Display System 3-Chip 1″ LCD
Native Resolution 1920 x 1200
Maximum Brightness White: 10,000 Lumens (ISO) Color: 10,000 Lumens
HDR Support No
Inputs/Outputs 1x RJ45 (HDBaseT) Audio, Control, Data, LAN, Video 1x HDMI Audio, Video Input 1x DVI-D Video Input 1x 5BNC Video Input 1x DE-15/DB-15 (VGA) Video Input 1x DE-15/DB-15 (VGA) Video Output 1x USB-A 2.0 Data 1x USB-B 2.0 Service Input 1x DE-9/DB-9 (RS-232) Control 1x RJ45 (Ethernet) LAN
Light Source Laser Phosphor
Supported Resolutions Maximum: 1920 x 1200
Aspect Ratio Native: 16:10
Scan Horizontal: 15 to 92kHz Vertical: 48 to 92Hz
Includes Lens No
Ceiling Mountable Yes
HDCP Support Yes, Version 1.4
Number of Expansion Slots 1
Mobile App Compatible No
Wireless LAN / Wi-Fi No
Bluetooth No
Expected Lamp Life Medium Brightness: 20,000 Hours
Fan Noise Full Brightness: 39 dB
Security Cable Lock Slot Security Bar
Input Power 100 to 240 VAC, 50 / 60 Hz at 3.4 to 8.4 A
Power Consumption Full Brightness: 840 W Standby Mode (Lamp Off): 0.5 W
Operating Conditions 32 to 77 F / 0 to 45 C at 20 to 80% Humidity
Storage Conditions 14 to 140 F / -10 to 60 C at 20 to 80% Humidity
Dimensions (W x H x D) 21.4 x 8.1 x 22.2″ / 544.0 x 205.0 x 564.0 mm (Without Protrusions)
Weight 58 lb / 26.31 kg
Package Weight 73 lb
Box Dimensions (LxWxH) 29 x 28.75 x 15.5″
The VPL-FHZ101L/W features HDBaseT, VGA, DVI-D, 5BNC, and HDMI inputs for connecting to nearly any source as well as a VGA output for passing video through the projector to another projector or display. The projector is controllable by various popular control systems via HDBaseT, RS-232, or the included remote control.
Sony VPLFHZ101L Overview Designed to Provide Bright Image in Large Venues
The 10,000-lumen brightness output helps ensure big-screen presentations with extra presence, even in brightly lit rooms. Reality Creation Technology
Sony VPLFHZ101L Overview Image quality is boosted by Sony’s Reality Creation technology, which uses a pattern-matching database to optimize low-resolution images, enhancing clarity without increasing digital picture noise.
Sony VPLFHZ101L Overview The laser light source provides up to 20,000 hours of operation without lamp replacement, reducing maintenance needs when compared to lamp-based projectors. Brightness is also maintained through the light source’s lifespan.
The VPL-FHZ101L/W is suitable for integration in A/V environments with popular control, monitoring, and management systems like Crestron Connected and Extron XTP Systems. Edge Blending
Seamlessly join color-matched images from multiple projectors for super-sized displays in corporate and education environments.
Enjoy enhanced projector position flexibility thanks to the generous lens shift range. Designed to Blend In
Lens Shift The projector features a flat-top surface to help it discreetly blend into nearly any space when it’s mounted to the ceiling.
Lens Position Memory Store and recall up to six settings for projected image size, position, and aspect ratio, saving time in different environments. This feature exclusively works with the VPLL-Z4111 lens option.
A variety of lens options let you customize the projector to suit virtually any size room and throw requirements. A quick release bayonet mount helps simplify lens exchange. Additional Features BrightEra LCD panels
Designed for Easy Lens Swapping Powered or manual focus and zoom, depending on lens used 10,000-hour maximum filter replacement cycle
Designed for Easy Lens Swapping Infinite dynamic contrast ratio
Meets 100% of the sRGB color space in sRGB Mode Up to 30 of horizontal and vertical keystone correction, depending on lens used
Slot for optional BKM-PJ20 3G-SDI input adapter HTML viewer
Designed for Easy Lens Swapping Automatic standby mode activates after approximately two minutes Sony VPLFHZ101L Specs Key Specs Display System 3-Chip 1″ LCD
Designed for Easy Lens Swapping Native Resolution 1920 x 1200 Maximum Brightness
Designed for Easy Lens Swapping White 10,000 Lumens (ISO)
Designed for Easy Lens Swapping Color 10,000 Lumens
1x RJ45 (HDBaseT) Audio, Control, Data, LAN, Video
HDR Support No Inputs/Outputs 1x HDMI Audio, Video Input
1x 5BNC Video Input 1x DE-15/DB-15 (VGA) Video Input, DE-15/DB-15 (VGA) Video Output
1x USB-A 2.0 Data
1x USB-B 2.0 Service Input 1x DE-9/DB-9 (RS-232) Control
1x RJ45 (Ethernet) LAN Light Source Laser Phosphor Image Display Display System 3-Chip 1″ LCD, LAN HDCP Support Yes, Version 1.4 Number of Expansion Slots 1 Hardware Mobile App Compatible No
1x 5BNC Video Input Native Resolution 1920 x 1200 Supported Resolutions
1x 5BNC Video Input Maximum 1920 x 1200 Maximum Brightness
1x 5BNC Video Input White 10,000 Lumens (ISO)
1x 5BNC Video Input Color 10,000 Lumens
Aspect Ratio Native 16:10 Scan
Aspect Ratio Horizontal 15 to 92kHz
Aspect Ratio Vertical 48 to 92Hz Includes Lens No Features
Aspect Ratio HDR Support No Ceiling Mountable Yes
Input/Output Connectors Inputs/Outputs 1x HDMI Audio, Video Input
1x 5BNC Video Input Wireless LAN / Wi-Fi No Bluetooth No General Light Source Laser Phosphor Expected Lamp Life
1x 5BNC Video Input Medium Brightness 20,000 Hours
Fan Noise Full Brightness 39 dB Security Cable Lock Slot Security Bar
Fan Noise Input Power 100 to 240 VAC, 50 / 60 Hz at 3.4 to 8.4 A
Power Consumption Full Brightness 840 W
Standby Mode (Lamp Off) 0.5 W
Power Consumption Operating Conditions 32 to 77 F / 0 to 45 C at 20 to 80% Humidity Storage Conditions 14 to 140 F / -10 to 60 C at 20 to 80% Humidity
Power Consumption Dimensions (W x H x D) 21.4 x 8.1 x 22.2″ / 544.0 x 205.0 x 564.0 mm (Without Protrusions) Weight 58 lb / 26.31 kg Packaging Info Package Weight 73 lb
Power Consumption Box Dimensions (LxWxH) 29 x 28.75 x 15.5″
SKU VPLFHZ101L-W
