Display System 3-Chip RGB Liquid Crystal Shutter Projection System LCD
Native Chip Resolution 1366 x 768 (HD)
On-Screen Resolution Up to Full HD (1920 x 1080) via Pixel-Shift Technology
Supported Resolutions Maximum: Full HD 1080p - 1920 x 1080
Maximum Brightness White: 5000 Lumens Color: 5000 Lumens
Aspect Ratio Native: 16:9 Supported: 16:10 Supported: 21:9 Supported: 4:3 Supported: 16:6
Dynamic Contrast Ratio 2,500,000:1
Color Depth 10-Bit Dithering (1.07 Billion Colors)
Focus Manual
Lens f/1.5 (f = 3.9 mm)
Optical Zoom None
Throw Distance 15.354 - 31.496" / 0.39 - 0.8 m
Throw Ratio 0.27 to 0.37:1
Projection Size 61 - 130" / 154.94 - 330.20 cm
Keystone Correction Manual-Vertical: 3 Manual-Horizontal: 3
Digital Zoom 1.35x
Built-In Speaker Yes
Projection Tilt Option Yes
Wireless LAN / Wi-Fi No, Optional Adapter Available
Light Source Laser Phosphor
Expected Lamp Life Full Brightness: 20,000 Hours Low Brightness: 30,000 Hours
Fan Noise Full Brightness: 36 dB Low Brightness: 27 dB
Security Cable Lock Slot Security Bar
AC Input Power 100 to 240 VAC, 50 / 60 Hz
Power Consumption Full Brightness: 381 W Low Brightness: 270 W Standby Mode (Lamp Off): 2 W
Operating Temperature 41 to 113 F / 5 to 45 C
Operating Humidity 20 to 80%
Dimensions (W x H x D) 18.1 x 9.0 x 17.7" / 46.0 x 22.9 x 45.0 cm
Weight 20.7 lb / 9.39 kg
Package Weight 28.855 lb
Box Dimensions (LxWxH) 24.6 x 20.2 x 13.4"
Epson 800F Overview The PowerLite 800F features HDBaseT, RCA, two VGA, and three HDMI inputs to support a variety of source devices. One VGA input can instead act as an output to daisy-chain multiple projectors or displays. An IR remote is included as an added convenience.
5000 lumens of color and white brightness provide bright images in settings with moderate ambient light
Full HD compatibility helps provide lifelike images up to 130" diagonal With a laser light engine designed to last up to 20,000 hours with no lamps to replace, the projector is virtually maintenance-free
HDBaseT, VGA, composite video, and three HDMI connectors provide a variety of connectivity options
Epson 800F Overview Direct playback function via USB
Ultra-short throw design projects large, easy-to-read images in small spaces 360 placement lets you mount or place the projector at nearly any position or angle, including portrait
Epson 800F Overview Remote management and control tools allow ease of access and maintenance
Mirror photos, videos, and apps with the optional wireless LAN adapter and Miracast or the Epson Creative Projection app for iOS, which lets you create, connect, and project customized effects for a variety of signage applications
Epson 800F Overview Enterprise level security encryption RoHS compliant Recyclable design Key Features
Pixel-Shift Full HD On-Screen Resolution Ultra-Short 0.27 to 0.37:1 Throw Ratio
Pixel-Shift Full HD On-Screen Resolution HDBaseT, VGA, Composite, 3x HDMI In, and RS-232 Controllable Remote Control Included Epson 800F Specs Image Display Display System
Pixel-Shift Full HD On-Screen Resolution HDMI Output, Selectable VGA Input/Output Laser Light Source Dual Built-In Speakers
Pixel-Shift Full HD On-Screen Resolution 3-Chip RGB Liquid Crystal Shutter Projection System LCD
Pixel-Shift Full HD On-Screen Resolution Native Chip Resolution 1366 x 768 (HD) On-Screen Resolution Up to Full HD (1920 x 1080) via Pixel-Shift Technology Supported Resolutions
Pixel-Shift Full HD On-Screen Resolution Maximum Full HD 1080p - 1920 x 1080 Maximum Brightness
Pixel-Shift Full HD On-Screen Resolution White 5000 Lumens
Pixel-Shift Full HD On-Screen Resolution Color 5000 Lumens
Aspect Ratio Native 16:9
Aspect Ratio Supported 16:10, 21:9, 4:3, 16:6
Aspect Ratio Color Depth 10-Bit Dithering (1.07 Billion Colors) Lens Focus Manual Lens f/1.5 (f = 3.9 mm) Optical Zoom None
Throw Distance Throw Ratio 0.27 to 0.37:1
Projection Size 61 130" / 154.94 - 330.20 cm Features Keystone Correction
Projection Size Manual-Vertical 3
Projection Size Manual-Horizontal 3 Digital Zoom 1.35x Built-In Speaker Yes
1 x HDBaseT (RJ45) Audio, Control, Data, LAN, Power, Video
3 x HDMI (HDMI Type-A) Audio, Video Input
1 x HDMI (HDMI Type-A) Audio, Video Output
Input/Output Connectors Inputs/Outputs 1 x VGA (DE-15/DB-15) Video Input, x VGA (DE-15/DB-15) Video Input/Output
1 x Composite (RCA) Video Input 3 x 1/8" / 3.5 mm Mini Audio Input
1 x Ethernet (1/8" / 3.5 mm Mini) Audio Output, (RJ45) LAN Input 1 x RS-232 (DE-9/DB-9) Control Input
1 x USB 2.0 (USB Type-A) Data Input, 2.0 (USB Type-A) LAN Input, 2.0 (USB Type-A) Power Output, 2.0 (USB Type-B) Control Output Hardware
Input/Output Connectors Inputs/Outputs Wireless LAN / Wi-Fi No, Optional Adapter Available General Light Source Laser Phosphor Expected Lamp Life
Input/Output Connectors Inputs/Outputs Full Brightness 20,000 Hours
Input/Output Connectors Inputs/Outputs Low Brightness 30,000 Hours
Fan Noise Full Brightness 36 dB
Fan Noise Low Brightness 27 dB Security Cable Lock Slot Security Bar
Fan Noise AC Input Power 100 to 240 VAC, 50 / 60 Hz
Power Consumption Full Brightness 381 W
Power Consumption Low Brightness 270 W
Standby Mode (Lamp Off) 2 W
Power Consumption Operating Temperature 41 to 113 F / 5 to 45 C
Power Consumption Operating Humidity 20 to 80%
Power Consumption Dimensions (W x H x D) 18.1 x 9.0 x 17.7" / 46.0 x 22.9 x 45.0 cm Weight 20.7 lb / 9.39 kg Packaging Info Package Weight 28.855 lb
Power Consumption Box Dimensions (LxWxH) 24.6 x 20.2 x 13.4"
SKU PL-800F
Brand Epson
