• Projects an image from 40 to 300″ in size
• webOS 6.0 signage platform
• Wi-Fi and Bluetooth connectivity
• Three HDMI and one DisplayPort inputs
• Two USB-A ports
• Two RJ45 and 1 x HDBaseT ports
• Dual 5W speakers built-in
• PiP and PbP
• LG One:Quick Share
• Crestron RoomView
• 9x linear tile mode
• Supports daisy chaining
• 360° installation
• IP control

• Brightness of 7000 Lumens
• UHD 4K 3840 x 2160 Native Resolution
• 1.53 to 2.45:1 Throw Ratio
• 3 HDMI, 1 DisplayPort & 2 RJ45 Ports
• Wi-Fi & Bluetooth Connectivity
• Automatic Screen Adjustment
• Landscape or Portrait Screen Rotation
• Edge Blending for Multiple Projectors
• webOS 6.0 Signage Platform
• Projects a 40 to 300″ Image

Specifications

Key Specs
Native Resolution 3840 x 2160
Maximum Brightness 7000 Lumens (ANSI)
Throw Ratio 1.53 to 2.45:1
Projection Size 40 to 300″ / 1.0 to 7.6 m
HDR Support Yes,
Inputs/Outputs
3x HDMI 2.0 Audio, Video Input
1x HDMI Audio, Video Output
1x DisplayPort Audio, Video Input
2x USB-A 2.0 Data Input/Output
2x RJ45 (Ethernet) LAN Input/Output
1x RJ45 (HDBaseT) LAN Input/Output
1x DE-9/DB-9 (RS-232) Control Input/Output
1x 1/8″ / 3.5 mm Mini Remote Input
1x 1/8″ / 3.5 mm Mini Audio Input
Light Source Laser Phosphor

Image Display
Native Resolution 3840 x 2160
Maximum Brightness 7000 Lumens (ANSI)
Aspect Ratio 16:9
Dynamic Contrast Ratio 3,000,000:1

Lens
Includes Lens Yes
Focus Auto
Lens Shift
Vertical: -33 to 60%
Horizontal: ± 28%
Optical Zoom Powered: 1.6x
Throw Ratio 1.53 to 2.45:1
Projection Size 40 to 300″ / 1.0 to 7.6 m

Features
Keystone Correction Auto:
HDR Support Yes,
Multi-Input Support (PIP/PBP) Picture-in-Picture (PIP), Picture-by-Picture (PBP)
Built-In Speaker Yes (Stereo)
Speaker Power 10 W

Input/Output Connectors
Inputs/Outputs
3x HDMI 2.0 Audio, Video Input
1x HDMI Audio, Video Output
1x DisplayPort Audio, Video Input
2x USB-A 2.0 Data Input/Output
2x RJ45 (Ethernet) LAN Input/Output
1x RJ45 (HDBaseT) LAN Input/Output
1x DE-9/DB-9 (RS-232) Control Input/Output
1x 1/8″ / 3.5 mm Mini Remote Input
1x 1/8″ / 3.5 mm Mini Audio Input
HDCP Support Not Specified by Manufacturer

Hardware
Operating System webOS 6.0
Mobile App Compatible No
Wireless LAN / Wi-Fi Yes, Built-in
Bluetooth Yes

General
Light Source Laser Phosphor
Expected Lamp Life Full Brightness: 20,000 Hours
Fan Noise
Full Brightness: 35 dB
Low Brightness: 31 dB
Power Consumption
Full Brightness: 500 W
Standby Mode (Lamp Off): < 0.5 W
Dimensions (W x H x D) 22.4 x 6.3 x 14.2″ / 570.0 x 160.0 x 360.0 mm
Weight 39 lb / 17.7 kg

Packaging Info
Package Weight 45 lb
Box Dimensions (LxWxH) 30 x 18.5 x 10.25″
