Product Overview
Specifications
-
Source
(36) 3W RGBW LEDs
100,000 Hour Average Life -
Photometrics
3,650 LUX 339 FC @3.3' (1m) (41 Degree Full ON)
1,020 LUX 95 FC @6.6' (2m) (41 Degree Full ON)
458 LUX 43 FC @9.8' (3m) (41 Degree Full ON)
255 LUX 24 FC @13.1' (4m) (41 Degree Full ON)
164 LUX 15 FC @16.4' (5m) (41 Degree Full ON) -
Effects
Strobe and Color Macros
Dimming : 0% - 100%
Selectable Dimming Curves -
Control / Connections
11 DMX Channel Modes (1 / 3 / 4x2 / 5x2 / 6x2 / 7 / 8 / 10)
Frequencies (1200Hz, 2400Hz, 4800Hz, 9600Hz)
E-Fly Internal Extended Range Wireless DMX Transceiver
4 Button Control Panel and LCD Menu Display
5pin DMX In/Out
RDM (Remote Device Management)
Locking Power Cable In
With Wired Digital Communication Network -
Electrical / Thermal
AC 100-240V - 50/60Hz
110W Max Power Consumption
14 Degree F to 113 Degree F (-10 Degree C to 45 Degree C) -
Firmware Updates
Current Version: V1.15
-
Dimensions (L x W x H)
14.7 x 9.9 x 12" (374 x 252.5 x 308.8mm)
-
Weight
14 lbs (6.4kg)
-
UPC Code
837874018516
