Total Outlets 10
Protected Outlets 5 x NEMA 5-15R (Battery and Surge) 5 x NEMA 5-15R (Surge Only)
Plug Type NEMA 5-15P
Data Line Protection RJ45
Communications USB, Serial via
Noise Filtering 5%
Surge Energy Rating 354 Joules
Maximum Wattage 865 W
Nominal Input Voltage 120 VAC
Input Frequency 50/60 Hz 3 Hz (Auto Sensing)
Nominal Output Voltage 120 VAC
Output Frequency 50/60 Hz 3 Hz
Load Capacity 1500 VA
Maximum Efficiency 87%
Waveform Simulated Sine Wave
Cells 1
Chemistry Lead-Acid
Recharge Time 8 Hours
Replacement Battery APCRBC124 APCRBC124J
Operating Temperature 32 to 104 F / 0 to 40 C
Operating Humidity 0 to 95%
Storage Temperature 23 to 113 F / -15 to 45 C
Operating Altitude 10,000′ / 3000 m
Storage Altitude 50,000′ / 15,000 m
Certifications REACH, RoHS, as per Manufacturer
Cable Length 6′ / 1.8 m
Dimensions (W x H x D) 11.85 x 4.41 x 15.04″ / 301 x 112 x 382 mm
Weight 26.6 lb / 12.1 kg
Package Weight 30 lb
Box Dimensions (LxWxH) 19.5 x 16 x 9.5″
Output 865W/1500VA
Input 120V
APC BR1500G Overview Output 865W/1500VA
APC BR1500G Overview Input 120V 5x Battery Backup, 5x Surge Protection NEMA 5-15R
APC BR1500G Overview Recharge Time 8 Hours
LCD Status and Control Console Cold Start/Hot Swappable Batteries
Battery and Surge Protected Outlets Back up and protect your hardware and data during power outages, surges and spikes. DataLine Surge Protection
Battery and Surge Protected Outlets Provides protection of connected equipment from power surges on the data lines. Surge Only Outlets
Battery and Surge Protected Outlets Protect secondary electronics from surges and spikes without reducing battery power used to run primary electronics during an outage. Energy Management Function
Energy saving feature automatically power off peripherals when the a master device, usually a PC, hibernates or is shut down. Power to peripherals is immediately restored when the master device wakes up or is switched on.
Boost and Trim Automatic Voltage Regulation (AVR)
Battery and Surge Protected Outlets Gives higher application availability by correcting low and high voltage conditions without using the battery. Green Mode
Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
Adjust the voltage points (widen or tighten the range) where your UPS transfers to battery to maximize useful battery life and protect sensitive electronics.
Toggle between pre-determined voltage-transfer points depending on your power quality (high, medium or low sensitivity), maximizing useful battery life and protecting sensitive electronics.
Maximizes battery performance, life, and reliability through intelligent, precision charging. Cold-Start Capable
Provides temporary battery power when the utility power is out. Battery Failure Notification
Intelligent Battery Management Provides early-warning fault analysis on batteries enabling timely preventive maintenance. Automatic Self-Test
Protect equipment with input transformer blocks without blocking access to other receptacles. Resettable Circuit Breaker
Transformer-Block Spaced Outlets Easy recovery from overloads; no need to replace a fuse. Simple Battery Replacement
Transformer-Block Spaced Outlets Increases UPS availability by allowing quick, easy battery replacement.
USB Connection Use your PC to access additional power protection and management features for your UPS via a USB Port. LCD Status Display
USB Connection Provides key UPS status at a glance. Multiple status indicators with load and battery bar graphs. Audible Alarms
Provides notification of changing utility power and UPS power conditions
Disconnected Battery Notification Warns when a battery is not available to provide backup power. APC BR1500G Specs General Total Outlets 10 Protected Outlets 5 x NEMA 5-15R (Battery and Surge) 5 x NEMA 5-15R (Surge Only) Plug Type NEMA 5-15P Data Line Protection RJ45 Communications
Disconnected Battery Notification USB, Serial via
Disconnected Battery Notification Noise Filtering 5% Power Surge Energy Rating 354 Joules Maximum Wattage 865 W
Nominal Input Voltage 120 VAC Input Frequency 50/60 Hz 3 Hz (Auto Sensing)
Nominal Output Voltage 120 VAC Output Frequency 50/60 Hz 3 Hz Load Capacity 1500 VA Maximum Efficiency 87% Waveform Simulated Sine Wave Battery Cells 1 Chemistry Lead-Acid Recharge Time 8 Hours Replacement Battery APCRBC124 APCRBC124J Environmental
Nominal Output Voltage 120 VAC Operating Temperature 32 to 104 F / 0 to 40 C
Nominal Output Voltage 120 VAC Operating Humidity 0 to 95% Storage Temperature 23 to 113 F / -15 to 45 C, Altitude 10,000′ / 3000 m Storage Altitude 50,000′ / 15,000 m Certifications
Nominal Output Voltage 120 VAC REACH, RoHS, as per Manufacturer Physical Cable Length 6′ / 1.8 m
Nominal Output Voltage 120 VAC Dimensions (W x H x D) 11.85 x 4.41 x 15.04″ / 301 x 112 x 382 mm Weight 26.6 lb / 12.1 kg Packaging Info Package Weight 30 lb
Nominal Output Voltage 120 VAC Box Dimensions (LxWxH) 19.5 x 16 x 9.5″
SKU BR1500G
Brand APC
MPN BR1500G
GTIN 00731304268772, 731304268772
UPC 731304268772
