NEC

NEC NP-PH1400U 3D WUXGA 1080p DLP Projector

(No reviews yet) Write a Review
SKU:
NP-PH1400U
UPC:
805736046069
MPN:
NP-PH1400U
Condition:
New
Shipping:
Free Shipping
  • NEC NP-PH1400U 3D WUXGA 1080p DLP Projector
  • NEC NP-PH1400U 3D WUXGA 1080p DLP Projector
  • NEC NP-PH1400U 3D WUXGA 1080p DLP Projector
  • NEC NP-PH1400U 3D WUXGA 1080p DLP Projector
  • NEC NP-PH1400U 3D WUXGA 1080p DLP Projector
  • NEC NP-PH1400U 3D WUXGA 1080p DLP Projector
$29,995.00

Description

NEC NP-PH1400U Overview

The NP-PH1400U 14,000 Lumen Professional Integration Projector from NEC is a fixed installation class projector for event spaces, large venues, houses of worship, lecture halls, theaters, and other settings that require a powerful light output. The NP-PH1400U features three 0.96" DLP chips that generate a 1920 x 1200 (WUXGA) native resolution and a 16:10 aspect ratio. A built-in scaling engine means the projector can accept many lower resolutions as well, including a variety of VESA computer resolutions as well as HD and SD video. Featuring an interchangeable lens design, the projector is compatible with as range of separately available lenses from NEC, including short-throw, zoom, and long-throw options.

Adaptable to a variety of input sources, the projector features two VGA inputs, an HDMI input, DisplayPort input, and Composite and S-video inputs for legacy analog equipment. There is also a 5-BNC hybrid analog input that can accept both RGBHV and Component signals. For future expansion there is an OPS (Open Pluggable Specification) slot so that you can add additional inputs and/or outputs, such as SDI, using separately available OPS-compatible expansion boards.

The projector can be controlled directly using surface panel buttons or the supplied IR remote. In addition, there is an Ethernet port and RS-232 port for remote operation either using proprietary software, software built into some operating systems (such as Windows Vista), or by logging into the projector with a web browser.

Key Features

  • WUXGA (1920 x 1200) Native Resolution
  • 14,000 Lumens Standard Output
  • Interchangeable Lens Design
  • HDMI, DisplayPort and Two VGA Inputs
  • 5-BNC Hybrid RGBHV/Component Input
  • S-Video and Composite Inputs
  • Supports Stacking and Edge Blending
  • OPS-Compatible Expansion Slot
  • PC-Less Presentations Over Network
  • IR, Ethernet and RS-232 Controllable

3-Chip DLP

Features three 0.96" DLP (Digital Light Processing) micro-mirror arrays to generate three monochrome images, one for each primary color: red, blue, and green

14,000 Lumen Dual-Lamp Design

Outputs up to 14,000 lumens, and supports "stacking" of multiple projectors to produce even higher light-levels

Interchangeable Lens Design (No Lens Included)

Short throw, zoom, and long throw lens options - available separately - mean this projector can be adapted to a wide range of setups, from close to screen mounting for rear projection to ultra-long throw for theaters or lecture halls

Integrated Scaling

Uses the NEC Hollywood Quality Video processor scaling engine to scale from input sources to do not match the projector's native 1920 x 1200 resolution

Lens Memory

Automatically resets lens attribute including zoom, focus, and shift based on the input resolution and input selection

Integrated Networking and Asset Management

Ethernet and RS-232 Connectivity

Operate the projector remotely across a network either using the Virtual Remote desktop software or from a Web browser by entering the projector's IP address (settings password protect-able). Alternatively, use RS-232 to establish a direct connection between the projector and a computer without exposing settings access to the network. There is also a wireless LAN adapter available separately for connecting to your network wirelessly

Image Express Utility for OS X and Windows

Dedicated projector software that provides wired and wireless data transmission via RS-232 or over the network. With Broadcast mode you can send information from one computer to several projectors

USB Keyboard and Mouse Inputs

You can remotely operate a computer that is networked with the projector by connecting a USB keyboard and/or mouse to the USB inputs

Windows Network Drive Function

Displays multimedia files (.jpeg, .bmp, .png, .mpeg2, or .wmv9) stored in a Windows shared folder or on a Windows Media Connect server present on the same network as the projector, allowing you to give presentations without bringing your computer into the conference room

Security

Cabinet Control Lock

Lock out surface panel buttons to prevent tampering or accidental settings changes

Logo Lock

Prevents unauthorized uses from changing the logo saved in projector memory

Password Protection

Restricts unauthorized access to projector settings

Email Notifications

Sends an alert when the lamp is approaching the end of life

Power Management

Up to 3000 Hours Lamp Life

The normal 2500 hour lamp life can be extended up to 3000 hours by using the lower brightness ECO Mode

Auto Standby

The projector will automatically turn off when an incoming signal is not detected from any of the inputs

Auto Power On

Powers up automatically when a signal is detected through the VGA port

Carbon savings meter

Calculates the energy saved by operating the projector in ECO Mode. A green ECO Mode button on the remote control allows you enable or disable ECO Mode without going into the menu

Quick Start

Responds to users inputs within three to four seconds, even while the projector is still warming up. Quick Shutdown, meanwhile, means you can kill the projector immediately, with no cooling required after shutdown

Sleep Time

Can be set to automatically turn off the projector at set countdown times

Low Power Consumption Standby

Consumes an estimated 0.5 watts in standby mode

Maintenance

2000 Hour Filter Life

Designed so that you should only need to replace the filter at the same time you replace the lamp

Remote Diagnostics

Enables you to monitor and make adjustments to the projector remotely

Built-in Software

Stacking Correction

Uses a webcam to help align multiple images when "stacking" up to four projectors for a brighter output - up to 56,000 lumens with four projectors. Stacking also provides redundancy, meaning you will still have an image even if one projector in the system fails

Picture-in-Picture and Side-by-Side

Combine two video sources in one presentation. Picture-in-picture overlays a smaller sub-window over the main image, whereas side-by-side gives both images equal precedence

Edge Blending

Helps you merge the edges of two or more projected images together when using multiple projectors to create non-standard aspect ratios or to display ultra-high resolution images

Built-in Wall Color Correction Presets

Automatically correct when projecting onto non-white surfaces, such as a wall that is painted green

DICOM Simulation

Optimizes settings for DICOM imagery such as X-rays

Cornerstone Correction

In addition to normal vertical and horizontal keystone correction, the software also digital corrects for diagonally skewing to help simply challenging installations

Geometric Correction

Projecting an image isn't confined to a standard flat screen or wall. Geometric correction allows you to project onto shapes such as on spheres, cylinders, corner angles, and many more non-standard surfaces

AutoSense

Automatically syncs with any computer signal and features one-touch image optimization

64-step Image Magnification

Allows you to target the focus on a particular part of the source image or crop images to fit one of the aspect ratios the projector provides

NEC NP-PH1400U Specs

Image Display

Display System 3-Chip 0.96" DC3 DMD DLP
Native Chip Resolution 1920 x 1200 (WUXGA)
Supported Resolutions WUXGA - 1920 x 1200
Maximum Brightness 14,000 Lumens
Uniformity None
Offset None
DLP Link 3D Yes
Color Wheel 3-Segment (R/G/B)
Scan Horizontal: 15 to 8 kHz
Vertical: 48 to 120 kHz

Lens

Lens Shift Vertical: + 50%
Vertical: to 40%
Horizontal: ± 20%
Throw Distance 1.8 - 243' / 0.549 - 74.066 m
Projection Size 80 - 500" / 203.20 - 1270.00 cm

Features

Keystone Correction Vertical: ± 30°
Horizontal: ± 35°
Ceiling Mountable Yes
Rear Screen Projection Yes

Hardware

Internal Storage None
Wireless LAN / Wi-Fi No, Optional Adapter Available

General

Light Source Lamp (2 x UHP)
Lamp Power 465 W
372 W
Expected Lamp Life Medium Brightness: 2500 Hours
Low Brightness: 3000 Hours
Fan Noise Medium Brightness: 45 dB
Low Brightness: 39 dB
Security Cable Lock Slot
Password Protection
Power Consumption Medium Brightness: 1215 W
Low Brightness: 985 W
Standby Mode (Lamp Off): 90 W
Low Brightness: 0.5 W
Dimensions (W x H x D) 22.7 x 22.0 x 9.3" / 57.7 x 55.9 x 23.6 cm
View AllClose

Warranty Information

1 Year Parts & Labor Manufacture Warranty
