DMX lighting control software With Wired Digital comm Network

ADJ myDMX 5 combines DMX lighting software and hardware for PC and Mac with a library of over 20,000 lighting fixture profiles. Its workflow centers on timeline-based scene building, flexible effects, a live mixer, music synchronization, and mobile control. The system helps users assemble larger, precisely timed light shows while keeping playback controls accessible during operation.

Ideal Use Cases

myDMX 5 is suited to users who need to program layered lighting scenes, run them live, or provide an approachable control surface for an installation. Super Scene timelines are useful when several source scenes must work together in an exact sequence, while scene segments and the GO button support cue-by-cue playback. Mobile control through iPhone, iPad, or Android devices fits installations and workflows where the main computer is not the preferred control point. Music-driven shows can follow BPM through tap-tempo, MIDI clock, or Ableton Link, and line-in audio can make lighting react to the music pulse.

Why Choose This Model

The extensive fixture profile library gives programmers more than 20,000 profiles to select from. Within the software, Super Scene combines different scenes on a single timeline; if a source scene changes, the related Super Scene updates automatically. New FX can create effects on any type of channel, map them in 2D, and combine an unlimited number of effects on a Super Scene timeline. Live Mixer places group dimmer control in the mixer rack and also provides access to strobe, blinder, and colour changes. Together, these tools cover detailed preparation and immediate live adjustment.

Installation and Integration

Use myDMX 5 with a PC or Mac and shape the control layout around the operator. Mapping mode lets any control be linked to a keyboard, MIDI controller, or DMX console in one click. A custom screen can be built for a touchscreen, while the myDMX Remote app allows customized controls such as buttons, faders, and colour wheels on iOS or Android tablets and smartphones over WiFi. The RJ45 socket is an alternative to USB and does not output Art-Net. That same socket allows the device to be controlled in Stand-Alone mode with the myDMX 5 Remote app on iPhone, iPad, or Android, an important detail when planning the connection and control path.

Performance Highlights

During playback, live rotary encoders for each scene provide direct control of dimmer, speed, phase shift, and size. Scenes can run forwards, backwards, or in both directions. They can also be divided into segments for jumps triggered with a GO button or BPM. For music synchronization, users can set BPM with tap-tempo, receive MIDI clock, connect through Ableton Link, or react to a line-in audio pulse. Scenes can be divided into a chosen number of beats to align with more difficult tempos. Fixture limits add another layer of show control: maximum movement can be restricted so beams stay within a selected area, and minimum and maximum dimming can be adjusted for each fixture across the entire show.

What Makes It Different

What distinguishes myDMX 5 is how its programming, playback, and remote-control features connect. A change to a source scene flows into its Super Scene automatically. Effects can be layered without a quantity limit and positioned through 2D mapping. The same project can then be shaped in Live Mixer, performed with scene-level rotary encoders, synchronized to multiple music timing sources, and presented through a customized touch or mobile layout. Mapping mode further extends hands-on control to keyboards, MIDI controllers, and DMX consoles. The RJ45 limitation is also clear: it offers an alternative to USB and supports Stand-Alone app control, but it is not an Art-Net output.

Final Assessment

ADJ myDMX 5 brings together a large fixture profile library, precise Super Scene sequencing, broad effect creation, live mixing, configurable playback, and several ways to synchronize with music. Its custom touch layouts and iOS or Android remote app make the control experience adaptable, while fixture movement and dimming limits help keep programmed output within chosen boundaries. For buyers comparing control paths, the key point is that RJ45 provides an alternative connection and Stand-Alone remote capability, not Art-Net output.
