Vertiv Avocent Cybex SC945DPH Overview

Monitor and manage multiple computers from a single mouse and keyboard setup while ensuring information is secure with the Vertiv SC945DPH Cybex Secure DPH KVM Switch. Designed to offer flexibility without compromising sensitive data of security conscious organizations, the SC945DPH isolates each connected system, providing unidirectional data flow to keep information safe.

Universal interfaces combine DisplayPort and HDMI ports so you can easily connect and control up to four systems from a single setup. The SC945DPH supports a max resolution up to 3840 x 2160 at 60 Hz refresh rate on two displays, giving you a clean and clear picture. Host and console connections also have a 3.5mm audio jack so you can listen to various alerts and notifications. Additionally, the SC945DPH has active intrusion detection and tamper-evident labels to notify you if the device has been accessed and manipulated on a hardware level.

Security Design

The SC945DPH KVM switch offers a variety of security features designed to protect your organization. Unidirectional optical data diodes ensure data flows in only one direction, while protected video display emulators eliminate potential data leakage from the display to the computer. Active intrusion detection and tamper-evident labels ensure hardware has not been accessed and manipulated on a hardware level.

Flexible Design

Designed with flexibility in mind, the SC945DPH includes a wide range of connections that work seamlessly with your setup. Universal video ports support DisplayPort and HDMI connections along with DVI-D via optional adapter. Freeze audio channel locks the connected audio channel to the computer to prevent sound crossover.

Switching Capabilities

The front of the SC945DPH offers easy switching with LED push buttons that notify you when a computer is connected, and which one is selected. Cursor navigation switching assists with transitions between computers by allowing you to press the left CTRL key and moving your cursor across screen borders.

Device Support

Each unit is equipped with two USB 2.0 Type-A console ports for your main console’s mouse and keyboard. The SC945DPH also supports touch-screens, smart-card systems, and biometric readers.

Certifications

The SC945DPH is TAA certified, allowing you to install this device in various organizations where data security is a high priority. This device is also developed in accordance with the National Information Assurance Partnership (NIAP) protection profile v4.0, allowing it to be used in commercial environments and provide adequate cybersecurity protocols.

Dedicated Peripheral Port

Dedicated Peripheral Ports (DPP) offer a secure connection to external USB authentication devices and independently lock the channel to the specific computer to prevent information crossover.
