Screen Size (Diagonal) 65″
Resolution 3840 x 2160
Panel Type VA LCD
Brightness 350 cd/m (Typical)
Viewing Angle (H x V) 178 x 178
Screen Area 56.22 x 31.61″ / 1428 x 803 mm
Aspect Ratio 16:9
Contrast Ratio 4000:1
Response Time 8 ms (GtG)
Pixels Per Inch (ppi) 68 ppi
Primary Connectivity Location Display
Input Ports 2 x HDMI Video 1 x 1/8″ / 3.5 mm Video 1 x DVI-D Video 1 x VGA 15-Pin Video
Output Ports 1 x 1/8″ / 3.5 mm Audio
USB Ports 1 x USB (Version Unspecified) Type-A – Service
Ethernet Ports 1
Control IR via 1/8″ / 3.5 mm Input IR via 1/8″ / 3.5 mm Output RS-232C via DE-9/DB-9 Input
Other I/O 1 x 1/8″ / 3.5 mm IR Input 1 x 1/8″ / 3.5 mm IR Output 1 x RS-232C Control Input
Digital Media Slot None
HDCP Support Yes, Version 2.2
Built-In Speakers Yes, 2 x 10 W
Power Consumption Operational: 185.0 W Standby: 0.5 W
AC Input Power 100 to 240 VAC, 50 / 60 Hz
Operating Temperature 32 to 104 F / 0 to 40 C
Operating Humidity 20 to 80%
Operating Altitude 4593.18 to 9186′ / 1400 to 2800 m
Wall Mounting 400 x 400 mm
Bezel Thickness 13.5 mm (Right/Top/Left) 14.5 mm (Bottom)
Dimensions 57.4 x 32.9 x 3.2″ / 1459.0 x 835.0 x 82.0 mm
Weight 59.52 lb / 27 kg
Package Weight 105 lb
Box Dimensions (LxWxH) 64 x 42 x 11″
4000 1 Contrast Ratio
Panasonic EQ1U Overview USB media player port
Panasonic EQ1U Overview Use USB memory stick (available separately) to operate self-made signage
Panasonic EQ1U Overview Display complicated drawings or detailed materials in an easy-to-read manner
Images of materials can be refreshed in real-time during a conference Slim design
Panasonic EQ1U Overview Failover and Failback safeguards for mission critical situations
Panasonic EQ1U Overview Use the remote control to edit the playlist without a PC
Panasonic EQ1U Overview Timer-programmable switching of device connection SNMP version 1-3 compatible
Panasonic EQ1U Overview Content Management Software for PC version 3.2 enables easy playlist creation with media support including combinations of still and video images
Panasonic EQ1U Overview Multi-monitoring and control software
18 hours a day operating time Supports CEC over HDMI Key Features 4K UHD 3840 x 2160 Resolution 350 cd/m Brightness
4000:1 Contrast Ratio 178 Viewing Angles
Panasonic EQ1U Overview HDMI, 3.5mm, DVI-D & VGA Ports RS-232 & IR Control
RJ45 Ethernet Port USB 3.0 Port Two 10W Speakers 400 x 400mm VESA Mounting Panasonic EQ1U Specs Display
RJ45 Ethernet Port Screen Size (Diagonal) 65″ Resolution 3840 x 2160 Panel Type VA LCD Brightness 350 cd/m (Typical) Viewing Angle (H x V) 178 x 178 Screen Area 56.22 x 31.61″ / 1428 x 803 mm
RJ45 Ethernet Port Aspect Ratio 16:9
RJ45 Ethernet Port Contrast Ratio 4000:1 Response Time 8 ms (GtG) Pixels Per Inch (ppi) 68 ppi Connectivity
2 x HDMI Video 1 x 1/8″ / 3.5 mm Video 1 x DVI-D Video 1 x VGA 15-Pin Video
Input Ports Output Ports 1 x 1/8″ / 3.5 mm Audio
1 x USB (Version Unspecified) Type-A Service
USB Ports Ethernet Ports 1 Control IR via 1/8″ / 3.5 mm Input IR via 1/8″ / 3.5 mm Output RS-232C via DE-9/DB-9 Input Other I/O 1 x 1/8″ / 3.5 mm IR Input 1 x 1/8″ / 3.5 mm IR Output 1 x RS-232C Control Input Digital Media Slot None General HDCP Support Yes, Version 2.2 Audio Built-In Speakers Yes, 2 x 10 W Electrical
Power Consumption Operational 185.0 W
Power Consumption Standby 0.5 W
Power Consumption AC Input Power 100 to 240 VAC, 50 / 60 Hz Environmental
Power Consumption Operating Temperature 32 to 104 F / 0 to 40 C
Power Consumption Operating Humidity 20 to 80%, Altitude 4593.18 to 9186′ / 1400 to 2800 m Physical Wall Mounting 400 x 400 mm Bezel Thickness 13.5 mm (Right/Top/Left) 14.5 mm (Bottom) Dimensions 57.4 x 32.9 x 3.2″ / 1459.0 x 835.0 x 82.0 mm Weight 59.52 lb / 27 kg Packaging Info Package Weight 105 lb
Power Consumption Box Dimensions (LxWxH) 64 x 42 x 11″
SKU TH-65EQ1U
Brand Panasonic
MPN TH-65EQ1U
GTIN 00885170338395, 885170338395
UPC 885170338395
