Product info:
- 16-channel amplifier with 8 independent playback zones
- 37 watts per channel into 8 ohms (1,000 Hz) with one zone driven
- 75 watts per channel into 4 ohms (1,000 Hz) with one zone driven
- 150 watts per channel into 8 ohms in bridged mode (one zone driven)
- high-efficiency Class D amplification
- thermal fan cooling
- signal-to-noise ratio: greater than 90 dB
- rear-mounted, independent level controls for each zone
- 3 output filter settings for each zone
- full-range (full): the entire, unfiltered audio signal is sent to the speakers
- low-pass (lp): frequencies from 20 Hz to 160 Hz are sent to the speakers — great for passive subwoofers
- high-pass (hp): frequencies from 80 Hz to 20,000 Hz are sent to the speakers
Connections:
- Bus A and Bus B stereo RCA inputs let you assign connected sources to any zone
- discrete "local" RCA inputs for each zone
- 12V trigger input and output for automated turn-on
- signal-sensing input activates the amplifier when a source is detected
- global trigger input/output
- detachable Phoenix-style speaker connectors support up to 14-gauge wire
- removable AC power cord
