Introducing the NETGEAR AV Line of M4250 Switches, developed and engineered for audio/video professionals with dedicated service and support. M4250 has been built from the ground up for the growing AV over IP market, combining years of networking expertise in AV with M4300 and M4500 series with best practices from leading experts in the professional AV market. AV codecs generally use 1Gbps or 10Gbps per stream and the AV Line of M4250 targets the widespread 1Gbps codecs.

PoE+, Ultra90 PoE++ and rear-facing ports ensure a clean integration in AV racks. M4250 switches come pre-configured for standard audio and video signals. When requirements are more specific, an AV user interface offers customization with port-based profiles. For audio Dante, Q-SYS and AES67 profiles are available, as well as an AVB profile requiring an AVB license sold separately. For video the M4250 offers profiles for NVX, AMX, Q-SYS, NDI, Dante etc. as well as audio/ video/control mixed profiles. When multiple switches are used, NETGEAR IGMP PlusTM brings automation for you to just connect them together, or with M4300 and M4500 switches.

Extended AV features

• Dedicated AV web-based GUI interface for more specific AV installations
• Color-based AV profiles can be applied to the different ports
• Dante, Q-SYS, AES67 and AVB audio profiles
• AVB requires a license (sold separately
• NVX, SVSI, Q-SYS, NDI and Dante video profiles
• Audio / video / control mixed profiles
• Automatic switch interconnect with NETGEAR Auto-Trunk, Auto-LAG and IGMP Plus
• Common Layer 2 and Layer 3 switching engine across all M4250 models
• Built-in IT web GUI, console, telnet and SSH consistent with other NETGEAR M4300 and M4500 series
• Feature set includes static, RIP and PIM routing, DHCP Server and PTPv2

Audio Video Bridging (AVB) services

• AVB is one of the many features designed into the M4250 product line
• AVB is an industry standard for transporting content over a network
• AVB is used most often when very low latency is required such as in live performances when lip sync is critical
• All of the AV Line M4250 switches can be optionally licensed for AVB support

Other IT use cases

• Standard or recessed mounting with all ports in the back, or all ports in the front
• Fully featured L2/L3/L4 platform for midsize Enterprise campus networks, IoT and IPTV

Industry standard management

• Industry standard command line interface (CLI), main NETGEAR IT web interface (GUI), SNMP, sFlow and RSPAN
• Single-pane-of-glass NMS300 management platform with centralized firmware updates and massconfiguration support

Industry leading warranty

• NETGEAR M4250 series is covered under NETGEAR ProSAFE Limited Lifetime Hardware Warranty
• 90 days of Technical Support via phone and email, Lifetime Technical Support through online chat and Lifetime Next Business Day hardware replacement

Specifications

Key Specs
Inputs/Outputs
24x RJ45 Gigabit Ethernet PoE+ (30 W, 802.3at)
4x SFP+ 10 GbE
2x RJ45 Gigabit Ethernet LAN
2x USB-C
1x USB-A
Switching Bandwidth 132 Gb/s
PoE Power Budget 480 W

Protocols
Layer Services Supported Layer 2, Layer 3
Supported Protocols
DHCP Server
IGMP Snooping
IPv4
IPv6
Link Aggregation
Port Mirroring
Jumbo Frames Support 12,000 Bytes
MAC Address Table Size 16K

Security
Security Features
DHCP Snooping
DoS Attack Prevention
RADIUS Authentication
Storm Control

Performance
Latency 0.8 to 2.2 µs
Forwarding Rate 98.21 Mpps
Switching Bandwidth 132 Gb/s
Packet Buffer 16 Mb

Computer
CPU Quad-Core: Up to 1.8 GHz Cortex A57
Memory 2 GB

Electrical
PoE per Port 30 W
PoE Power Budget 960 W
Input Power 100 to 240 VAC, 50 / 60 Hz
Power Supply Type Internal

Environmental
Operating Temperature 32 to 77°F / 0 to 45°C
Operating Humidity 90%
Storage Temperature -4 to 158°F / -20 to 70°C
Storage Humidity 95%
Noise Level 59.0 dB (Active)

General
Certifications No
Cooling System Fan/Passive Combo
Indicator Lights Yes
Rack Mountable Yes 1 RU
Dimensions 17.3 x 15.7 x 1.7″ / 440 x 400 x 43.2 mm
Weight 13.91 lb / 6.31 kg

Packaging Info
Package Weight 18.86 lb
Box Dimensions (LxWxH) 21.2 x 18.2 x 4.8″
