Display System 3-Chip 0.62″ Polysilicon TFT LCD
Native Chip Resolution 1920 x 1080 (Full HD)
Supported Resolutions Maximum: 4K UHD – 3840 x 2160
Maximum Brightness White: 1000 Lumens Color: 1000 Lumens
Aspect Ratio Native: 16:9 Supported: 4:3
Dynamic Contrast Ratio 200,000:1
Color Depth 8-Bit (16.78 Million Colors)
Focus Auto
Lens f/2 (f = 13.9 mm)
Optical Zoom None
Throw Ratio 1:1
Projection Size 30 – 150″ / 76.2 – 381.0 cm
Keystone Correction Vertical: 34 Horizontal: 40
Supported HDR Input Formats HDR10, Hybrid Log Gamma
Ceiling Mountable Yes
Rear Screen Projection Yes
Built-In Speaker Yes (Stereo)
Speaker Power 5W
Inputs/Outputs 2 x HDMI (HDMI Type-A) Audio, Video Input 1 x 1/8″ / 3.5 mm Mini Audio Output 1 x USB 2.0 (USB Type-A) Audio, Data, Power, Service, Video 1 x USB 2.0 (Mini-USB) Service Input
HDCP Support Version 2.3
Virtual Assistant Support Google Assistant
Operating System Android TV
Wireless LAN / Wi-Fi Yes, Built-in
Bluetooth 5.0, connectivity lets you use the projector as a standalone wireless speaker
Light Source Laser Phosphor
Expected Lamp Life Medium Brightness: 20,000 Hours
Fan Noise Full Brightness: 27 dB Low Brightness: 22 dB
Security Cable Lock Slot
AC Input Power 100 to 240 VAC, 50 / 60 Hz
Power Consumption Full Brightness: 102 W Low Brightness: 73 W
Operating Temperature 41 to 86 F / 5 to 30 C
Dimensions (W x H x D) 6.9 x 5.3 x 6.9″ / 17.5 x 13.5 x 17.5 cm Including Feet
Weight 4.7 lb / 2.1 kg
Package Weight 7.355 lb
Box Dimensions (LxWxH) 11.2 x 9.7 x 9.6″
The onboard speaker system was designed by Yamaha to provide a powerful performance
The Android TV operating system is embedded and features voice search via the built-in Google Assistant and lets you watch streaming apps like Hulu, HBO, YouTube, and live TV via apps like YouTube TV
Chromecast built-in enables you to wirelessly cast content directly from your compatible smartphone, tablet, or computer, including popular Android and Apple devices
Scene Adaptive Color Correction helps produce a clear, natural picture for nearly all your content 3LCD technology displays 100% of the RGB color signal for every frame for accurate color while maintaining color brightness
10-bit color processing
ARC via HDMI 2
USB Type-A port supports thumb drives, mic, HID, and web cameras
Android TV supports resolutions up to Full HD at 60 fps with 4:4:4 color
Dynamic, Vivid, Bright Cinema, Natural, and Cinema color modes RoHS compliant Recyclable design Key Features
Color & White Brightness of 1000 Lumens
1:1 Throw Ratio
Wi-Fi 5, Bluetooth, Chromecast built-in
Analog Audio Output USB Port for Multimedia Playback Built-In Stereo 5W Speaker Includes Remote Control Epson EF-12 Specs Image Display Display System 3-Chip 0.62″ Polysilicon TFT LCD
Analog Audio Output Native Chip Resolution 1920 x 1080 (Full HD) Supported Resolutions
Analog Audio Output Maximum 4K UHD – 3840 x 2160 Maximum Brightness
Analog Audio Output White 1000 Lumens
Analog Audio Output Color 1000 Lumens
Aspect Ratio Native 16:9
Aspect Ratio Supported 4:3
Aspect Ratio Color Depth 8-Bit (16.78 Million Colors) Lens Focus Auto Lens f/2 (f = 13.9 mm) Optical Zoom None
Aspect Ratio Throw Ratio 1:1
Projection Size 30 150″ / 76.2 – 381.0 cm Features Keystone Correction
Projection Size Vertical 34
Projection Size Horizontal 40
Supported HDR Input Formats HDR10, Hybrid Log Gamma Ceiling Mountable Yes Rear Screen Projection Yes Built-In Speaker Yes (Stereo) Speaker Power 5W
2 x HDMI (HDMI Type-A) Audio, Video Input 1 x 1/8″ / 3.5 mm Mini Audio Output
1 x USB 2.0 (USB Type-A) Audio, Data, Power, Service, Video, 2.0 (Mini-USB) Service Input HDCP Support Version 2.3 Hardware Virtual Assistant Support Google Assistant
Operating System Android TV Wireless LAN / Wi-Fi Yes, Built-in Bluetooth 5.0 General Light Source Laser Phosphor Expected Lamp Life
Operating System Android TV Medium Brightness 20,000 Hours
Fan Noise Full Brightness 27 dB
Fan Noise Low Brightness 22 dB Security Cable Lock Slot
Fan Noise AC Input Power 100 to 240 VAC, 50 / 60 Hz
Power Consumption Full Brightness 102 W
Power Consumption Low Brightness 73 W
Power Consumption Operating Temperature 41 to 86 F / 5 to 30 C
Power Consumption Dimensions (W x H x D) 6.9 x 5.3 x 6.9″ / 17.5 x 13.5 x 17.5 cm Including Feet Weight 4.7 lb / 2.1 kg Packaging Info Package Weight 7.355 lb
Power Consumption Box Dimensions (LxWxH) 11.2 x 9.7 x 9.6″
SKU EF12
Brand Epson
MPN V11HA14020
GTIN 00010343959217, 010343959217
UPC 010343959217
