Screen Size (Diagonal) 86″
Resolution 3840 x 2160
Panel Type LCD
Brightness 400 cd/m (Typical)
Viewing Angle (H x V) 178 x 178
Aspect Ratio 16:9
Contrast Ratio 1200:1
Primary Connectivity Location Display
Input Ports 4 x HDMI Audio, Video 1 x 15-Pin VGA Video 1 x RCA Stereo (L/R) Audio
Output Ports 1 x TOSLINK Optical Audio 1 x 1/8″ / 3.5 mm Audio
USB Ports 2 x USB (Version Unspecified) Type-A 1 x USB (Version Unspecified) Type-C
Ethernet Ports 1
Control RS-232C via DE-9/DB-9 Input IR via 1/8″ / 3.5 mm Input
Wi-Fi With Included Hardware (Wi-Fi 4 (802.11n))
Display Orientation Landscape
HDCP Support Yes, Version 2.2
Haze Level 3%
Built-In Speakers Yes, 2 x 12 W
Speaker Configuration 2-Channel
AC Input Power 110 to 127 VAC, 50 / 60 Hz
Wall Mounting 600 x 400 mm
Duty Cycle 16 Hours
Dimensions 75.9 x 43.3 x 3.1″ / 1929.0 x 1100.0 x 80.0 mm
Weight 136.1 lb / 61.7 kg
1200 1 Typical Contrast Ratio
1200:1 Typical Contrast Ratio Wi-Fi Adapter Included Suitable for 16-Hour/Day Use Panasonic CQE1W Specs Display
Panasonic CQE1W Overview Screen Size (Diagonal) 86″ Resolution 3840 x 2160 Panel Type LCD Brightness 400 cd/m (Typical) Viewing Angle (H x V) 178 x 178
Panasonic CQE1W Overview Aspect Ratio 16:9
Panasonic CQE1W Overview Contrast Ratio 1200:1 Connectivity
4 x HDMI Audio, Video 1 x 15-Pin VGA Video 1 x RCA Stereo (L/R) Audio
Input Ports Output Ports 1 x TOSLINK Optical Audio 1 x 1/8″ / 3.5 mm Audio
2 x USB (Version Unspecified) Type-A
1 x USB (Version Unspecified) Type-C
USB Ports Ethernet Ports 1 Control RS-232C via DE-9/DB-9 Input IR via 1/8″ / 3.5 mm Input Wi-Fi With Included Hardware (Wi-Fi 4 (802.11n)) General Display Orientation Landscape HDCP Support Yes, Version 2.2 Surface Haze Level 3% Audio Built-In Speakers Yes, 2 x 12 W Speaker Configuration 2-Channel Electrical
USB Ports AC Input Power 110 to 127 VAC, 50 / 60 Hz Physical Wall Mounting 600 x 400 mm Duty Cycle 16 Hours Dimensions 75.9 x 43.3 x 3.1″ / 1929.0 x 1100.0 x 80.0 mm Weight 136.1 lb / 61.7 kg
SKU TH-86CQE1W
