Display Size 55"
Native Resolution 1920 x 1080, 1920 x 1080 Maximum Brightness 500 nits / cd/m 2 (Sustained) A/V Inputs
Maximum Brightness 500 nits / cd/m 2 (Sustained)
A/V Inputs 2x HDMI 2.0 1x DisplayPort 1.2 1x DVI-D 1x 1/8" / 3.5 m, 2x HDMI 2.0 1x DisplayPort 1.2 1x DVI-D 1x 1/8" / 3.5 mm
Panel Type IPS-Type LCD
Aspect Ratio 16:9
HDR Support No
Contrast Ratio 1200:1
Refresh Rate 60 Hz
Color Gamut 72% NTSC
Viewing Angle (H x V) 178 x 178
Finish Anti-Glare
A/V Outputs 1x DisplayPort 1.2 1x 1/8" / 3.5 mm (Analog Audio)
HDCP Support Yes
USB I/O 1x USB-A 2.0
Ethernet I/O 1x RJ45 (Unspecified Ethernet)
Other I/O 1x 1/8" / 3.5 mm Serial (RS-232C) Input 1x 1/8" / 3.5 mm Serial (RS-232C) Output 1x 1/8" / 3.5 mm IR Input 1x 1/8" / 3.5 mm IR Output
Built-In Speakers No
Smart TV No
Power Consumption Maximum: 220.0 W Typical: 165.0 W Standby: 0.5 W
Input Power 100 to 240 VAC, 60 / 50 Hz
Power Adapter Type Internal
Operating Conditions 32 to 104 F / 0 to 40 C at 10 to 80% Humidity
Certifications UL60950-1
VESA Mounting-Hole Pattern 600 x 400 mm
Environmental Resistance Dust-Resistant (IP5X)
Bezel Thickness 2.25 mm (Top/Left) 1.25 mm (Right/Bottom) 3.5 mm (Bezel-to-Bezel)
Duty Cycle 24 Hours / 7 Days
Dimensions 47.8 x 26.9 x 2.9" / 1213.5 x 684.3 x 73.1 mm
Weight 42.8 lb / 19.4 kg
Package Weight 62 lb
Box Dimensions (LxWxH) 54.38 x 22.63 x 9.88"
Samsung video walls provide an impressive UHD viewing experience with minimal effort. With a daisy chain design utilizing DisplayPort 1.2 and HDMI ports, the VMB-R display can project UHD content across multiple screens up - to 5 x 5 - without requiring an external graphic card or UHD splitters. Key Specs Display Size 55"
2x HDMI 2.0 1x DisplayPort 1.2 1x DVI-D 1x 1/8" / 3.5 m Display Display Size 55" Panel Type
IPS-Type LCD Aspect Ratio 16:9
IPS-Type LCD Native Resolution 1920 x 1080 Maximum Brightness 500 nits / cd/m 2 (Sustained)
HDR Support No Contrast Ratio 1200:1
Refresh Rate 60 Hz Color Gamut 72% NTSC Viewing Angle (H x V) 178 x 178 Finish Anti-Glare Connectivity A/V Inputs
Refresh Rate 60 Hz 2x HDMI 2.0 1x DisplayPort 1.2 1x DVI-D 1x 1/8" / 3.5 mm A/V Outputs 1x DisplayPort 1.2 1x 1/8" / 3.5 mm (Analog Audio) HDCP Support Yes
1x USB-A 2.0
USB I/O Ethernet I/O 1x RJ45 (Unspecified Ethernet) Other I/O 1x 1/8" / 3.5 mm Serial (RS-232C) Input 1x 1/8" / 3.5 mm Serial (RS-232C) Output 1x 1/8" / 3.5 mm IR Input 1x 1/8" / 3.5 mm IR Output Speaker Built-In Speakers No Hardware Smart TV No Electrical
Power Consumption Maximum 220.0 W
Power Consumption Typical 165.0 W
Power Consumption Standby 0.5 W
Power Consumption Input Power 100 to 240 VAC, 60 / 50 Hz
Power Adapter Type Internal General Operating Conditions 32 to 104 F / 0 to 40 C at 10 to 80% Humidity Certifications UL60950-1 VESA Mounting-Hole Pattern 600 x 400 mm Environmental Resistance Dust-Resistant (IP5X) Bezel Thickness 2.25 mm (Top/Left) 1.25 mm (Right/Bottom) 3.5 mm (Bezel-to-Bezel) Duty Cycle 24 Hours / 7 Days Dimensions 47.8 x 26.9 x 2.9" / 1213.5 x 684.3 x 73.1 mm Weight 42.8 lb / 19.4 kg Packaging Info Package Weight 62 lb
Power Adapter Type Internal General Box Dimensions (LxWxH) 54.38 x 22.63 x 9.88"
SKU VM55B-U
Brand Samsung
MPN VM55B-U
GTIN 00887276652610, 887276652610
UPC 887276652610
