Display System 0.96″ DLP
Native Chip Resolution 1920 x 1200 (WUXGA)
Maximum Brightness 31,000 Lumens
Uniformity 90%
Aspect Ratio 4:3
Dynamic Contrast Ratio 20,000:1, 20,000:1 Scan
Scan Horizontal: 15 to 100 kHz Vertical: 24 to 120 kHz
Projection Size 70 – 1000″ / 177.80 – 2540.00 cm
Keystone Correction Vertical: 40 Horizontal: 15
Ceiling Mountable Yes
Rear Screen Projection Yes
Inputs/Outputs 1 x Composite (BNC) Video Input 1 x HDMI (HDMI Type-A) Video Input 1 x DVI-D Video Input 5 x Composite (BNC) Video Input 1 x VGA (DE-15/DB-15) Video Input 2 x Composite (BNC) Video Output 1 x DE-9/DB-9 Video Input 1 x DE-9/DB-9 Video Output 1 x USB 2.0 (USB Type-B) Power Output
Dimensions (W x H x D) 27.6 x 16.5 x 49.2″ / 700.0 x 418.0 x 1250.0 mm with protrusion parts
Weight 174 lb / 78.92 kg
Panasonic RZ31KU Overview Furthermore, DIGITAL LINK supports transmission of uncompressed full HD video and control commands through a single Cat5e or higher STP cable for distance up to 492′ (150m). The projector’s dust-proof design features hermetically sealed laser modules, long-life Eco Filter, and refined air-intake system. Technology
Panasonic RZ31KU Overview Combines 3-Chip DLP with SOLID SHINE laser technology for bright and immersive picture quality
Accurate color-space reproduction
Minimal maintenance required under continuous operation Dustproof design featuring hermetically sealed laser modules, long-life Eco Filter, and refined air-intake system
Efficient liquid cooling system ensures stable operation in ambient temperatures of up to 113 F (45 C)
31,000 lumens of brightness with durable performance
Panasonic RZ31KU Overview Real Motion Processor 120 Hz frame-creation technology for smooth motion reproduction
Panasonic RZ31KU Overview Dynamic Contrast laser light-source modulation achieves high 20,000:1 contrast
Panasonic RZ31KU Overview Detail Clarity Processor 5 clarifies and enhances fine details with advanced processing algorithm
Panasonic RZ31KU Overview System Daylight View 3 improves color perception in bright environments and in mapping applications
Panasonic RZ31KU Overview Quiet operation with original cooling technology Versatile System
Panasonic RZ31KU Overview Free 360-degree installation (vertical and horizontal)
Shares optional lenses with Panasonic 3-Chip DLP projector family
Panasonic RZ31KU Overview DIGITAL LINK supports transmission of uncompressed full HD video and control commands through a single CAT 5e or higher STP cable for distance up to 492 (150m)
Panasonic RZ31KU Overview Multiple projector stacking available without frame Convenient one-box design
Multi-screen support system seamlessly connects multiple screens
Multi-Unit brightness and color control Geometry Manager Pro Panasonic RZ31KU Specs Image Display Display System 0.96″ DLP
Panasonic RZ31KU Overview Native Chip Resolution 1920 x 1200 (WUXGA) Maximum Brightness 31,000 Lumens Uniformity 90%
Panasonic RZ31KU Overview Aspect Ratio 4:3
Panasonic RZ31KU Overview Horizontal 15 to 100 kHz
Panasonic RZ31KU Overview Vertical 24 to 120 kHz Lens
Projection Size 70 1000″ / 177.80 – 2540.00 cm Features Keystone Correction
Projection Size Vertical 40
Projection Size Horizontal 15 Ceiling Mountable Yes Rear Screen Projection Yes Inputs/Outputs
Projection Size 1 x Composite (BNC) Video Input, x DVI-D Video Input, x VGA (DE-15/DB-15) Video Input, x DE-9/DB-9 Video Input, x DE-9/DB-9 Video Output
1 x HDMI (HDMI Type-A) Video Input
Projection Size 5 x Composite (BNC) Video Input
Projection Size 2 x Composite (BNC) Video Output
1 x USB 2.0 (USB Type-B) Power Output General
Projection Size Dimensions (W x H x D) 27.6 x 16.5 x 49.2″ / 700.0 x 418.0 x 1250.0 mm with protrusion parts Weight 174 lb / 78.92 kg
SKU PT-RZ31KU
Brand Panasonic
MPN PTRZ31KU
GTIN 00885170287372, 885170287372
UPC 885170287372
