resolution will help ensure that text is clear at most viewing distances.

The PowerLite 975W features VGA, RCA composite, and two HDMI inputs to support various sources. One HDMI input is MHL-compatible, which will allow you to connect your compatible smart device directly to the projector to mirror its screen, and wireless presentation is possible via the included LAN module. You can output the video to another projector or display with the VGA output. Its 3.5mm audio inputs and output allow for audio transmission, for a more immersive experience. An IR remote is included for convenient control, while the included VGA cable will provide instant connectivity.

Key Features

• Brightness of 3600 Lumens
• WXGA (1280 x 800) Native Resolution
• 1.38 to 2.24:1 Throw Ratio
• VGA, RCA Composite, 2 x HDMI Inputs
• VGA Output for Loop-Through
• Analog Audio Input and Output
• Built-In 16W Speaker
• Ethernet and RS-232 Controllable
• Wireless LAN Module Included
• VGA Cable and IR Remote Included

High Color and White Brightness Levels

The PowerLite 975W features 3600 lumens of color and white brightness to help overcome ambient light.

Wireless Ready

Includes a LAN module for wireless connectivity.

HDMI with MHL connectivity

View HD content and mirror your mobile device with MHL.

Auto Screen Fit

Designed to easily and quickly adjust the image to fit the screen.

Accurate Colors

3-chip, 3LCD technology provides a wide color gamut.

Eco-Friendly Lamp

The lamp lasts up to 10,000 hours in ECO Mode.

Secure Wireless Networking

Enjoy secure wireless connectivity plus wireless HD screen mirroring of up to four different devices with Miracast, allowing you to mirror Chromebook, iOS, Android, Mac, and Windows computer screens.

Split Screen Feature

Simultaneously project two images, video or still, side by side from two different sources.

Enhanced Detail

The projector's 15,000:1 dynamic contrast ratio helps enhance clarity for both text and graphics.

Designed for Versatile Connectivity

Two HDMI ports support HD A/V devices, and one port is MHL-compatible for use with your compatible smart devices.

Remote Management and Control Tools

The included software allows for remote monitoring and control of Epson network projectors. The PowerLite 975W is also compatible with Crestron RoomView management software.

Epson 975W Specs

Image Display

Display System	3-Chip Polysilicon TFT LCD
Native Chip Resolution	1280 x 800 (WXGA)
Supported Resolutions	Maximum: Full HD 1080p - 1920 x 1080
Maximum Brightness	3600 Lumens
Aspect Ratio	Native: 16:10
Contrast Ratio	15,000:1
Color Depth	10-Bit (1.07 Billion Colors)

Lens

Focus	Manual
Lens	f/1.51 - 1.99 (f = 18.2 - 29.2 mm)
Optical Zoom	Manual: 1.6x
Throw Distance	22.31 - 27.559' / 6.8 - 8.4 m
Throw Ratio	1.38 to 2.24:1
Projection Size	29 - 280" / 73.66 - 711.20 cm

Features

Keystone Correction	Vertical: ± 30°
Ceiling Mountable	Yes
Rear Screen Projection	Yes
Built-In Speaker	Yes (Mono)
Speaker Power	16W

Input/Output Connectors

Inputs/Outputs

1 x HDMI (HDMI Type-A) Audio, Video Input 1 x HDMI with MHL Support (HDMI Type-A) Audio, Video Input 1 x VGA (DE-15/DB-15) Video Input 1 x Composite (RCA) Video Input 2 x 1/8" / 3.5 mm Mini Audio Input 1 x 2RCA Audio Input 1 x VGA (DE-15/DB-15) Video Output 1 x 1/8" / 3.5 mm Mini Audio Output 1 x Ethernet (RJ45) LAN Input 1 x RS-232 (DE-9/DB-9) Control Input 1 x USB 2.0 (USB Type-A) Data 1 x USB 2.0 (USB Type-B) Control

Hardware

Wireless LAN / Wi-Fi

Yes, Built-in

General

Light Source	Lamp (1 x UHE)
Lamp Power	250 W
Expected Lamp Life	Medium Brightness: 10,000 Hours
Fan Noise	Medium Brightness: 29 dB
Security	Cable Lock Slot
AC Input Power	120 to 240 VAC, 50 / 60 Hz
Power Consumption	Medium Brightness: 334 W Standby Mode (Lamp Off): 2.4 W Standby Mode (Lamp Off): 0.21 W
Dimensions (W x H x D)	14.8 x 4.5 x 11.4" / 37.6 x 11.4 x 29.0 cm Including feet 14.8 x 3.9 x 11.4" / 37.6 x 9.9 x 29.0 cm Excluding feet and lens
Weight	9.7 lb / 4.4 kg

Packaging Info

Package Weight	14.5 lb
Box Dimensions (LxWxH)	20.6 x 15.1 x 8.1"
