Product code:
VPL-FHZ90L
UPC:
027242909373
Condition:
New
Availability:
In stock, ship same-day or until 48 Hrs
Shipping:
Free Shipping
Display System:
3 LCD system
Display Device:
1��� x 3 BrightEra LCD Panel, Aspect ratio: 16:10
Number of Pixels:
6,912,000 (1920 x 1200 x 3) pixels
Projection Lens:
Powered / Manual (Depend on lens)
Zoom - Powered / Manual:
Powered / Manual (Depend on lens)
Light Source:
Laser diode
Filter Replacement Cycle (Max.):
10,000 H
Screen Size:
Depend on Lens
Light Output*1:
9,000 lm*2
Mode: Standard (Center):
9,800 lm*3
Color Light*1:
9,000 lm
Mode: Middle:
8,000 lm
Contrast Ratio*1:
Contrast ratio (full white/full black): ��� : 1
Displayable Scanning Frequency:
15 kHz to 92 kHz
Vertical:
48 Hz to 92 Hz
Accepted Signal Resolution:
Maximum signal resolution: 1920 x 1200
Video Signal Input:
480/60i, 576/50i, 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i
The following items are available for digital signal only: 1080/60p, 1080/50p, 1080/24p
Keystone Correction (Max.):
*=+/- 30 degrees
Vertical:
*=+/- 30 degrees
INPUT OUTPUT (Computer/Video/Control):
RGB / Y PB PR input connector: 5 BNC (female)
INPUT B:
RGB input connector: Mini D-sub 15-pin (female)
INPUT OUTPUT (Others):
Type-A x 1
Control signal input/output:
D-sub9pin male/RS232C
LAN:
RJ45, 10BASE-T/100BASE-TX/1000BASE-T
Acoustic Noise*1:
39 dB
Light Output Mode: Middle:
39 dB
Operating Temperature / Operating Humidity:
0��C to 45��C (32��F to 109��F) / 20% to 80% (no condensation)
Storage Temperature / Storage Humidity:
-10��C to +60��C (14��F to +140��F) / 20% to 80% (no condensation)
Power Requirements:
AC 100 V to 240 V, 8.4 A to 3.4 A, 50 Hz/60 Hz
Power Consumption:
840 W
AC 220 V to 240 V:
814 W
Power Consumption (Standby Mode):
0.50 W (when "Standby mode" is set to "Low")
AC 220 V to 240 V:
0.50 W (when "Standby mode" is set to "Low")
Power Consumption (Networked Standby Mode):
21.6 W (LAN)
26.5 W (HDBT)
26.6 W (ALL terminals and networks connected, when "Standby mode" is set to "Standard")
AC 220 V to 240 V:
21.3 W (LAN)
26.5 W (HDBT)
26.6 W (ALL terminals and networks connected, when "Standby mode" is set to "Standard")
Dimensions (W x H x D) (without protrusions):
Approx. 21 13/32 x 8 1/16 x 22 7/32 inches(544 x 205 x 564 mm)
Mass:
Approx. 58 lb (26 kg)
Supplied Accessories:
RM-PJ30
Projection Lens:
VPLL-4008, Z4111, Z4015, Z4019, Z4025, Z4045
Optional Projection Lens:
Throw Ratio: 1:00:1Lens Shift - Range Vertical: +/-32%Lens Shift - Range Horizontal: +/-15%
VPLL-Z4111:
Throw ratio: 1:30:1 to 1:96:1Lens Shift ��� Range Vertical: +/-99%Lens Shift ��� Range Horizontal: +/-51%
Notes:
The figures are approximate. They vary depending on the environment or how the projector is used.
*2:
The value is in accordance with ISO 21118, and may differ depending on the actual unit. Brightness and contrast vary depending on use conditions and environments.
